Summary of Contents for Acer H5370BD series
- Page 1 Acer Projector H5370BD/E131D/HE-711J Series User's Guide Downloaded From projector-manual.com Acer Manuals...
- Page 2 Serial number: ___________________________________ Date of purchase: ________________________________ Place of purchase: ________________________________ Acer and the Acer logo are registered trademarks of Acer Incorporated. Other companies' product names or trademarks are used herein for identification purposes only and belong to their respective companies.
- Page 3 Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind onto or into the product. Downloaded From projector-manual.com Acer Manuals...
- Page 4 Use the product only with the supplied power supply cord set. If you need to replace the power cord set, make sure that the new power cord meets the following requirements: detachable type, UL listed/CSA certified, VDE approved or its equivalent, 4.5 meters (15 feet) maximum length. Downloaded From projector-manual.com Acer Manuals...
- Page 5 Locations where the altitudes are higher than 10000 feet. • Unplug immediately if there is something wrong with your projector. Do not operate if smoke, strange noise or odor comes out of your projector. It Downloaded From projector-manual.com Acer Manuals...
- Page 6 • This product is capable of displaying inverted images for ceiling mount installation. Only use acer ceiling mount kit for mounting the projector and ensure it is securely installed. Downloaded From projector-manual.com Acer Manuals...
- Page 7 Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure utmost protection of the global environment, please recycle. For more information on the Waste from Electrical and Electronics Equipment (WEEE) regulations, visit http://www.acer-group.com/public/ Sustainability/sustainability01.htm Mercury advisory For projectors or electronic products containing an LCD/CRT monitor or display: “Lamp(s) contain Mercury,...
-
Page 8: Precautions
When the lamp reaches the end of its life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn back on until the lamp module has been replaced. To replace the lamp, follow the procedures listed under "Replacing the Lamp". Downloaded From projector-manual.com Acer Manuals... -
Page 9: Table Of Contents
How to optimize image size and distance How to get a preferred image size by adjusting distance and zoom User Controls Installation menu Acer Empowering Technology Onscreen Display (OSD) Menus Color Image Setting Management Audio Language Downloaded From projector-manual.com Acer Manuals... - Page 10 Appendices Troubleshooting LED & Alarm Definition Listing Cleaning and replacing the dust filters Replacing the Lamp Ceiling Mount Installation Specifications Compatibility modes Regulations and safety notices Downloaded From projector-manual.com Acer Manuals...
-
Page 11: Introduction
Enables projecting 3D content via DLP Link Technology: Blue-Ray 3D supported and Nvidia 3DTV Play Ready • Enrich 3D experience for 2D contents via 2D to 3D convert function • Acer ColorBoost technology delivers nature’s true colors for vivid, life-like images • High brightness and contrast ratio •... -
Page 12: Package Overview
Contact your dealer immediately if any thing is missing. Projector Power cord VGA cable Security card 2 x Batteries Carrying case E131D/ HE-711J/ H5370BD Series P/N:MC.JG511.002 Quick Start Guide User's Guide (CD-ROM) Remote control Dust Filters (Optional) MHL cable (Optional) Downloaded From projector-manual.com Acer Manuals... -
Page 13: Projector Overview
HDMI 2/MHL connector RS232 connector HDMI 1 connector Audio input connector S-Video input connector 10 Power socket YPbPr/YCbCr input connector 11 Kensington lock port Composite video input connector 12 Dust filter inlets Downloaded From projector-manual.com Acer Manuals... -
Page 14: Control Panel
SOURCE Changes the active source. POWER See the contents in "Turning the Projector On/Off" section. Empowering key Unique Acer functions: e3D, eView, eTimer, ePower Management. • MENU Press "MENU" to launch the Onscreen display (OSD) menu, back to the previous step for the OSD menu operation or exit the OSD menu. -
Page 15: Remote Control Layout
MUTE To turn on/off the volume. ZOOM Zooms the projector display in or out. Empowering Unique Acer functions: e3D, eView, eTimer, ePower Management. • MENU Press "MENU" to launch the Onscreen display (OSD) menu, back to the previous step for the OSD menu operation or exit the OSD menu. - Page 16 1080i), YCbCr (480i/576i) and RGBsync. S-VIDEO To change source to S-Video. SD/USB A No function. USB B No function. HDMI/DVI To change source to HDMI™ or MHL (HDMI 2/MHL connector only). (no DVI function) LAN/WiFi No function. Downloaded From projector-manual.com Acer Manuals...
