Instructions for Installation/Set-up, Operation, Servicing, & Storage
Portable, Outdoor Use-Only, Gasoline Generator
6600 Watt Continuous (8000 Watt Surge) Capacity
Can be used to power individual appliances plugged directly into the generator's outlets, or as a
back-up connection to a building's power supply (via a professionally installed UL-approved
transfer switch.
READ and UNDERSTAND this manual completely before using the generator! Failure to properly set up,
operate, and maintain this generator could result in serious injury or death from carbon monoxide poisoning,
electric shock, fire/explosion, or burns. In particular, be aware of the following hazards:
Generators give off carbon monoxide, a poisonous gas that can kill you. You CANNOT smell it, see it, or taste it.
• ONLY run generator OUTDOORS and AWAY from building air intakes. NEVER run generator inside any enclosed or
semi-enclosed spaces, including homes, basements, garages, sheds, boxes, RVs, boats or pick-up truck beds. These
spaces can trap poisonous gases, EVEN if you run a fan or open windows.
• Install carbon monoxide alarms inside nearby structures/buildings (battery-operated, or plug-in with battery backup).
• High voltage electricity from generator can kill. DO NOT operate in wet locations. Be sure generator is properly
grounded. Use only UL-listed, outdoor-rated grounded extension cords of proper size.
• NEVER plug the generator directly into a wall outlet. ANY connection to a building's electrical system MUST
ISOLATE THE GENERATOR FROM UTILITY POWER via a UL-approved transfer switch installed by a licensed
electrician. Otherwise, back feed from the generator into the power grid could kill utility workers.
• DO NOT overload generator (per rated capacity), and OPERATE ONLY in an area with adequate cooling ventilation so
engine does not overheat. Exhaust can be extremely hot. Keep muffler at least 7' from all combustible objects.
• All fuels are flammable. Never fuel a running or hot engine. Never pump fuel directly into generator at gas station – use
approved container to transfer fuel. Ensure there are no fuel leaks, and keep sources of sparks and flames away.
•
ALWAYS keep a fire extinguisher rated "ABC" nearby.
CHOOSE THE RIGHT GENERATOR FOR YOUR NEEDS. See the "Power load Planning & Management" section
of this manual to determine your power load requirements and then compare to the generator's rated capacity.
INSPECT COMPONENTS: Closely inspect to make sure no components are missing or damaged. See the "Unpacking
& Delivery Inspection" section for instructions on whom to contact to report missing or damaged parts.
ARRANGE FOR PROFESSIONAL INSTALLATION of a transfer switch if you will be connecting the generator to
your building's electrical system. See the "Installation/Initial Set-Up" section for more information about this
requirement.
Any Questions, Comments, Problems, or Parts Orders
Owner's Manual
Electric shock / Electrocution
Call NorthStar Product Support 1-800-270-0810
M165957K
ITEM NUMBER: 165957
SERIAL NUMBER: _____________
TM
WARNING
CO Poisoning
Fire / Explosion
STOP!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for North Star M165957K
Summary of Contents for North Star M165957K
- Page 1 ARRANGE FOR PROFESSIONAL INSTALLATION of a transfer switch if you will be connecting the generator to your building’s electrical system. See the “Installation/Initial Set-Up” section for more information about this requirement. Any Questions, Comments, Problems, or Parts Orders Call NorthStar Product Support 1-800-270-0810 M165957K ITEM NUMBER: 165957 SERIAL NUMBER: _____________ WARNING CO Poisoning...
