  • Page 2 16 Limited Warranty Information ©2016 Rockford Corporation. All Rights Reserved. PUNCH® and associated logos where applicable, are registered trademarks of Rockford Corporation in the United States and/ or other countries. iPhone and iPod are trademarks of Apple Inc., registered in the U.S. and other countries. The Bluetooth word mark and logos are registered trademarks owned ®...

  • Page 3: Specifications

    Specifications PMX-8BB Model Operating Voltage 10.5V - 16V Fuse Rating 25 W X 4 @ 4 Ohms RMS Power Output 50 W x 4 @ 2 Ohms Peak Max. RCA Output Voltage Output Impedance 500Ω Frequency Response 20 - 20kHz FM Frequency Range 87.5MHz - 107.9MHz...
  • Page 4 Dimensions 6.9” (175mm) 2.2” (56mm) 8.3” (210mm) Fig. 1...

  • Page 5: Wiring Diagram

    ACC (+12V) GREY SPEAKER FRONT RIGHT (+) GREY/BLACK SPEAKER FRONT RIGHT (-) SECTION A-A SECTION B-B Wiring Diagram BLUE/WHITE REMOTE (+) PURPLE SPEAKER REAR RIGHT (+) PURPLE/BLACK SPEAKER REAR RIGHT (-) BLACK GROUND (-) 12 PIN MOLEX FUSE CONNECTOR LINE OUT LEFT ZONE1 LINE OUT RIGHT ZONE 1...
  • Page 6 Wiring Diagram LINE OUT LEFT ZONE1 LINE OUT RIGHT ZONE 1 LINE OUT SUB-W OUT 1 BLACK SUB-W OUT 2 BLACK SIRIUSXM INPUT LINE OUT LEFT ZONE2 LINE OUT RIGHT BLACK ZONE 2 LINE OUT SUB-W OUT 1 GREY SWI INPUT SUB-W OUT 2 AUX IN LINE OUT LEFT...
  • Page 7 Wiring Diagram PIN NO. WIRE COLOR WIRE DEFINITION GREEN SPEAKER REAR LEFT (+) GREEN/BLACK SPEAKER REAR LEFT (-) ORIENTATION ORANGE/WHITE ILLUMINATION WHITE SPEAKER FRONT LEFT (+) WHITE/BLACK SPEAKER FRONT LEFT (-) ACC (+12V) GREY SPEAKER FRONT RIGHT (+) GREY/BLACK SPEAKER FRONT RIGHT (-) SECTION A-A SECTION B-B BLUE/WHITE...
  • Page 8 Installation / Mounting Mounting Contents • Source Unit To mount the unit, you will need to find a flat surface with adequate sup- port material that provides a secure mounting location. • 13-pin Extension Cable (PMX10C) 1. Once you have determined a mounting location, you will need to mount the unit vertically with the wire harnesses facing down.
  • Page 9 This source unit has a zero current draw when turned off. All of your Punch EQ is an onboard equalizer with up to +6dB @45Hz and/or up to settings and presets will be saved along with your boat’s battery during +6dB boost at 12.5kHz...

  • Page 10: Basic Operation

    Settings SOFTWARE VERSION - Short press the encoder button to display the current firmware version of the unit. UPDATE - Short press the encoder button to update the firmware. Follow the instructions on the screen when updating. PMX-CAN DIAGNOSTICS STATUS - Short press the encoder button to display the connection status.
  • Page 11 Operation AM BAND SETTINGS To access the AM BAND SETTINGS, short press the MENU when using the AM TUNER source. This will give you access to the settings specific to the AM TUNER (PRESETS>ADD PRESETS>REMOVE PRESETS>AM>AUTO STORE>LOCAL). PRESETS Short press the encoder button to access the PRESETS list. Using this feature allows you to see what PRESETS are saved on the unit.

  • Page 12: Bluetooth Operation

    Operation Bluetooth Operation Pandora ® ® After your device is paired to the source unit, this feature allows you This feature allows you to control the Pandora app from the source unit ® to control playback from your device directly from the unit. Select the directly (Android users will have to use Bluetooth only, iOS users can BLUETOOTH source option on the source unit.

  • Page 13: Direct Tuning

    Operation PRESETS Short press the encoder button to access the PRESETS list. Using this feature allows you to see what PRESETS are saved on the unit. ADD PRESETS Short press the encoder button on the ADD PRESETS option. You will need to be on both the channel and PRESET group you want to add first (SXM1>SXM2>SXM3).

  • Page 14: Troubleshooting

    Troubleshooting Symptom / Advisory Diagnosis Remedy Basic Blown fuse Check fuse of the unit, replace with correct rating. If connected following the instructions, the unit will not Vehicle’s ignition is off operate with ignition off. Source unit does not turn on. Voltage applied to Red wire is not Check battery, connections and fuses and repair or replace between 10.5 &...
  • Page 15 Troubleshooting Verify that your vehicle is outdoors with a clear view of the sky. Verify that the SiriusXM magnetic mount antenna is mounted on a metal surface on the outside of the vehicle. The SiriusXM Connect Tuner is having Move the SiriusXM antenna away from any obstructions. No Signal difficulty receiving the SiriusXM satel- Inspect the antenna cable for damage and kinks.

  • Page 16: What Is Covered

    Warranty Rockford Corporation offers a limited warranty on Rockford Fosgate products on the following terms: Length of Warranty POWER Amplifiers – 2 Years Direct Fit Speakers – 2 Years ® Source Units – 2 Years All other products – 1 Year Any Factory Refurbished Product –...
