SERVICE MANUAL
7
2005
MA188
TE
L 13942296513
1
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-25
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-26
www
.
CD RECEIVER
KD-G269
ATT
SOUND
U
F
R
SOURCE
D
VOL
VOL
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)

TABLE OF CONTENTS

x
ao
y
i
COPYRIGHT © 2005 Victor Company of Japan, Limited
http://www.xiaoyu163.com
8
Q Q
3
6 7
1 3
u163
.
2 9
9 4
2 8
Area suffix
UR -------------------------- Brazil
KD-G269UR
1 5
0 5
8
2 9
9 4
m
co
9 9
2 8
9 9
No.MA188
2005/7

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-G269

Summary of Contents for JVC KD-G269

  • Page 1: Table Of Contents

    3 7 63 1515 0 SERVICE MANUAL CD RECEIVER MA188 2005 KD-G269 Area suffix UR -------------------------- Brazil SOUND KD-G269UR SOURCE L 13942296513 Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) TABLE OF CONTENTS PRECAUTIONS .

  • Page 2: Http://Www.xiaoyu163.Com

    http://www.xiaoyu163.com 3 7 63 1515 0 SPECIFICATION AUDIO AMPLIFIER SECTION 18 W RMS × 4 Channels at 4 Ω and -1% THD+N Power Output 80 dBA (reference: 1 W into 4 Ω) Signal to Noise Ratio 4 Ω (4 Ω to 8 Ω allowance) Load Impedance Tone Control Range Bass...

  • Page 3: Precautions

    http://www.xiaoyu163.com SECTION 1 3 7 63 1515 0 PRECAUTIONS Safety Precautions Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
  • Page 4 http://www.xiaoyu163.com Preventing static electricity 3 7 63 1515 0 Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.2.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
  • Page 5 http://www.xiaoyu163.com Important for laser products 3 7 63 1515 0 5.CAUTION : If safety switches malfunction, the laser is able 1.CLASS 1 LASER PRODUCT to function. 2.DANGER : Invisible laser radiation when open and inter 6.CAUTION : Use of controls, adjustments or performance of lock failed or defeated.

  • Page 6: Specific Service Instructions

    http://www.xiaoyu163.com SECTION 2 3 7 63 1515 0 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. L 13942296513 u163 1-6 (No.MA188) http://www.xiaoyu163.com...

  • Page 7: Disassembly

    http://www.xiaoyu163.com SECTION 3 3 7 63 1515 0 DISASSEMBLY Main body 3.1.1 Removing the front panel assembly (See Fig.1) Push the detach button in the lower right part of the front panel assembly and remove the front panel assembly. Front panel assembly Detach button Fig.1 3.1.2 Removing the bottom cover...
  • Page 8 http://www.xiaoyu163.com 3.1.4 Removing the heat sink 3 7 63 1515 0 (See Fig.4) • Remove the front panel assembly as required. From the left side of the main body, remove the screw B and two screws C attaching the heat sink. Heat sink Fig.4 3.1.5 Removing the rear bracket...
  • Page 9 http://www.xiaoyu163.com 3.1.7 Removing the CD mechanism assembly 3 7 63 1515 0 (See Fig. 7) • Remove the front panel assembly, bottom cover, front chassis assembly, heat sink, rear bracket and main board. Remove the three screws H and take out the CD mechanism as- sembly from the top chassis.
  • Page 10 http://www.xiaoyu163.com CD Mechanism Assembly 3 7 63 1515 0 3.2.1 Removing the top cover (See Figs.1 and 2) (1) Remove the two screws A on the both side of the body. (2) Lift the front side of the top cover and move the top cover backward to release the two joints a.