-
Page 2: Hazard Signal Word Definitions
Hazard Signal Word Definitions... -
Page 3: Table Of Contents
Hazard Signal Word Definitions ...2 About Your Generator ...4 Specifications ...6 Safety Label Locations...7 Machine Component Identification ...8 Power Load Planning & Management ...10 Installation / Initial Set-Up: 1. Unpacking & Delivery Inspection...12 2. Planning the Power Load...12 3. Set-up as a PORTABLE or BUILDING BACK-UP Power Source ...13 4. -
Page 4: About Your Generator
Thank you for purchasing your NorthStar portable generator! This engine-driven, portable generator is designed to provide up to 8000 Watts of electrical power (6600 watts continuous, 8000 watts surge). It can supply power: 1. As a portable power source. You can plug appliances directly into the generator’s electrical outlets. -
Page 5: Warranty Registration
About Your Generator (cont’d) NorthStar is constantly improving its products. The specifications outlined herein are subject to change without prior notice or obligation. The purchaser and/or user shall assume liability for any modification and/or alterations of this equipment from original design and manufacture. -
Page 6: Specifications
Specifications – Item #165957K SPECIFICATIONS Item Number Maximum Output Continuous Output Voltage Phase Frequency Power Factor Engine Engine Speed Fuel Type Fuel Capacity Oil Capacity Starting Method 120 V Receptacle 120/240 V Receptacle Circuit Breakers Grounding Post Battery (not included) Dimensions Length Width... -
Page 7: Safety Label Locations
Safety Label Locations – Item #165957K WARNING BURN HAZARD Do not touch hot muffler. ©2005 NT+E 1-800-270-0810 PN 39260 • Commercial-grade electric start engine • Extend run 6.5 gallon fuel tank • Maintenance-free brushless alternator design • Smooth running focus mount isolation system Always make sure safety labels are in place and in good condition. -
Page 8: Machine Component Identification
Machine Component Identification - Item #165957K Figure 1 (Ref. 1-8) Ref. Description Circuit Breakers 120/240V 30A Locking device Receptacle Grounding Post 120V 20A Duplex Receptacle 120V 15A Duplex Receptacle Oil Drain Plug Air Cleaner Super Silent Muffler Figure 2 (Ref. 10-18) 00591 Ref. -
Page 9: Reference Guide
Machine Component Identification - Item #165957K REFERENCE GUIDE Reference 1 – Circuit Breakers Reference 2 – 120/240V Receptacle Reference 3 – Grounding Post Reference 4 – 120V Receptacle Reference 5 – 120V Receptacle Reference 6 – Oil Drain Plug Reference 7 – Air Cleaner Reference 8 –... -
Page 10: Power Load Planning & Management
Power Load Planning & Management NEVER exceed the rated wattage capacity of your generator. OVERLOADING may cause SERIOUS DAMAGE to the generator and attached electrical devices, and may result in fire. Your generator MUST BE SIZED PROPERLY to provide both the running and starting (surge) wattage of the devices you will be powering. - Page 11 Power Load Planning & Management (cont’d) Device Furnace fan (1/3 HP) Freezer Hair dryer Hand drill (1”) Hand drill (1/2”) Hand drill (3/8”) Hand drill (1/4”) Hedge trimmer Home computer Impact wrench (a) Hard-starting motors require 3-5 times the rated running watts (b) For extremely hard to start loads such as air conditioners and air compressors, consult the equipment dealer to determine maximum wattage To calculate the running and starting wattage requirements for the devices you will be...
-
Page 12: Installation / Initial Set-Up
Installation / Initial Set-Up There are a number of important steps required to set up your generator for initial use. These steps are: Steps for Installation / Initial Set-Up 1. Unpacking & delivery inspection. 2. Planning the power load to stay within the generator’s rated capacity. -
Page 13: Set-Up As A Portable Or Building Back-Up Power Source
Installation / Initial Set-Up 3. Set-up either as a BUILDING BACK-UP or PORTABLE Power Source This generator is designed to provide up to 8000W of electrical power. It can supply electricity in two ways: 1. As a back-up, standby power source for a building. For this application, you must arrange for a licensed electrician to connect the generator to your building’s electrical system via the installation of an UL-approved transfer switch. - Page 14 Installation / Initial Set-Up that have been chosen as critical to operate during a power outage. The generator cannot power your entire home -- you must work with the installing electrician to determine which devices/appliances you wish to power during an outage. The electrician can help you determine which circuits and devices can be powered simultaneously without overloading the generator.
