05
Sequencer, Animator
and Arpeggiator
1
2
3
4
5
6
7
8
9
0
5
6
7
8
42
In this section we are going to explain three very important features of the Modal 008: first
of all, our very powerful 12 row, 32 step Sequencer; secondly, a unique tool called Animator,
a note-triggered sequencer for parameters that allow you to create complex modulations;
finally, the 008's Arpeggiator.
To access the screen page related to one of these sections, you can either repeatedly press the
Seq/Ani/Arp panel button underneath the Tempo knob or use the second 'menu button' (B).
The Sequencer, Animator and Arpeggiator can all be monitored and controlled with the
Sequencer front panel, which you can find on the right-hand side of the screen: this panel
features 16 push-dials and 16 red/blue LEDs which always mirror the parameters displayed on
the LCD.
This panel also features:
•
the Tempo encoder, which can be turned to change the current Song Tempo (expressed
in BPM) and also tapped to start/stop the Sequencer
•
Backward/Forward buttons, for changing the step position on the LCD/panel (both for the
Sequencer and the Animator)
•
a Mode button, for changing the direction mode of the sequence/animation
•
Up/Down buttons, for changing the two currently displayed rows on the panel and the
LCD (both for the Sequencer and the Animator)
43