  • Page 11: No.ma188)1

    http://www.xiaoyu163.com 3.2.2 Removing the connector board 3 7 63 1515 0 Wires (See Figs.3 to 5) CAUTION: Before disconnecting the flexible wire from the pickup, solder the short-circuit point on the pickup. No observance of this in- struction may cause damage of the pickup. (1) Remove the screw B fixing the connector board.
  • Page 12 http://www.xiaoyu163.com 3.2.3 Removing the DET switch 3 7 63 1515 0 (See Figs.6 and 7) (1) Extend the two tabs c of the feed sw. holder and pull out the switch. (2) Unsolder the DET switch wire if necessary. DET switch Connector board Pickup...
  • Page 13 http://www.xiaoyu163.com 3.2.4 Removing the chassis unit 3 7 63 1515 0 (See Figs.8 and 9) • Prior to performing the following procedure, remove the top Chassis unit cover and connector board. Suspension spring (L) Suspension spring (R) (1) Remove the two suspension springs (L) and (R) attaching the chassis unit to the frame.
  • Page 14 http://www.xiaoyu163.com 3.2.5 Removing the clamper assembly 3 7 63 1515 0 (See Figs.10 and 11) • Prior to performing the following procedure, remove the top cover. (1) Remove the clamper arm spring. Clamper arm (2) Move the clamper assembly in the direction of the arrow to spring release the two joints d.
  • Page 15 http://www.xiaoyu163.com 3.2.6 Removing the loading / feed motor assembly 3 7 63 1515 0 (See Figs.12 and 13) • Prior to performing the following procedure, remove the top cover, connector board and chassis unit. (1) Remove the screw C and move the loading / feed motor assembly in the direction of the arrow to remove it from the chassis rivet assembly.
  • Page 16 http://www.xiaoyu163.com 3.2.7 Removing the pickup unit 3 7 63 1515 0 Pickup unit (See Figs.14 to 18) • Prior to performing the following procedure, remove the top cover, connector board and chassis unit. (1) Remove the screw D and pull out the pu. shaft holder from the pu.
  • Page 17 http://www.xiaoyu163.com 3.2.9 Removing the trigger arm 3 7 63 1515 0 Joint k (See Figs.19 and 20) • Prior to performing the following procedure, remove the top cover, connector board and clamper unit. (1) Turn the trigger arm in the direction of the arrow to release Trigger arm the joint k and pull out upward.
  • Page 18 http://www.xiaoyu163.com 3.2.11 Removing the mode sw. / select lock arm 3 7 63 1515 0 Link plate Joint t (See Figs.22 and 23) Mode sw. • Prior to performing the following procedure, remove the top plate assembly. Select lock arm (1) Bring up the mode sw.
  • Page 19 http://www.xiaoyu163.com 3.2.12 Reassembling the mode sw. / select lock arm 3 7 63 1515 0 Select lock arm spring (See Figs.24 to 26) REFERENCE: Hook w Reverse the above removing procedure. Joint v (1) Reattach the select lock arm spring to the top plate and set Joint v the shorter end of the select lock arm spring to the hook w on the top plate.
  • Page 20 http://www.xiaoyu163.com 3.2.13 Removing the select arm R / link plate 3 7 63 1515 0 Joint c' Link plate Joint r (See Figs.27 and 28) Select arm R Joint b' • Prior to performing the following procedure, remove the top plate assembly.
  • Page 21 http://www.xiaoyu163.com 3.2.15 Removing the loading roller assembly 3 7 63 1515 0 (See Figs.31 to 33) Loading roller assembly • Prior to performing the following procedure, remove the Roller guide clamper assembly and top plate assembly. spring (1) Push inward the loading roller assembly on the gear side and detach it upward from the slot of the joint g' of the lock arm rivet assembly.
  • Page 22 http://www.xiaoyu163.com 3.2.16 Removing the loading gear 5, 6 and 7 3 7 63 1515 0 Loading gear bracket (See Figs.35 and 36) • Prior to performing the following procedure, remove the top Loading gear 6 cover, chassis unit, pickup unit and top plate assembly. (1) Remove the screw K attaching the loading gear bracket.
  • Page 23 http://www.xiaoyu163.com 3.2.17 Removing the gears 3 7 63 1515 0 Joint p' (See Figs.37 to 40) • Prior to performing the following procedure, remove the top Change plate cover, chassis unit, top plate assembly and pickup unit. rivet assembly • Pull out the loading gear 3. (See Fig.35.) (1) Pull out the feed gear.
  • Page 24 http://www.xiaoyu163.com 3.2.18 Removing the turn table / spindle motor 3 7 63 1515 0 Turn table (See Figs.41 and 42) • Prior to performing the following procedure, remove the top cover, connector board, chassis unit and clamper assembly. (1) Remove the two screws L attaching the spindle motor as- sembly through the slot of the turn table on top of the body.

  • Page 25: Adjustment

    (3) Digital tester Output Level Line out 2.0V (Vol. MAX) (4) Tracking offset meter (5) Test Disc JVC :CTS-1000 Dummy load (6) Extension cable for check Exclusive dummy load should be used for AM,and FM. For FM EXTSH002-22P × 1 dummy load,there is a loss of 6dB between SSG output and antenna input.The loss of 6dB need not be considered since...