- Page 15 Installation / Initial Set-Up ♦ Extension cords may be used to power devices that are located at a distance from the generator. However, use only UL-listed, outdoor-rated, grounded extension cords of the proper size. Use Table 2 below to choose an adequately sized extension cord according to the amperage of the device being used and the length of the cord.
-
Page 16: Selecting A Suitable Site
Installation / Initial Set-Up Before using the generator, you must select a suitable OUTDOOR location for installation and operation. This location should meet all of the criteria listed below. WARNING: You must choose a suitable site for operating your generator to avoid equipment damage and/or injury and possible death from carbon monoxide poisoning, electric shock, or fire. - Page 17 Installation / Initial Set-Up • Situate so there is adequate clearance around generator to allow for cooling airflow so that heat does not build up. • Never place the generator immediately adjacent to a building or other structure – allow at least a 7’ clearance. •...
-
Page 18: Grounding The Generator
Installation / Initial Set-Up Always ensure the generator is properly grounded to prevent electrical shock. You must always ground the generator by the following method when using the generator as a portable electrical source: 1) Drive a ¾” or 1” copper pipe or rod into the ground close to the generator. The pipe/rod must penetrate moist earth –... -
Page 19: Battery Installation
Installation / Initial Set-Up Your generator’s engine is equipped with an electric starter which requires the installation of a 12- volt lawn tractor size battery (Group U1). See the “Specifications” section of this manual for more specific battery requirements for this generator model, such as minimum amperage or CCA rating. The battery is to be supplied by the customer and should be installed in the protective battery box located near the engine. -
Page 20: Operation
Once you have set up your generator for use, it is time to start your generator. The following are the procedures necessary for safe, successful operation of your generator. 1. General Safety Rules for Operation 2. Preparing for Operation 3. Starting the Engine 4. - Page 21 • Malfunction during operation. Immediately turn off the generator if any of the following conditions arise during operation: o Excessive change in engine speed, slow or fast o Overheating in load connecting devices o Sparking or arcs from generator o Loss of electrical output o Receptacle damage o Engine misfire o Excessive vibration...
- Page 22 Static electricity and filling the gasoline tank: Static electricity can initiate from ungrounded gasoline tanks or containers, from flowing gasoline, and from persons carrying a static electric charge Static electricity can explosively ignite gasoline vapors that are present during the fueling process, resulting in serious burns to nearby persons.
-
Page 23: Preparing For Operation
Position Position generator in accordance with the instructions given in generator “Installation & Initial Set-up, Step 4: Select a Suitable Site” manual. Operate outside only, on dry, level ground with adequate clearance and ventilation. WARNING: Carbon monoxide poisoning hazard Generators give off carbon monoxide exhaust, a poisonous gas that can kill. - Page 24 Operation (cont’d) WARNING : Gasoline fire/explosion hazard Gasoline is highly flammable and explosive. Heat, sparks, and flames can ignite gasoline vapors, which can become widespread during fueling. A flash fire and/or explosion could result and cause serious injury or death. Use extreme care when handling gasoline. Carefully follow all the instructions in this section to avoid the following conditions which could result in gasoline ignition: •...
- Page 25 ground to be filled. • Keep nozzle in contact with portable container while filling. Manually control the flow of gasoline; do NOT use the nozzle’s lock-open device. • A portable container made of metal or conductive plastic is preferred because it dissipates charge to ground more readily. 5) Clean up gasoline spills /splashes immediately.
-
Page 26: Starting The Engine
After you have completed the pre-start checklist procedures, you are ready to start the engine. To start the engine: 1) Disconnect all loads to the generator. 2) Turn the gasoline line valve to the ON position. 3) For cold engine, move choke lever to full choke position. To restart a warm engine, move choke lever to half choke or to RUN position. -
Page 27: Checking Generator Output
Although the speed of the engine was carefully adjusted at the factory so that the generator produces the proper voltage and frequency, output voltage should be checked periodically to ensure the generator is working properly before connecting loads to the generator. WARNING : The generator must be run at the correct speed in order to produce the proper electrical voltage and frequency. -
Page 28: Connecting Loads
You will want to be careful when connecting loads so as not to overload the generator, especially if you are powering devices with motors that require a higher starting power load. Instructions are provided below for connecting loads when you are using the generator: o As a portable power source o Connected to a building as a back-up power source WARNING :... -
Page 29: Storage & Exercise
When you are finished using the generator, you must: o Disconnect all loads o Shut off fuel supply o Store the generator properly o Plan on exercising the engine regularly unless the generator is prepared for long-term storage. Detailed instructions are provided below. Disconnect loads &... - Page 30 Prepare engine for If you will not be able to exercise the generator regularly, you must long term storage if prepare the engine for long term storage to prevent gum deposits from needed forming and causing malfunction of the engine. Prepare engine for long term storage by: o Removing all gasoline from the tank and carburetor o Adding fuel stabilizer to the gasoline (following manufacturer’s...
