Before Installation and Configuration

1. H685 router has different version. Study your router version before installation.
2. For GSM/GPRS/EDGE/HSDPA/HSUPA/HSPA/HSPA+/4G LTE version, please get a SIM card with data
business.
3. For CDMA2000 EVDO/CDMA1x version, please get a UIM card with data business or inform us before
order if the network uses non-ruim (nam-flashing).
4. Make sure the sim card or uim card is with enough data business and balance.
5. Make sure the signal is good enough where you test or install the router. Weak signal will make the router
no work. If you find your signal strength is not good, please contact us for high gain antenna.
6. Different countries and carriers use different network band and frequency. E-Lins packs units with free
world-wide-use antenna. It can work, but the data speed or signal may not be good at your sites. Please buy
dedicated high gain antenna from your local suppliers or contact E-Lins to OEM/ODM the antenna.
Notes: This quick start is for GSM/GPRS/EDGE/HSDPA/HSUPA/HSPA+/TD-SCDMA network only. For EVDO
network or CDMA network, please refer to manual or contact us freely.
Step 1) Confirm the sim card if can work with other 2G/3G/4G router or modem. If the sim card can not work, the
router will not work correctly.
Step 2) Connect the H685 Router LAN port to a PC via RJ45 cable. Make the PC automatically to get the IP,
Submask, DNS.
The PC will be get a IP of 192.168.8.xxx.

Step 3) At PC IE browser, please type:

Username: admin
Step 4) Internet Settings – WAN – Cell Modem
Notes:
1) If you don't replace any cellular module or not do the "Load Default to factory", please skip this step and jump to
Step 5.
2) Please be patient that the router will take some more time to dialup online for first configuration,
At "Cell Modem", please select "AUTO_DETECT", and click "Apply" button. The router will automatically detect the
module modem.
Notes: we highly suggest that reboot the router (power off and re-power on) after we select "AUTO_DETECT".
Tel: +86‐755‐29230581    E‐mail: sales@e‐lins.com        sales@szelins.com    www.szelins.com

http://192.168.8.1
Password: admin
E‐Lins Technology Co.,Limited
H685 Quick Start


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the h685 and is the answer not in the manual?

Questions and answers

Related Manuals for E-Lins h685

Summary of Contents for E-Lins h685

  • Page 1 Step 1) Confirm the sim card if can work with other 2G/3G/4G router or modem. If the sim card can not work, the router will not work correctly. Step 2) Connect the H685 Router LAN port to a PC via RJ45 cable. Make the PC automatically to get the IP, Submask, DNS.
  • Page 2 H685 Quick Start                                                                                                                    ...
  • Page 3 H685 Quick Start                                                                                                                    ...
  • Page 4 Notes: sometimes the router cannot dialup after the APN configuration, please power off the router, and re-power on it. Because some radio modules need reboot after the initial APN configuration. Step 7) Once H685 router is online, it gets a WAN IP Address and Status Page will show similar info. Step8) Activate the “Cell ICMP Check” feature Notes: 1) For router working with best stability, we highly suggest activate and use this feature.
  • Page 5 H685 Router check “www.google.com” and “112.134.33.8”, it will check 3 times. After the previous check, it will do next check after 60 seconds. Totally it will check 3 times. If 3 times all failed, H685 Router will reboot. If reboots 3 times continuously, H685 Router goes to sleep to stop checking.