  • Page 26: Troubleshooting

    http://www.xiaoyu163.com SECTION 5 3 7 63 1515 0 TROUBLESHOOTING Feed section Is the voltage output at Is the wiring for IC561 Is 5V present at IC541 Check CD 8V. IC561 pin 22 5v or 0V pin 22 correct? pin 27? Check the vicinity of IC561.
  • Page 27 http://www.xiaoyu163.com Signal processing section 3 7 63 1515 0 No sound from either Is the sound output from Compare the L-ch and channel. both channels (L, R)? R-ch to locate the defective point. Normal Is 9V present at IC301 pin Check the vicinity of the Q321 audio power supply.
  • Page 28 http://www.xiaoyu163.com Maintenance of laser pickup 3 7 63 1515 0 Replacement of laser pickup (1) Cleaning the pick up lens Before you replace the pick up, please try to clean the lens Turn off the power switch and, disconnect the with a alcohol soaked cotton swab.
  • Page 29 http://www.xiaoyu163.com 16 PIN CORD DIAGRAM 3 7 63 1515 0 Black Green Violet Blue Gray BL/WH White Yellow WH/BK GN/BK VI/BK GY/BK BL/WH 7 RD RD 7 16 YL MEMORY YL 4 8 BK REMOTE 5 BL/WH 3 GN 11 GN/BK L 13942296513 2 VI 10 VI/BK...
  • Page 30 http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY CAR ELECTRONICS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.MA188) Printed in Japan http://www.xiaoyu163.com...
  • Page 31 3 7 63 1515 0 SCHEMATIC DIAGRAMS CD RECEIVER KD-G269 CD-ROM No.SML200507 Area suffix UR -------------------------- Brazil L 13942296513 SOUND KD-G269UR SOURCE Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) Contents Block diagram...

  • Page 32: Safety Precaution

    http://www.xiaoyu163.com 3 7 63 1515 0 Safety precaution Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system. Please use enough caution not to see the beam directly or touch it in case of an adjustment or operation check.
  • Page 33 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Block diagram CJ701 AM ANT TU.LCH FM ANT TU701 TU.RCH FM/AM CJ321 TUNER LINE OUT REAR L SW1,SW2,PSW MUTE REAR R Q332,432 Q861 MICON MUTE SD/ST MUTING LINE OUT MONO CD.RESET,STATUS POSITION SET TRD,FOD...
  • Page 34 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 Standard schematic diagrams Main amp section TU701 QAU0394-002 CJ701 QNB0190-001 L701 4.7u R201 2.2k R703 R101 2.2k R701 Q791 2SB624/4/-X R735 Q861 1.5k R791 Q792 UN2111-X 2SB709A/QR/-x C731 R736 R733 R333 R334 MUTE...
  • Page 35 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 CD section C541 C545 47/6.3 0.01 C543 0.033 C540 R558 Q541 2SA2093/QR/-T D551 1A3G-T1 IC561 MN6627482WA CD8V CD.RESET STATUS SUBQ SQCK TLOCK FLOCK CD.SENSE R151 C152 KICK MDATA 2.2/50 MCLK R560 C546 BLKCK...
  • Page 36 http://www.xiaoyu163.com 3 7 6 3 1 5 1 5 0 LCD & Key control section JS686 IC681 QSW0793-001 RPM7338-V4 C682 0.012 R687 C681 4.7/6.3 R688 C687 0.022 R681 CJ601 QGZ1601K1-15S LCD1 ILL_10V REMOCON ENC1 ENC2 DIMOUT LCD.SCK LCD.SO LCD.CE KEY0 KEY1 KEY2 1 3 9 4 2 2 9 6 5 1 3...
  • Page 37 http://www.xiaoyu163.com 3 7 63 1515 0 Printed circuit boards Main board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) D904 C915 C901 R911 R903 R434 IC901 C914 D869 C906 C861 D867 R862 R861 C996 B366 R904...
  • Page 38 http://www.xiaoyu163.com 3 7 63 1515 0 Switch board Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) (Forward side) (Reverse side) R630 D630 D631 S606 IC681 Q670 Q671 R671 R646 C681 D652 C682 R645 D653 R670 R647...
  • Page 39 http://www.xiaoyu163.com 3 7 63 1515 0 < M E M O > L 13942296513 u163 http://www.xiaoyu163.com...
  • Page 40 http://www.xiaoyu163.com 3 7 63 1515 0 L 13942296513 u163 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY CAR ELECTRONICS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan Printed in Japan (No.MA188SCH) http://www.xiaoyu163.com...

