Straight-through Cable
1 2 3 4
1 2 3 4
Crossover Cable
1 2 3 4
1 2 3 4
Please make sure your connected cables are with the same pin assignment and color as the above table
before deploying the cables into your network.
A.3 Fiber Optic Cable Connection Parameter
The wiring details are shown below:
Fiber Optic Patch Cables:
■
Standard
100BASE-FX
(1300nm)
100BASE-FX
(1310nm)
100BASE-BX-U
(TX :1310/RX :1550)
100BASE-BX-D
(TX :1550/RX :1310)
5 6 7 8
SIDE 1
5 6 7 8
SIDE 2
5 6 7 8 SIDE 1
5 6 7 8
SIDE 2
Figure A-1: Straight-through and Crossover Cables
Fiber Type
Multi-mode
Multi-mode
Single-mode
Single-mode
SIDE 1
1 = White / Orange
2 = Orange
3 = White / Green
4 = Blue
5 = White / Blue
6 = Green
7 = White / Brown
8 = Brown
SIDE 1
1 = White / Orange
2 = Orange
3 = White / Green
4 = Blue
5 = White / Blue
6 = Green
7 = White / Brown
8 = Brown
Cable Specification
50/125μm or 62.5/125μm
50/125μm or 62.5/125μm
9/125μm
9/125μm
114
User Manual of FRT-415N
SIDE 2
1 = White / Orange
2 = Orange
3 = White / Green
4 = Blue
5 = White / Blue
6 = Green
7 = White / Brown
8 = Brown
SIDE 2
1 = White / Green
2 = Green
3 = White / Orange
4 = Blue
5 = White / Blue
6 = Orange
7 = White / Brown
8 = Brown
