- Page 1 LavryBlack Series Model DA10 Digital to Analog Converter Lavry Engineering, Inc. P.O. Box 4602 Rolling Bay, WA 98061 http://lavryengineering.com email: techsupport@lavryengineering.com Rev 3.52 August 6, 2009...
-
Page 4: Rear Panel
Rear Panel CONNECTIONS: CAUTION: Care must be taken when connecting the DA10 directly to the input of a power amplifier or powered monitors to avoid speaker damage. It is suggest that before making any connections, the DA10’s Volume setting be reduced to a low value (“00” to “05”). Please switch OFF or disconnect power to all devices in your system before making input and output connections to the DA10. -
Page 5: Operation
Connect the XLR OUTPUTS to your destination device (recording studio equipment, receiver, power amplifier, or powered speakers). Use XLR to RCA adapters or adapter cables to connect the XLR outputs of the DA10 to equipment with RCA inputs. If connections are made to equipment with unbalanced inputs, please be sure to set the internal jumpers for the proper unbalanced mode (typically “Pin 2 Hot”). -
Page 6: Pll Settings
LavryBlack DA10 Operation - When the PLL mode is set to narrow or crystal and the DA10 receives a valid input signal, both the “lock” lamp and the sample rate indicator that corresponds to the input’s sample frequency illuminate. The input must have a sample frequency of 44.1, 48, 88.2, or 96 kHz. -
Page 7: Volume Control
There are two ways the DA10 can be used to listen to digital audio sources through speakers: 1.) Connect the main output of the DA10 to the input of a receiver or preamp, set the DA10 to a “fixed” level, and adjust the speaker volume using the volume control of the receiver or preamp. - Page 8 LavryBlack DA10 Operation 2.) Connect the main output of the DA10 directly to the input of a power amp or powered monitors and use the Volume control of the DA10 to adjust the speaker volume. PLEASE NOTE: When operating the DA10 connected directly to a power amp or powered monitors, it is important to reduce the VOLUME of the DA10 to a very low setting BEFORE turning the AC power of the power amp or monitors “ON!”...
- Page 9 V peak to peak, balanced or unbalanced). At the point where the horizontal line intersects the curve, trace straight down to the scale on the bottom of the graph to find the closest DA10 Volume control setting that will be the maximum volume for your equipment’s inputs. Pro users can use the vertical scale on the left edge of the graph for the same purpose using dBu units.
-
Page 10: Unbalanced Connections
Opening the DA10 to Set the Internal Jumpers- 1.) If you have not plugged the DA10 in yet, it is a good idea to do so first. Plug in the only the AC power cord, and turn the DA10 “ON.” Start by reducing the volume setting to “00” and turn “OFF”... - Page 11 PLL settings, if you have not already done so. Turn “ON” the power amp or raise the volume of the preamp to a normal level. Start playback of your source, and using the DA10’s level control, raise the volume until you hear sound from your speakers. If you have turned the volume setting up to at least “20,”...
-
Page 12: Specifications
If you have any questions, contact: techsupport@lavryengineering.com Please Note: The DA10 automatically adjusts to AC power inputs in the range of 90 to 264 Volts AC and line frequencies between 47 and 63 Hertz. There are no settings to change. -
Page 13: Limits And Exclusions
Subject to the conditions set forth below, for one year after the original purchase date of the product, Lavry Engineering will repair the product free of charge in the United States in the event of a defect in materials or workmanship.
