Building Networks for Peopl e
Network
Security UTM Firewall
This Quick Guide will guide you through the installation Process. You are
only moments away from using your new D-Link Network Security Product
DFL-260

Advertisement

   Related Manuals for D-Link DFL-260

   Summary of Contents for D-Link DFL-260

  • Page 1

    Building Networks for Peopl e Network Security UTM Firewall This Quick Guide will guide you through the installation Process. You are only moments away from using your new D-Link Network Security Product DFL-260...

  • Page 2: Table Of Contents

    DFL-260 Quick Installation Guide 1.Before You Begin 1.1 Check Your Package Contents..............1 2.Indentifying Components 2.1 Front View....................2 2.2 Rear View....................2 2.3 LED Indicators...................3 2.4 Default Interface Attribute Definition............3 3.Connecting the DFL-260 3.1 Setting up Firewall to your Network............4 4.Configure DFL-260 4.1 Configure your Computer’s IP ..............5...

  • Page 3: Check Your Package Contents

    If any of these items is found damaged or missing in your package, report it to your reseller immediately for replacement. DFL-260 NetDefend™ Network Security UTM Firewall 5V DC Power Adapter Console Cable (RS-232 cable)

  • Page 4: Front View, Rear View

    Identifying Components The following illustrates the front panel of the DFL-260 and explains the front panel’s key components: 2.1 Front View Power indication of the DFL-260. Power LED Status LED System status indication of the DFL-260. 3. WAN LED WAN port status indication of the DFL-260.

  • Page 5: Led Indicators

    DFL-260 Quick Installation Guide 2.3 LED Indicators Status Color Description Power Solid green Green The device is powered on. Light off The device is powered off. Status Solid green Green System is operating properly. Light off The device is not working.

  • Page 6: Connecting The Dfl

    B. Connect an Ethernet cable from the DFL-260 to your Cable/ DSL modem. If the Cable/DSL modem is powered on, wait for the WAN LED on the DFL-260 to light up to show a proper connection. Otherwise, turn off your Cable/DSL modem, connect the Ethernet cable from the DFL-260 to your Cable/DSL modem, and turn on the Cable/DSL modem.

  • Page 7: Configure Dfl

    Configure DFL-260 4.1 Configure Your Computer’s IP Address Make sure that the network adapter in your computer is configured to use a static IP address with 192.168.1.1 as default gateway and 255.255.255.0 as netmask. Instructions on how to configure the network adapter can be found in the appendix.

  • Page 8: Using The Setup Wizard

    IP Address in the web browser, instead of the default IP Address shown.) Log on to the DFL-260 web interface. To start using the DFL-260 web interface you need to log on using the default username and password. Type the default...

  • Page 9

    DFL-260 Quick Installation Guide Step1 - Welcome to the DFL-260 setup wizard! This wizard will guide you through the setup of your DFL-260 Click Next Step2 - Set up firewall administrator password First Enter the username that you want to use for the admin account.

  • Page 10

    DFL-260 Quick Installation Guide Step 3 - Set up time and date Click Set time and date button for setting device Click Next Select the appropriate date Enter the appropriate time Click...

  • Page 11

    DFL-260 Quick Installation Guide Step 4 - Set up timezone Select the appropriate timezone. Enter the appropriate dayligt saving time settings. Next Click Step 5 - Select WAN interface Select the WAN interface that you want to use. Click Next...

  • Page 12

    DFL-260 Quick Installation Guide Step 6 - Configure WAN interface Select the appropriate configuration for the WAN interface, Click Next continue to step 7.1 further down. Note: If you are unsure of which setting to select, please contact your Internet Service Provider.

  • Page 13

    DFL-260 Quick Installation Guide Step 7.2 - WAN Interface Type is PPPoE If you selected PPPoE (Point-to-Point Protocol over Ethernet) you will have to fill out the user name and password provided to you by your ISP. The PPPoE Service...

  • Page 14

    DFL-260 Quick Installation Guide Step 7.4 - WAN Interface Type is Big Pond If you selected Big Pond you will have to fill out the user name and password provided to you by your ISP. Click Next and continue to step 8.

  • Page 15

    DFL-260 Quick Installation Guide Step 9 - Configure helper servers NTP Servers If enabled, specify which NTP Servers that should be used to syncronize the firewall time Syslog Servers If enabled, specify where the firewall should log, you can specify up...

  • Page 16: Microsoft Windows Xp

    Appendix To connect to the DFL-260 Network Security UTM Firewall, make sure the network adapter in your computer is configured properly. Here is how to configure the network adapter manually to the correct IP-address. 5.1 How to configure Static IP Manually on Microsoft Windows XP Go to Start >...

  • Page 17: How To Configure Static Ip Manually On Apple Mac Os X

    DFL-260 Quick Installation Guide Select Use the following IP address Set IP address to 192.168.1.30, Subnet mask to 255.255.255.0 and Default gateway to 192.168.1.1 Click Note: Except for 192.168.1.1, you could set your PC with any IP addresses that same as the 192.168.1.0/ 255.255.255.0 subnet.

  • Page 18

    DFL-260 Quick Installation Guide Select Built-in Ethernet in the show pull down menu Select Manually in the Configure pull down menu Set IP Address to 192.168.1.30, Subnet Mask to 255.255.255.0 and Router to 192.168.1.1. Click on Apply Now...

  • Page 19

    STATEMENT EMI Statement FCC Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 20

    DFL-260 Quick Installation Guide Attenzione! Il presente prodotto appartiene alla classe A. Se utilizzato in ambiente domestico il prodotto può causare interferenze radio, nel cui caso è possibile che l`utente debba assumere provvedimenti adeguati. VCCI Warning VCCI Warning BSMI Warning 警告使用表...
