INSTALLATION INSTRUCTIONS

– Air Conditioner –
for Refrigerant R410A
■ R410A Models
Model No.
Indoor Units
Rated Capacity
Type
Indoor Unit Type
200
E2
High Static Pressure Ducted
S-200PE2R5
Connectable outdoor unit for this indoor unit is the model U-200PE1R8.
Read through the Installation Instructions before you proceed with the installation.
In particular, you will need to read under the "IMPORTANT!" section at the top of the page.
85464369848020
CV6233318769

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-200PE2R5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Panasonic S-200PE2R5

Summary of Contents for Panasonic S-200PE2R5

  • Page 1: Installation Instructions

    Type Indoor Unit Type High Static Pressure Ducted S-200PE2R5 Connectable outdoor unit for this indoor unit is the model U-200PE1R8. Read through the Installation Instructions before you proceed with the installation. In particular, you will need to read under the “IMPORTANT!” section at the top of the page.

  • Page 2: Important

    IMPORTANT! • Provide a power outlet exclusively for each unit, and full disconnection means Please Read Before Starting having a contact separation in all poles This air conditioner must be installed by the sales dealer must be incorporated in the fixed wiring or installer.
  • Page 3 …At least 2.5 m • Clean up the site after you finish, remembering to check that no metal 　 Indoor unit of this air conditioner shall be chips or bits of wiring have been left installed in a height of at least 2.5 m. inside the unit.

  • Page 4: Table Of Contents

    CONTeNTS Page Page IMPORTANT ........2 7.

  • Page 5: General

    1. GeNeRAL 1-4. Additional Materials Required for Installation Refrigeration (armored) tape This booklet briefly outlines where and how to install the air conditioning system. Please read over the entire set of Insulated staples or clamps for connecting wire (See your local codes.) instructions for the indoor and outdoor units and make sure all accessory parts listed are with the system before beginning.

  • Page 6: How To Install The Indoor Unit

    3. HOW TO INSTALL THe INDOOR UNIT ■ High Static Pressure Ducted Type (Type e2) 3-1. Required Minimum Space for Installation and Service (1) Dimensions of suspension bolt pitch and unit 1170 Unit: mm (Suspension bolt pitch) (60) (60) 1100 Inspection access (600 ×...

  • Page 7: Suspending The Indoor Unit

    3-2. Suspending the Indoor Unit Depending on the ceiling type: 1. Check the suspension bolt pitch. 2. Ensure that the ceiling is strong enough to support the weight of the unit. 3. To prevent the unit from dropping, firmly fasten the suspension bolts as shown in the figure below. Unit: mm Hole-in-anchor Hexagonal nut (field supply)

  • Page 8: Installing The Refrigerant Tubing

    3-3. Installing the Refrigerant Tubing The size of the refrigerant tubing is as shown in the table below. Table 3-1 Type ø19.05 Gas tube (Brazing connection) ø9.52 (Flare connection) Tightening torque (approximate) Liquid tube : 34 ~ 42 N • m Thickness of connecting tube : 0.8 mm NOT E...

  • Page 9: Installing The Drain Piping

    3-4. Installing the Drain Piping Sealing tape (1) Prepare standard hard PVC pipe (O.D. 32 mm) for the drain and use the supplied drain socket to prevent water leaks. The PVC pipe must be purchased separately. When doing this, apply adhesive for the PVC pipe at the connection point. Drain socket (2) If connecting a drain socket (supplied) to the threaded drain port, first wrap the (supplied)

  • Page 10: Caution For Ducting Work

    3-5. Caution for Ducting Work • This unit has high static pressure. In case of small pressure resistance (for instance, a short duct), install an airflow control damper (field supply) for adjusting airflow volume as airflow volume / airflow noise increases. •...

  • Page 11: Electrical Wiring

    4. eLeCTRICAL WIRING 4-1. General Precautions on Wiring (1) Before wiring, confirm the rated voltage of the unit as shown on its nameplate, then carry out the wiring closely following the wiring diagram. WARNING (2) This equipment is strongly recommended to be installed with Earth Leakage Circuit Breaker (ELCB) or Residual Current Device (RCD).
  • Page 12 CAUTION (1) When linking the outdoor units in a network, disconnect the terminal extended from the short plug from all outdoor units except any one of the outdoor units. (When shipping: In shorted condition.) For a system without link (no wiring connection between outdoor units), do not remove the short plug. (2) Do not install the inter-unit control wiring in a way that forms a loop.
  • Page 13 How to connect wiring to the terminal ■ For stranded wiring (1) Cut the wire end with cutting pliers, Stranded wire Special Screw then strip the insulation to expose washer the stranded wiring about 10 mm and Ring pressure tightly twist the wire ends. (Fig. 4-6) Ring pressure terminal Screw and...

  • Page 14: How To Process Tubing

    5. HOW TO PROCeSS TUBING NOTE Refer to the Installation Instructions attached to the Outdoor Unit. 6. HOW TO INSTALL THe TIMeR ReMOTe CONTROLLeR OR HIGH-SPeC WIReD ReMOTe CONTROLLeR (OPTIONAL PART) NOTE Refer to the Operating Instructions attached to the optional Timer Remote Controller or optional High-spec Wired Remote Controller.

  • Page 15: External Static Pressure Setting

    8. eXTeRNAL STATIC PReSSURe SeTTING Choose one of the methods (selection of “a”, “b”, “c” within the range of dotted line as shown in the flowchart below) and make settings. a. No setting changes: When using as it is factory preset at shipment. (If resetting after external static pressure setting once, it might be different from factory preset.) b.

  • Page 16: Operating The Timer Remote Controller (Cz-Rtc2)

    8-1. How to Set on PC Board 1. Turn off the power breaker to halt the supply of electricity to the PC board. 2. Open the lid of the electrical component box and confirm the location where the Select switch on the indoor unit control PCB is placed.

  • Page 17: Operating The High-Spec Wired Remote Controller (Cz-Rtc3)

    8-3. Operating the High-spec Wired Remote Detailed settings 20:30 (THU) Controller (CZ-RTC3) Unit no. Code no. Set data Sel. Next 20:30 (THU) 4. Select the “Set data” by pressing the button. Select one of the “Set data” among “0006”, “0003” START or “0001”...

  • Page 18: Operating The Timer Remote Controller (Cz-Rtc4)

    8-4. Operating the Timer Remote Controller (CZ-RTC4) <Procedure> Table 8-4 Setting the external static pressure Indoor unit Item code 1. Press and hold down the Type 200 buttons simultaneously for 4 or more seconds. External static pressure of the rated airflow volume , the Unit No., Item Code and Detailed 270 Pa Data will blink on the LCD display.)

  • Page 19: Appendix

    9. APPeNDIX Type Period (Depends on filter specifications) ■ Name of Parts An air filter is not provided with this air conditioner at the time of Type e2 (HIGH STATIC PReSSURe DUCTeD) shipment. To get clean air and to extend the service life of the air conditioner, an air filter must be installed in the air intake.
  • Page 20 85464369848020 Printed in China DC0315-0...