-
Page 17: Mhl (Mobile High-Definition Link) Control
(only for Multi-Media mode) Forward Scans forward through the file playback. (only for Multi-Media mode) KeyPad 0~9 Number buttons. (only for Numeric mode) PgUp/PgDn Use the button to select the next or previous page. (only for Navigation mode) Downloaded From projector-manual.com Acer Manuals... -
Page 18: Getting Started
Description Power cord Audio cable Jack/Jack USB cable VGA to component/HDTV adapter HDMI cable 3 RCA component cable S-Video cable RS232 cable Composite video cable Audio cable Jack/RCA VGA cable MHL cable (MicroUSB to HDMI) Downloaded From projector-manual.com Acer Manuals... - Page 19 Note: To ensure the projector works well with your computer, please make sure the timing of the display mode is compatible with the projector. Note: USB cable needs powered extender if the length is over 5 m. Downloaded From projector-manual.com Acer Manuals...
-
Page 20: Turning The Projector On/Off
If you connect to multiple sources at the same time, use the "Source" button on either control panel or the remote control or direct source key on the remote control to switch between inputs. Power button Downloaded From projector-manual.com Acer Manuals... -
Page 21: Turning The Projector Off
LED temp indicator will blink. Contact your local dealer or service center. Note: Whenever the projector automatically shuts down and the LED lamp indicator turns solid red, contact your local reseller or service center. Downloaded From projector-manual.com Acer Manuals... -
Page 22: Adjusting The Projected Image
Adjusting the Height of Projected Image The projector is equipped with tilt adjusting wheels for adjusting the height of image. To raise/lower the image: Use Tilt adjusting wheels to fine-tune the display angle. Tilt adjusting wheel Downloaded From projector-manual.com Acer Manuals... -
Page 23: How To Optimize Image Size And Distance
Note: Remind as below figure, the space of 122 cm height is required when located at 3 m distance. Height: 122 cm from base to top of image Height: 112 cm 3 m Desired Distance Figure: Fixed distance with different zoom and screen size. Downloaded From projector-manual.com Acer Manuals... - Page 24 387 x 218 412 x 232 452 x 254 471 x 265 516 x 290 529 x 298 581 x 327 588 x 331 645 x 363 10.3 606 x 341 665 x 374 Zoom Ratio: 1.1x Downloaded From projector-manual.com Acer Manuals...
-
Page 25: How To Get A Preferred Image Size By Adjusting Distance And Zoom
The table below shows how to achieve a desired image size by adjusting either the position or the zoom ring. Example: to obtain an image size of 50" set the projector at a distance 1.7 m and 1.9 m from the screen and adjust the zoom level accordingly. Downloaded From projector-manual.com Acer Manuals... - Page 26 133 x 75 155 x 87 177 x 100 199 x 112 221 x 125 266 x 149 332 x 187 398 x 224 443 x 249 553 x 311 664 x 374 10.3 Zoom Ratio: 1.1x Downloaded From projector-manual.com Acer Manuals...
-
Page 27: User Controls
The new settings will be saved automatically upon exiting the menu. Push the menu button anytime to exit the menu and return to the Acer welcome screen. Downloaded From projector-manual.com Acer Manuals... -
Page 28: Acer Empowering Technology
Acer Empowering Technology Acer Empowering Key provide four Acer unique functions, they are "Acer eView Management", "Acer eTimer Management", "Acer ePower Management" and "Acer e3D Management respectively. Press " " key to launch the Onscreen display main menu to modify its function. -
Page 29: Onscreen Display (Osd) Menus
• To exit OSD, press "MENU" on the remote control or control panel again. The OSD menu will close and the projector will automatically save the new settings. Main menu Setting Sub menu Downloaded From projector-manual.com Acer Manuals... -
Page 30: Color
Tint Adjusts the color balance of red and green. • Press to increase the amount of green in the image. • Press to increase the amount of red in the image. Downloaded From projector-manual.com Acer Manuals... -
Page 31: Color Mode
Adjusts signal noise reduction."0" means the noise reduction is off, ">0" increase noise reduction. Black Extension This ensures optimum black level for each analog source. Note: "Saturation" and "Tint" functions are not supported under computer or HDMI mode. Downloaded From projector-manual.com Acer Manuals... -
Page 32: Image
Adjusts the sharpness of the image. • Press to decrease the sharpness. • Press to increase the sharpness. H. Position • Press to move the image left. (Horizontal position) • Press to move the image right. Downloaded From projector-manual.com Acer Manuals... - Page 33 Overscan: Always keep overscan on HDMI image. Note: "H. Position", "V. Position", "Frequency" and "Tracking" functions are not supported under HDMI or Video mode. Note: "HDMI Color Range" and "HDMI Scan Info" functions are only supported under HDMI mode. Downloaded From projector-manual.com Acer Manuals...
