  • Page 1 MOZART INSTRUCTIONS FOR USING, MAINTAINING AND INSTALLING THE HOOD...
  • Page 2 INSTRUCTIONS FOR USE, MAINTENANCE AND INSTALLATION FOR THE DOWNDFRAFT. ATTENTION: The downdraft must only be installed from a qualified technician. Every responsibility regarding installations from unauthorized persons will be declined. Before proceeding with the downdraft installation, please read carefully these instructions. Keep this booklet together with the downdraft.
  • Page 3 When the filtering function is operating, with air recycle, carbon filters must be used. When the downdraft is used in the filtering function, there must be a suitable section for spillage of the air suction on the base of the kitchen. When the suction function is operating, exhausting the filtered air on the outside, a suitable compensation system must be used according to current standards in force.
  • Page 4 It is possible to connect on the front or on the back part of the downdraft a tube of diameter 150. It is possible to connect on the side of the downdraft a tube 220x90 or 230x80 on both sides. Fig.
  • Page 5 ELECTRIC WIRING Safety Instructions:  Before any manipulation of the controller power cord (230 volt)  Before each operation, all devices connected  Electrical connections must be performed by professionals 1 - External motor connector 2 - Power supply 230V 3 - Cable with faston for microswich hood 4 - Remote control antenna cable...
  • Page 6 MOZART CONTROL FUNCTIONS PLEASE NOTE : THE SUCTION OF THE DOWNDRAFT CAN BE STARTED ONLY WHEN THE DOWNDRFT IS COMPLETLY EXTRACTED. BUTTON “A” With suction motor turned on, every time the button is pressed the motor speed will be reduced of one step.
  • Page 7 take the cover out from the downdraft and open the cover lifting it upwards. (Fig.A) The metal filters can be removed using the special handle unhooking first the filter in the front part and pulling up. (Fig.B) Fig. B Fig. A After washing the filters, they must be thoroughly dried and reassembled correctly.
  • Page 8 Airone S.r.l. - Via Ghebo, 12 - 35017 Piombino Dese (PD) Italy tel +39.049.9369333 fax +39.049.9369399 www.aironehoods.com...
