- Page 2 SBG3600-N Series LTE Multi-WAN Small Business Gateway Version 1.00 Edition 1, 4/2015 Quick Start Guide Default Login Details LAN IP Address http://192.168.1.1 User Name admin Password 1234 Copyright © 2015 ZyXEL Communications Corporation...
- Page 3 Device Panels SBG3600-N LEDS RESET LAN 1-4 ON/OFF WLAN SIM CARD CONSOLE POWER...
- Page 4 SBG3600-NB LEDS RESET LAN 1-4 ON/OFF WLAN SIM CARD CONSOLE POWER...
-
Page 5: Hardware Setup
Requirements Make sure you have the following before you start: • INTERNET ACCESS: You need an Internet account with an ISP (Internet Service Provider) and information such as your user name, password, and so on. • WEB BROWSER: Internet Explorer 8.0 and later versions, with JavaScript enabled, or Mozilla Firefox 3 and later versions, Chrome, or Safari 2.0 and later versions. - Page 6 3. Insert the LTE SIM card. Insert the SIM card before you turn on the Device. To connect the SBG3600-N:...
- Page 7 To connect the SBG3600-NB: 4. Do one or more of the following to connect to the Internet. a. DSL: Use a telephone cable to connect your Device’s DSL port to a telephone jack (or the DSL or modem jack on a splitter if you have one). If your ISP supports DSL bonding, you can connect DSL1 and DSL2 to two separate telephone jacks and enable the bonding feature for increased throughput at longer distances.
- Page 8 b. SFP: If fiber access is available, insert a fiber optic SFP module and connect the fiber optic cable for Internet access. (See Transceiver Installation and Removal on page for more information on SFP module.) c. GbE: If you already have a broadband router or modem, use an Ethernet cable to connect the GbE port to it for Internet access.
-
Page 9: Transceiver Installation And Removal
• The WLAN light flashes green when WLAN is activated. It stays on green when the wireless LAN is ready and blinks when there is traffic. • The LTE Signal light bars indicate the LTE signal quality. The more bars turn on, the higher the signal quality. -
Page 10: Set Up A Wireless Network
Wireless Settings Example SSID: ZyXEL0A561 WPA2-PSK: FB373BD35636BC45 The default wireless settings vary by SBG3600-N Series Device. Use the information on the bottom panel of your Device. The Web Configurator Use the Web Configurator web browser tool to configure the Device. Your computer and the Device need to be in the same IP address range to use it. - Page 11 2. Enter the default user name admin and password 1234. Click Login. If the login screen does not open, make sure you allow web browser pop-up windows, JavaScript and Java permissions. Your computer should be also set to get an IP address automatically from a DHCP server.
- Page 12 4. The Status screen displays, where you can view the Device’s device, interface, and system information.
- Page 13 Network standby power consumption < 12W and, b) Off mode power consumption < 0.5W EU Importer: ZyXEL Communications A/S Generatorvej 8D, 2860 Søborg, Denmark | http://www.zyxel.dk US Importer: ZyXEL Communications, Inc | 1130 North Miller Street Anaheim, CA 92806-2001 | http://www.us.zyxel.com...
- Page 14 Model SBG3600-N000 MANUFACTURED BY AND TCF FILE LOCATED AT Company ZyXEL Communications Corporation Address 1.No. 2, Gongye E. 9th Road, Hsinchu Science Park, Hsinchu, Taiwan, R.O.C. 2.No. 6, Innovation Road II, Hsinchu Science Park, Hsinchu, Taiwan, R.O.C. 3. Generatorvej 8D, 2860 Søborg, Denmark...
