Devilink™ System Overview
When using Devilink™ PR as heating regulation you also have
to install a Devilink™ RS, which allows you to control the
heating based on room temperature, in the specific room
where installed. With the Devilink™ RS you can also adjust the
temperature.
Devilink™ PR is to be put in to a socket/outlet together with a
SCHUCKO plug.
Devilink™ HR (Hidden relay) is a device supporting two types
of operation modes, either for controlling heating element or
other electrical equipments ON/OFF manually or by schedule.
When using Devilink™ HR as heating regulation you also
have to install a Devilink™ RS, which allows you to control
the heating based on room temperature, in the specific room
where installed. With the Devilink™ RS you can also adjust the
temperature.
Devilink™ HR is to be mounted in to a build in box in the wall.
Devilink™ FT (Floor Thermostat) or FTS (FT with sensor)
is one device supporting 3 types of operation modes, for
controlling of heating elements or other electrical equipments
ON/OFF manually or by schedule.
By controlling of floor heating DEVI always recommends
installing of a floor sensor.
Comfort heating – where a comfortable warm surface of the floor is
required you have only to connect a floor sensor to the Devilink™ FT as
heating regulation.
By Total heating you have to connect a floor sensor to the Devilink™ FT and
combined the installation with a Devilink™ RS, which allows you to control
the heat through both air and floor measurements. Devilink™ FT is to be
mounted in to a build in box in the wall or external box on the Wall.
3
