- Page 1 MANUAL PMR4000R INFO@APART-AUDIO.COM...
-
Page 2: Important Safety Instructions
Features The APart PMR4000R is a professional multi source music player with integrated FM RDS tuner, internet radio, UPnP and USB media player, compatible with MP3, WMA, FLAC and WAV audio files. The unit is equipped with analog outputs, optical digital output for the digital media player, wired Ethernet and Wifi 2.4G. -
Page 3: Front Panel
12. Info: Press the „INFO“ button repeatedly to browse through diverse information. The type of information and whether information is displayed all depends on the broadcasting station or connected media. The info button works in all operating modes. INFO@APART-AUDIO.COM... -
Page 4: Rear Panel
2. Output level adjustment: turn this potmeter to set the analog output to a certain level. This feature comes in handy when more sources are in use in the same system. 3. Analog output on cinch connectors: white = left channel, red = right channel. WWW.APART-AUDIO.COM... -
Page 5: Getting Started
Alternatively, connect the optical digital output to your digital playback system. The optical digital jack is a standard Toslink® optical connector and carries a digital SPDIF signal from the USB/UPnP/internet radio. Turn the output level potmeter to a position that suits your needs. INFO@APART-AUDIO.COM... -
Page 6: Remote Control
Remote control: The handheld infrared remote control requires two „AAA” batteries for operation. Inserting/changing batteries: Remove the battery compartment lid carefully. Insert new batteries and ensure correct polarity, as graphically displayed inside the compartment. Replace the battery lid carefully. WWW.APART-AUDIO.COM... -
Page 7: Power Supply
“wired” and proceed until the setup wizard has finished. Detailed information on network settings will be explained below. After finishing the setup wizard, select a module via the push buttons or via the menu: FM radio, internet radio, USB or UPnP. INFO@APART-AUDIO.COM... - Page 8 PMR4000R is connected to the same network and has received an IP address, it will be shown in the list as follows: APart PMR4000R (followed by a unique identifier). Select “Allowed” and save the changes. Click on “Customize” in the dialog window and check the media streaming settings.
- Page 9 1. Make sure your PC is connected to the network and set it up as a UPnP server. 2. Ensure that the PMR4000R has been turned on and is connected successfully to the same network. 3. Add supported audio files (MP3/WMA/FLAC or WAV) and/or folders you want to share with your PMR4000R to your Windows Media Player’s media library.
- Page 10 Control Panel\All Control Panel Items\Network and Sharing Center\Media streaming options In this screenshot we see the APart PMR4000R showing up in the network ! You have to allow the unit to access the UPnP server’s media files ! WWW.APART-AUDIO.COM...
- Page 11 Click “Customize” in the field showing the APart PMR4000R to check media streaming settings. Select “Make all of the media in my library available to this device” instead of “Use default settings”. Normally this is optional, but when your media files have been redirected...
- Page 12 When you select “Internet radio“ or “UPnP” mode, PMR4000R will try to connect to a network. If this is the first time that a connection has been made or previously accessed networks are not accessible, then the “Network Wizard”...
-
Page 13: Network Profile
Storing a radio station to memory: 10 memory presets are available for storing. Tune to an internet radio station. Press and hold a numeric key 1 to 10 on the handheld remote until “Preset stored” INFO@APART-AUDIO.COM... -
Page 14: Internet Radio Portal
The portal is free of charge. To register your unit on this portal, you need an access code: Search for the access code on your PMR4000R: in internet radio operation mode, press the menu button, select “Station List”, scroll down to “Help” and select “Get Access code”. -
Page 15: General Functions
These folders and favourite stations will immediately show up on your PMR4000R. To access the added favorites, press the menu button, select “Station List”, “My Favourites”. Now the folders with the added favourite stations you created online will show up on the unit. -
Page 16: Fm Radio Operation
The maximum analog output level can be preset using the volume knob at the back of the unit. Set the volume knob to adjust the analog output level of the PMR4000R to be equal to the level of other sound sources in your system. - Page 17 In all cases, it is mandatory to use an FM separation transformer (available in specialized shops) to galvanically separate the PMR4000R and all other units in the audio chain from the external antenna or cable network. Failure to do so will...
- Page 18 Nr of presets Wifi 2.4GHz 802.11g Authentication Open, Pre-shared key (PSK), Wifi protected access (WPA) or WPA2 Channels selectable per country Ethernet Connector standard RJ45 network port General Power supply 230 VAC/50Hz Power consumption max 30VA WWW.APART-AUDIO.COM...
- Page 19 Mains power cable, IR remote control unit, Wifi antenna, FM antenna wire Remote control battery 2 pcs type AAA type LR03 Operating temperature 10-40°C Relative humidity 10 to 80% non-condensing Dimensions LxWxH: 484 (430)x325 (300) x44 mm Weight 3850g INFO@APART-AUDIO.COM...
-
Page 20: Warranty Info
This warranty is valid only for the original end-user and cannot be transferred. During the warranty period APart-Audio or one of its authorized service partners shall either repair or replace any product, free of charge, that proves to be defective on inspection by APart-Audio or its authorized service representative.