-
Page 31: Maintenance & Repair
Inspect and maintain your generator as specified below in order to keep it in safe and optimal working order. Follow all safety rules and recommended maintenance steps. ALWAYS shut off the engine, disconnect the spark plug(s) and discharge the capacitor before cleaning, adjusting, or servicing the generator. - Page 32 Maintenance & Repair (cont’d) Check GFCI Once a month, test the Ground Fault Circuit Interrupter (GFCI) to (if equipped) protect against electrical shock due to failure of the GFCI. (Only for those models equipped with GFCI – See the “Specifications” section.) To test the GFCI: 1.
-
Page 33: Troubleshooting
Problem Possible Causes Engine will not start. a) Low oil level. b) Fouled spark plug. c) Out of fuel. d) Stop switch in OFF position. e) Battery is not charged. Voltage too low. a) Engine speed too slow. b) Generator is overloaded. Circuit breaker trips. -
Page 34: Summary Of Important Safety Information For Operation
Summary of Important Safety Information for Operation This section provides a summary of the various safety procedures and measures that have been presented throughout the manual. Keep this summary handy and refer to it to refresh your memory about how to safely use your generator. Carefully read and make sure you understand the following safety information before using the generator. - Page 35 Summary of Important Safety Information for Operation (cont’d) Installation / Initial Set-up Safety • Dry, level surface. Situate generator on a dry, firm, level surface. Ensure generator sits level and will not slide or shift during operation. Block wheels if applicable. •...
-
Page 36: Safety - During Use
Summary of Important Safety Information for Operation (cont’d) Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. Use extreme care when handling: • Fuel outdoors. Fill fuel tank outdoors – never indoors. Gasoline vapors can ignite if they collect inside an enclosure. - Page 37 Summary of Important Safety Information for Operation (cont’d) • Avoid contact. Avoid contact with bare wires, terminals, connections, etc. while the unit is running. • Electric shock accident. If an electric shock accident occurs, immediately shut down the source of electrical power.
-
Page 38: Generator Exploded View
Generator Exploded View Rev - K... - Page 39 Generator Exploded View Rev - K Ref # Part # Description 38759 Fuel Tank Assembly 33321 Fuel Cap 777352 Battery Box 30754 Leather Washer 779422 Decal 777834 Hose Clamp 779423 Warning Decal 32833 Roll Cage 39260 Hot Muffler Sticker 31335 Honda GX390 Engine, 13 HP 778530A Generator Head...
-
Page 40: Wiring Diagram
Wiring Diagram Rev - K Diag # Part # Description 306438 15 Amp, 120 Volt Receptacle (NEMA 5-15R) 31736 20 Amp, 120 Volt Receptacle (NEMA 5-20R) 306422 30 Amp, 120/240 Volt Locking Receptacle (NEMA L14-30R) 306429 Grounding Post 306433 Thermal Circuit Breaker, 15 Amp 38191 Wiring Harness (Connects generator to Control Panel) -
Page 41: Generator Head Exploded View
Generator Head Exploded View Rev - K Item # Part # Description 38266 Mount Plate (J609B) 38267 Fan Bolts 38268 38269 Drive End Bracket 38270 Enclosing Band 777304 End Cover 38271 End Cover Plug 38272 Stator 38273 Rotor 307479 Diode 38275 Securing Stud 38276...
