Propane Gas Patio Heater - 45,000 BTU
USER'S MANUAL
WARNING
Important safety precautions are described in
these instructions! Carefully read and follow
all safety information before assembling and
operating the heater.
THIS APPLIANCE IS APPROVED FOR
OUTDOOR USE ONLY.
BH-BBRZH45
800-779-3267
sales@schaeferfan.com • www.schaeferfan.com
©2008 Schaefer Ventilation Equipment
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schaefer BH-BBRZH45
Summary of Contents for Schaefer BH-BBRZH45
- Page 1 USER'S MANUAL WARNING Important safety precautions are described in these instructions! Carefully read and follow all safety information before assembling and operating the heater. THIS APPLIANCE IS APPROVED FOR OUTDOOR USE ONLY. BH-BBRZH45 800-779-3267 sales@schaeferfan.com • www.schaeferfan.com ©2008 Schaefer Ventilation Equipment...
-
Page 2: Parts Identification
Parts Identification Knob Igniter Wire Plugs into Gas Valve Gas Valve Thermocoupler Anti-Tilt Switch Gas Line Spark Igniter Regulator Hose Burner Connection Head Igniter Thermocoupler Emitter Regulator Hose... - Page 3 Assembly Instructions STEP 1 STEP 2 STEP 3 Attach three vertical supports to Fasten the post to the vertical supports Slide the cylinder cover over the the base using three M8x15 bolts. using six M6x35 bolts and six M6 nuts. post.
-
Page 4: Operation
Assembly Instructions cont'd LEAK TEST Now that the heater is assembled, a leak test should be performed on all connections and hoses to ensure safe operation. 1. MIX IN A SPRAY BOTTLE EQUAL PARTS WATER AND DISH SOAP. Solution can also be mixed in a bowl, and a small brush can be used for application. -
Page 5: Specifications
Safety SPECIFICATIONS This applicance is an infrared portable heater. The burner is controlled and adjusted by the control knob. The gas supply is controlled by the valve on the gas cylinder. The burner is made of stainless steel. Heat diffusion is assisted by the reflector above. Objects placed under a heater while it is operating are subject to radiant heat and may be damaged. -
Page 6: Maintenance
Contact your dealer for replacement parts. Warranty Schaefer Ventilation Equipment, LLC. warrants to the original purchaser that our products which prove to be defective in material or workmanship within one year (unless otherwise specified) from date of purchase will be repaired or replaced at the option of Schaefer Ventilation Equipment, LLC.
