System Overview; Table Of Contents - Devilink CC Installation Manual

Index / Devilink™System Overview
Devilink™ System Overview ...................................................................................
1.0 Placement of Devilink™ CC ...........................................................................
2.0 Mounting of Devilink™ CC .............................................................................
3.0 Configuration of Devilink™ ..........................................................................
4.0 Modifying an exiting Installation ................................................................
5.0 Troubleshooting ...............................................................................................
6.0 Technical specifications .................................................................................
Devi Warranty ..............................................................................................................
Devilink™ is a wireless control system for electrical floor heating.
The central brain in the system is the Devilink™ CC (Central
Controller) equipped with a colour touch screen. From this
you can control the entire installation. The Devilink™ CC
communicates wirelessly with all other Devilink™ devices in
the installation.
If you want to operate on room temperature you have the option
of installing a Devilink™ RS (Room Sensor). This has a built-in
room sensor and thus measures the ambient temperature. You
can also adjust the temperature with Devilink™ RS
The Devilink™ RS (Room Sensor) has a built-in temperature
sensor which measures the ambient temperature. It allows
you to control the heating based on room temperature, in the
specific room where installed. With the Devilink™ RS you can also
adjust the temperature.
Devilink™ PR (Plug in relay) is a device supporting two types of
operation modes, either for controlling heating element or other
electrical equipments ON/OFF manually or by schedule.
