SERVICE MANUAL

TECHNICAL INFORMATION

FOR SERVICE PERSONNEL ONLY
RAM-55QH4
RAM-65QH4
NOTE:
This manual describes only points that differ from RAF-25,
50NH4, RAD-25, 40QH4 and RAM-70, 80QH4 (TC No.
0757EF), RAK-25, 35, 50NH4 (TC No. 0761EF), RAD-25,
40NH4, RAI-25, 40NH4 (TC No. 0763EF) for items not
described in this manual.
TYPE
MODEL
TOTAL INPUT
TOTAL AMPERES
DIMENSIONS
(mm)
NET WEIGHT
SPECIFICATIONS AND PARTS ARE SUBJECT TO CHANGE FOR IMPROVEMENT

ROOM AIR CONDITIONER

JUNE 2004
(W)
(A)
(kW)
(B.T.U.)
W
H
D
(kg)
Refrigeration & Air-Conditioning Division
PM
REFER TO THE FOUNDATION MANUAL

SPECIFICATIONS ------------------------------------------------------------------- 5

Installation ---------------------------------------------------------------------- 14
Construction And Dimensional Diagram ---------------------- 21
Main Parts Component --------------------------------------------------- 23
CAPACITY DIAGRAM ------------------------------------------------------------- 25
Wiring Diagram ----------------------------------------------------------------- 33
Circuit Diagram ---------------------------------------------------------------- 37
Block Diagram ------------------------------------------------------------------ 43
Basic Mode ------------------------------------------------------------------------ 45
REFRIGERATING CYCLE DIAGRAM ---------------------------------------- 73
Description Of Main Circuit Operation ------------------------ 77
Trouble Shooting ---------------------------------------------------------- 108
Disassembly And Reassembly --------------------------------------- 115
Parts List And Diagram ------------------------------------------------- 118
DC INVERTER DUAL SYSTEM MULTI
OUTDOOR UNIT
RAM-55QH4
1ø, 220 - 240V, 50Hz
REFER TO THE SPECIFICATIONS PAGE
850
650
298
50
NO. 0217E
RAM-55QH4
RAM-65QH4
