- Page 1 MWR15 Marine Wired Remote Control INSTALLATION / OWNER'S MANUAL IPX6 Waterproof UV Resistant Salt Resistant...
-
Page 2: Control Locations
Dimension Ø61mm(2.4") 16mm(0.6") 29.6mm(1.2") 250mm(9.8") 250mm(9.8") Control Locations 1. Volume up: To adjust volume up 2. Mute: To silence the audio 3. Tune/Track up: To move radio frequency up in tuner mode or track in CD, USB mode etc. that the receiver supports 4. - Page 3 Wiring Extension Cable(included 1M) HEAD UNIT(not included) 3.5mm jack connects directly into SWC (Steering Wheel Control) input of any receiver Once the remote has been mounted, connect the extension cable to the remote and head unit as shown in the diagram above. When routing the extension cable. be sure to avoid sharp objects, tight corners, and places where it might get pinched as this could affect performance and cause damage to the unit.
-
Page 4: Installation
Turn on the receiver and test the functions of the remote control. * Choose and prepare location. MWR15 is designed to be mounted in a 2"(50mm) gauge cutout. Mounting depth will vary, but at least 2.5" is needed to mount the remote control. - Page 5 Standard Gauge Cutout Mounting Attach rubber gasket to the back of remote housing and insert into gauge hole opening. Fasten to the stainless mounting bracket with the included hardware.
-
Page 6: One-Year Limited Warranty