-
Page 34: Setting
Use this function to select your desired startup screen. If you change the setting, the changes will take effect when you exit the OSD menu. • Acer: The default startup screen of your Acer projector. • User: Use memorize picture from "Screen Capture" function. Screen Capture Use this function to customize the startup screen. - Page 35 • If you select "Always request password while projector turns on.", the user has to enter the password every time when the projector is turned on. Downloaded From projector-manual.com Acer Manuals...
-
Page 36: Management
Activate this function to display a reminder to change the lamp 30 hours before its expected end-of-life. Lamp Hour Reset Press the button and choose "Yes" to turn the lamp hour counter to 0 hours. Downloaded From projector-manual.com Acer Manuals... -
Page 37: Audio
Choose "On" to enable DLP 3D function. • On: Choose this item while using DLP 3D glasses, 120Hz 3D capable graphics cards and HQFS format file or DVD with corresponding SW player. • Off: Turn off 3D mode. Downloaded From projector-manual.com Acer Manuals... - Page 38 - DDD TriDef Media Player (Trial): http://www.tridef.com/download/TriDef-3-D-Experience-4.0.2.html Note: "3D L/R Invert" is only available when 3D is enabled. Note: There has reminder screen if 3D still enable when power on projector. Please adjust setting depended on your purpose. Downloaded From projector-manual.com Acer Manuals...
-
Page 39: Language
Language Language Choose the multilingual OSD menu. Use the to select your preferred menu language. • Press to confirm the selection. Downloaded From projector-manual.com Acer Manuals... -
Page 40: Appendices
Appendices Troubleshooting If you experience a problem with your Acer projector, refer to the following troubleshooting guide. If the problem persists, please contact your local reseller or service center. Image Problems and Solutions Problem Solution No image appears • Connected as described in the "Getting Started"... - Page 41 Set up the display format to 16:9 (wide) aspect ratio on your DVD player. • If you play an Letterbox(LBX) format DVD title, please change the format to Letterbox(LBX) in the projector OSD. Downloaded From projector-manual.com Acer Manuals...
- Page 42 -> Auto Keystone" and choose "Off" on the OSD, if "Keystone" button is not available on the remote control. Image is reversed • Select "Image --> Projection" on the OSD and adjust the projection direction. Downloaded From projector-manual.com Acer Manuals...
-
Page 43: Osd Messages
Projector Overheated - the projector has exceeded its recommended operating temperature and must be allowed to cool down before it may be used. Replace the lamp - the lamp is about to reach its maximum lifetime. Prepare to replace it soon. Downloaded From projector-manual.com Acer Manuals... -
Page 44: Problems With The Projector
If this happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp, follow the procedures in the "Replacing the Lamp" section. Downloaded From projector-manual.com Acer Manuals... -
Page 45: Led & Alarm Definition Listing
Power button ON Lamp retry Quick flashing Turning off Quick (cooling state) flashing Turning off (cooling completed) Error (thermal failure) Error (fan lock failure) Quick flashing Error (lamp breakdown) Error (color Wheel fail) Quick flashing Downloaded From projector-manual.com Acer Manuals... -
Page 46: Cleaning And Replacing The Dust Filters
To clean the dust filters, use a small vacuum cleaner designed for computers and other office equipment. If the dirt is difficult to remove or the filter is broken, please contact your local dealer or service center to obtain a new filter. Downloaded From projector-manual.com Acer Manuals... -
Page 47: Replacing The Lamp
Replacement Suggested!" When you see this message, change the lamp as soon as possible. Make sure the projector has been cooling down for at least 30 minutes before changing the lamp. Warning: The lamp compartment is hot! Allow it to cool down before changing the lamp. Downloaded From projector-manual.com Acer Manuals... - Page 48 To replace the lamp module, reverse the previous step. Warning: To reduce the risk of personal injury, do not drop the lamp module or touch the lamp bulb. The bulb may shatter and cause injury if it is dropped. Downloaded From projector-manual.com Acer Manuals...
