Di2 Gear Cable Routing - BMC Team Machine SLR01 Assembly Instructions Manual

Note: the DO stopper is cylindrical. There is no flat surface on it, and in opposition with the rear brake cable stopper
(described in point 5. of section "Rear brake cable")
YES

Di2 gear cable routing

1. Prepare the frame for Di2 gear cable routing by installing the DT cover (1) and the BB cover as shown on the picture (2) below.
Please make sure that the BB cover is well clipped inside the frame (3).
When needed, please look at the instructions described in point 5. of section "Gear cable routing for mechanical
shifting".
1
3
NO
2