  • Page 41: Parts List

    3 7 63 1515 0 PARTS LIST [ KD-G269 ] * All printed circuit boards and its assemblies are not available as service parts. Area suffix L 13942296513 UR -------------------------- Brazil - Contents - 3- 2 Exploded view of general assembly and parts list (Block No.M1) 3- 5 CD mechanism assembly and parts list (Block No.MB)
  • Page 42 http://www.xiaoyu163.com 3 7 63 1515 0 Exploded view of general assembly and parts list Block No. L 13942296513 Switch board u163 The part http://www.xiaoyu163.com...
  • Page 43 http://www.xiaoyu163.com 3 7 63 1515 0 Block No. Main board L 13942296513 Switch board u163 The parts without symbol number are not service. http://www.xiaoyu163.com...
  • Page 44 http://www.xiaoyu163.com 3 7 63 1515 0 General Assembly Block No. [M][1][M][M] Symbol No. Part No. Part Name Description Local  GE10043-210A TOP CHASSIS GE40135-001A EARTH PLATE GE30938-003A HEAT SINK QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3) GE40235-001A SCREW (x2) QYSDST2604ZA TAP SCREW M2.6 x 4mm(x3) GE40235-004A SCREW...
  • Page 45 http://www.xiaoyu163.com 3 7 63 1515 0 CD mechanism assembly and parts list Block No. Grease TN-2001-1011 TNG-87 GP-501MK CFD-005Z GP-305T L 13942296513 u163 The parts without symbol number are not service. http://www.xiaoyu163.com...
  • Page 46 http://www.xiaoyu163.com 3 7 63 1515 0 CD mechanism Block No. [M][B][M][M] Symbol No. Part No. Part Name Description Local  30320101T FRAME 30320102T TOP COVER 30320115T DANPER F 30320116T DANPER R 303205505T CHASSIS RIVET 303205503T CHANGE P. RVT A 303205301T CLAMPER ASS'Y 303205302T SPINDLE MOTOR A...
  • Page 47 http://www.xiaoyu163.com 3 7 63 1515 0 Electrical parts list Main board  Symbol No. Part No. Part Name Description Local Block No. [0][1] C310 NCB31HK-103X C CAPACITOR 0.01uF 50V K  Symbol No. Part No. Part Name Description Local C311 QEKJ1AM-107Z E CAPACITOR 100uF 10V M...
  • Page 48 http://www.xiaoyu163.com 3 7 63 1515 0  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local C573 QERF1AM-227Z E CAPACITOR 220uF 10V M R401 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J C574 NCB31EK-103X C CAPACITOR 0.01uF 25V K R402...
  • Page 49 http://www.xiaoyu163.com 3 7 63 1515 0  Symbol No. Part No. Part Name Description Local  Symbol No. Part No. Part Name Description Local R801 NRS181J-103X MG RESISTOR 10kΩ 1/8W J Q670 2SB624/4/-X TRANSISTOR R803 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J Q671 UN2211-X TRANSISTOR...
  • Page 50 http://www.xiaoyu163.com 3 7 63 1515 0  Symbol No. Part No. Part Name Description Local R686 NRSA63J-101X MG RESISTOR 100Ω 1/16W J R687 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J R688 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J CJ601 QGZ1601K1-15S CONNECTOR (1-15) JS686 QSW0793-001 ROTARY ENCODER...
  • Page 51 http://www.xiaoyu163.com 3 7 63 1515 0 <MEMO> L 13942296513 u163 3-11 http://www.xiaoyu163.com...
  • Page 52 http://www.xiaoyu163.com 3 7 63 1515 0 Packing materials and accessories parts list Block No. No additional / supplemental order of WARRANTY CARDs are available. A10 A11 A12 A13 A14 A15 A16 A17 L 13942296513 KIT: A1 A2 A3 A4 A5 u163 3-12 http://www.xiaoyu163.com...
  • Page 53 http://www.xiaoyu163.com 3 7 63 1515 0 Packing and Accessories Block No. [M][3][M][M] Symbol No. Part No. Part Name Description Local  VKZ4027-202 PLUG NUT VKH4871-003 MOUNT BOLT VKZ4328-003 LOCK NUT QYWWS53A008ZA WASHER 0mm/5.3mm x GE40130-002A HOOK (x2) QAM0089-003 16P CORD ASSY FSJB3002-00E HARD CASE GE20137-003A...