-
Page 49: Ceiling Mount Installation
Ceiling Mount Base - Attach to ceiling Short Rod Long Rod Extension Rod Long Cylinder Cap Allen Key Screw Type A - For tightening/loosening 50 mm length / 8 mm diameter - Tightening Screw Medium Rod Downloaded From projector-manual.com Acer Manuals... - Page 50 Use two washers for extra support, if deemed necessary. Attach the ceiling bracket to the ceiling rod. Large cylinder cap Allen Key - For tightening/loosening Screw Type A Tightening Screw 50 mm length/ 8 mm diameter Downloaded From projector-manual.com Acer Manuals...
- Page 51 3 mm diameter screws are enclosed in the screw pack. Models Screw Type B Washer Type Diameter (mm) Length (mm) Large Small H5370BD/E131D/HE-711J 55.00 mm 55.00 mm SCREW SPEC. M3 x 20 mm Downloaded From projector-manual.com Acer Manuals...
-
Page 52: Specifications
Specifications The specifications listed below are subject to change without notice. For final specs, please refer to Acer's published marketing specifications. Projection system ® Resolution Native: 720P (1280 x 720) , Maximum: UXGA (1600 x 1200), WSXGA+ (1680x1050), 1080p(1920x1080), WUXGA-RB (1920 x 1200, RB) - Page 53 AC power cord x1 • VGA cable x1 • Remote control x1 • Batteries x 2 (for remote control) • User's Guide (CD-ROM) x1 • Quick start guide x1 • Security card x 1 • Carrying case x1 Downloaded From projector-manual.com Acer Manuals...
-
Page 54: Compatibility Modes
1280X1024 91.15 QuadVGA 1280x960 60.00 1280x960 75.00 SXGA+ 1400x1050 65.32 UXGA 1600x1200 75.00 Power Mac G4 640x480 31.50 640x480 66.6(67) 35.00 800x600 37.88 1024x768 48.36 1152x870 68.68 1280x960 75.20 i Mac DV (G3) 1024x768 60.30 Downloaded From projector-manual.com Acer Manuals... - Page 55 50(25) 33.75 1080p 1920x1080 67.50 1080p 1920x1080 56.25 B. HDMI Digital HDMI - PC Signal Modes Resolution V.Frequency [Hz] H.Frequency [KHz] 640x480 31.47 640x480 37.86 640x480 37.50 640x480 43.27 640x480 119.51 61.60 SVGA 800x600 35.20 Downloaded From projector-manual.com Acer Manuals...
- Page 56 HDMI - Extended Wide timing Modes Resolution V.Frequency [Hz] H.Frequency [KHz] WXGA 1280x768 47.78 1280x768 60.29 1280x768 68.63 1280x720 44.80 1280x720 119.858 92.89 1280x800 49.60 1366x768 47.71 WXGA+ 1440x900 55.90 WUXGA 1920x1080-RB 66.60 1920x1080-EIA 67.50 1920x1200-RB 59.95 74.04 Downloaded From projector-manual.com Acer Manuals...
- Page 57 1080p (Side by Side (Half)) 1920x1080 56.25 1080p (Side by Side (Half)) 1920x1080 67.5 Horizontal scan rate: 15k-100 kHz Graphic source monitor range limits Vertical scan rate: 24-120 Hz Analog:165 MHz Max. pixel rate: Digital:165 MHz Downloaded From projector-manual.com Acer Manuals...
- Page 58 1080i 1920x1080 50(25) 28.13 1080p 1920x1080 23.97/24 1080p 1920x1080 28.13 1080p 1920x1080 29.97/30 33.75 Horizontal scan rate: 15-50 kHz Graphic source monitor range limits Vertical scan rate: 24-60 Hz Max. pixel rate: Digital: 75 MHz Downloaded From projector-manual.com Acer Manuals...
-
Page 59: Regulations And Safety Notices
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notice: Canadian users This Class B digital apparatus complies with Canadian ICES-003. Downloaded From projector-manual.com Acer Manuals... -
Page 60: Declaration Of Conformity For Eu Countries
Cet appareil numérique de la classe B est conforme a la norme NMB-003 du Canada. Declaration of Conformity for EU countries Acer hereby declares that this projector series is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Compliant with Russian regulatory certification... -
Page 61: Declaration Of Conformity
New Taipei City 221, Taiwan Declaration of Conformity Acer Incorporated 8F, 88, Sec. 1, Xintai 5th Rd., Xizhi, New Taipei City 221, Taiwan Contact Person: Mr. RU Jan, e-mail:ru.jan@acer.com And, Acer Italy s.r.l Via Lepetit, 40, 20020 Lainate (MI) Italy Tel: +39-02-939-921 ,Fax: +39-02 9399-2913 www.acer.it... - Page 62 Downloaded From projector-manual.com Acer Manuals...
