Setup parameters

HOME Display

Program Selection & Edit
10 SL88 Grand by Studiologic®
The SL main page (HOME) is a very clear and complete pic-
ture of the main functions, as it follows:
Program
(i.e. 001 NAME)
the selected Program

P001 SL 88 GRAND

GROUP SAGA SETUP

INSTRUMENT
SOUND
VOL 122
INSTRUMENT
SOUND
VOL 101
ZONES (color coded)
active Zones and main parameters
(Volume, Keyboard range)
By rotating the encoder,
when a ZONE is selected, you
can immediately control the
Volume (000-127).
To select a Program, you can either rotate the Encoder (direct
selection) or Click the Encoder, rotate to select and Click to
confirm.
When a Program is selected (by moving the cursor to the top
area of the display) pressing IN you enter in Program Edit.
P001 SL 88 GRAND
STORE UNDER:
NAME:
ZONE EDIT:
MERGE SOURCE:
MERGE DEST.:
MERGE FILTER:
The following parameters are avaible:
STORE UNDER
To select the position where
you want to store the current
Program.
GROUP
the related GROUP of the selected program
(-------- if no GROUPS are selected)
1 INSTRUMENT 2
SOUND
A0 / F#2 VOL 096 G3 / Db4
3 INSTRUMENT 4
SOUND
B7 / C8 VOL 124 A0 / F#2
P001 SL 88 GRAND
GROUP SAGA SETUP
INSTRUMENT 1
SOUND
VOL 122 A0 / F#2
INSTRUMENT 3
97
SOUND
VOL 101 B7 / C8
P001
SL 88 GRAND
1 2 3 4
OFF
USB OUT
SYS OFF - ALL
INSTRUMENT 2
SOUND
VOL 096 G3 / Db4
INSTRUMENT 4
SOUND
VOL 124 A0 / F#2
