5.3.2.3 DHCP Static

Click DHCP Static in the left pane and the page shown in the following figure appears. You can assign the IP
addresses on the LAN to the specific individual PCs based on their MAC address.
The following table describes the parameters:
Field
IP Address
MAC Address
Add
Delete Selected
Undo
DHCP Static IP Table
5.3.2.4 LAN IPv6
On this page, you can configure the LAN IPv6. Choose Setup > LAN > LAN IPv6. The IPv6 LAN setting
page as shown in the following figure appears.
Figure 5-23 DHCP Static
Description
Enter the specified IP address in the IP pool range, which is assigned to
the host.
Enter the MAC address of a host on the LAN.
After entering the IP address and MAC address, click it. A row will be
added in the DHCP Static IP Table.
Select a row in the DHCP Static IP Table; then click it and this row is
deleted.
Click it to refresh this page.
It shows the assigned IP address based on the MAC address.
