PRE-OPERATION CHECKS การตรวจเช็ ค เครื ่ อ งก่ อ นการใช้ ง าน PEMERIKSAAN PRA-OPERASI KIỂM TRA TRƯỚC KHI VẬN HÀNH ! WARNING Avoid touching the engine and muffler with any part of your body or clothing during inspection or repair, while they are still hot.
Page 9
B • Keep inflammables away from the exhaust outlet. 1 m (3.94 in) เก ็ บ ว ั ต ถ ุ ท ี ่ ต ิ ด ไฟง ่ า ยไว ้ ห ่ า งจากท ่ อ ไอเส ี ย 1 ม. (3.94 in) B •...
Page 10
B 2. Connect the hoses on the joints with band. 3. Connect the strainer on the inlet hose end. NOTE: Should air leak, water could not be drawn up. เช ื ่ อ มต ่ อ ท ่ อ ท ี ่ ส วมเข ้ า ก ั บ ข ้ อ ต ่ อ ด ้ ว ยสายร ั ด B 2.
Page 11
Water 1. Remove priming plug and add water until pump casing is filled up with water. CAUTION: Should the pump be started without water in the casing, mechanical seal could be damaged. น ้ ำ 1. ถอดจ ุ ก ไล ่ อ ากาศออกและเต ิ ม น ้ ำ เข ้ า ไปจนเต ็ ม ห ้ อ งป ั ๊ ม ข...
Page 13
Drain of water after use. Water inside casing freezes at below 0°C (32°F) in winter and there by pump may possibly break. After use, drain water from drain port at bottom to store. ระบายน ้ ำ ออกให ้ ห มดหล ั ง การใช ้ ง าน น...
TROUBLE AND REMEDY Pump does not revolve. Engine does not start (Refer to instruction manual of engine) Sticking of impeller (Disassemble & clean) Entrance of air at suction side (Check piping at suction side) Pumping volume is small. Drop of engine output (Repair) Breakage of mechanical seal (Replace mechanical seal) High suction lift (Lower) Thin or long or kink of hose (Thicken or shorten or straighten)
MASALAH DAN PERBAIKAN Pompa tidak berputar Mesin tidak hidup. (Bacalah petunjuk penggunaan mesin) Kipas menempel. (Bongkar dan bersihkan) Pemasukan udara di sisi hisap (Periksa selang di sisi hisap). Volume pemompaan kecil Output mesin menurun (perbaiki) Sil mekanis rusak (Ganti sil mekanis) Penanjakan hisap terlalu tinggi (Turunkan) Selang terlalu tipis atau panjang atau terpuntir (Tebalkan atau pendekkan atau luruskan).
TROUBLESHOOTING PROCEDURES 1. Remove spark plug, and with its metal part touching the cylinder head, try to Do sparks fly in build sparks in the spark plug. spark plug? 2. If no spark flies between the electrodes of the spark plug, replace it. 3.
2. Jika tidak ada bunga api di antara elektroda pada busi, ganti busi. busi? 3. Jika tetap tidak ada bunga api, periksakan mesin pada toko resmi MAKITA atau service center resmi MAKITA. 1. Periksa kompresi dengan menarik gagang starter perlahan.
SPECIFICATIONS Model EPH1000 Weight 7.5 kg Type Self-priming CENTRIFUGAL PUMP Diameters (suction-discharge) 1 × 1 in Total head 45 m 148 Ft Pump 130 L/min Maximum delivery volume 34 gal/min Maximum suction lift 26 Ft (8 m) Axle seal Mechanical seal...
SPESIFIKASI Model EPH1000 Berat 7,5 kg Jenis POMPA SENTRIFUGAL swa-pancing Diameter (lubang hisap – keluaran) 1 × 1 in Tinggi angkat 45 m 148 Ft Pompa 130 L/ menit Volume pengiriman maksimum 34 gal/ menit Angkat hisap maksimum 26 Ft (8 m)
SAFETY PRECAUTIONS Please make sure you review each precaution carefully. EXHAUST PRECAUTIONS • Never inhale exhaust gasses. They contain carbon monoxide, a colorless, odorless and extremely dangerous gas which can cause unconsciousness or death. • Never operate the engine indoors or in a poorly venblated area, such as tunnel, cave, etc. •...
LANGKAH PENGAMANAN Mohon pastikan Anda telah membaca setiap langkah dengan seksama. PENGAMANAN GAS BUANG • Dilarang menghirup gas buang. Gas buang mengandung karbon monoksida, gas tidak berwarna, tidak berbau dan sangat berbahaya yang dapat menyebabkan kehilangan kesadaran atau kematian. • Dilarang memakai mesin di dalam ruangan atau di daerah berventilasi kurang, misalnya di terowongan, gua, dll.
Page 24
Makita Corporation Anjo, Aichi, Japan www.makita.com 885178-375...
