Congratulations on your purchase of the conrad-johnson Premier One-b
amplifier. You have acquired one of the finest pieces of musical repro-
duction equipment available today. The Premier One-b was designed for
the purpose of providing ourselves and the community of designers of
high-end audio equipment with a reference amplifier. It is the result of 10
man years of research into the application of vacuum tube devices to the
reproduction of recorded music. The design and materials have been
carefully selected to yield years of unvarying excellence.
Please take a few minutes to read this manual so that you will better
understand the features and capabilities of your Premier One-b.
Premier One-b Owner's Manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the One-b and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Conrad-johnson design One-b

Summary of Contents for Conrad-johnson design One-b

  • Page 1 Congratulations on your purchase of the conrad-johnson Premier One-b amplifier. You have acquired one of the finest pieces of musical repro- duction equipment available today. The Premier One-b was designed for the purpose of providing ourselves and the community of designers of high-end audio equipment with a reference amplifier.
  • Page 2 LIMITED WARRANTY FOR THE CONRAD-JOHNSON Premier One-b 1. conrad-johnson design, inc. warrants that the conrad-johnson Pre- mier One-b will be free from defects in material and workmanship for a period of three years from the date of original purchase. 2. conrad-johnson will repair defective units without charge for labor or...
  • Page 3 Proper registration of the warranty is important! It will enable us to inform you of any alterations in the design of a given model and of any new products we offer which are likely to be of interest to you. Premier One-b Owner’s Manual...

  • Page 4: Installation

    The cabinet or shelf should be open at both front and back. For more restricted installations, cooling fans are essential. The front panel of the Premier One-b will fit in a standard 19" equipment rack and is designed to carry the weight of the unit so that it may be rack mounted.
  • Page 5 Only the very best loudspeaker systems will be capable of fully revealing the capabilities of this precision instru- ment. On the other hand, the Premier One-b is ruthlessly revealing. For example, it can render unacceptable faults in the phono system which may be just discernible with an amplifier of lower resolution.

  • Page 6: Absolute Phase

    To complicate matters, our experience suggests that the choice of interconnects will be system dependent - those that are ranked first on a given system may be a poor choice for a different system. Premier One-b Owner’s Manual...

  • Page 7: Tube Replacements

    QUESTIONS? If you have any questions about the installation or function of your Premier One-b do not hesitate to call Customer Service at (703) 698- 8581. TUBE REPLACEMENTS The Premier One-b uses eighteen vacuum tubes of three different types: two 5751 (V1 and V2), two 6FQ7 (V3 through V6) and twelve EL34s (V7 through V18).
  • Page 8 This is normal and no cause for alarm. This biasing procedure should be performed whenever the amplifier’s output tubes are replaced, and after each six months of use. Premier One-b Owner’s Manual...
  • Page 9 FUSE OF DIFFERENT TYPE OR RATING THAN THAT SUPPLIED BY THE FACTORY. PLATE FUSE: Your Premier One-b has been fitted with plate supply fuses which are designed to protect the amplifier circuitry in the event of output tube failure. The fuse holders are physically located near the speaker connectors.

  • Page 10: Specifications

    Small Signal Distortion: Less than .05% at midband Phase: Phase correct (non-inverting) Frequency response: 20Hz to 20KHz +0, -.5dB Hum and noise: 96dB below full power output. Input Impedance: 100K ohms. Dimensions: 22D x 19W x 10.5H inches. Weight: 135 lbs. Premier One-b Owner’s Manual...
  • Page 11 If the problem is intermittent, please indicate. If you do not have the original packing material, replacements are avail- able from conrad-johnson design at a nominal charge. If the unit is under warranty, be sure to enclose a copy of your receipt as proof of purchase.
