Defining a Scan Area (Cropping Frame)

You can select or deselect scan frames (cropping areas) for images displayed in the preview area.
Selecting the cropping area automatically
Defining a cropping frame
Defining multiple cropping frames
Deleting cropping frames
Selecting the cropping area automatically
1
Display the preview.
2
Click [ ] (Auto Crop) on the toolbar.
Every time this button is clicked, the selected cropping frame becomes smaller.
Defining a cropping frame
1
Display the image in the preview area.
2
Click [ ] (Crop) on the toolbar.
3
Click on the preview image and drag around the contours/border of the area you want to select.
To adjust the selected area
Drag around the contours/border of the area or manually enter the width and height for [Input Settings] in the
[Advanced Mode] tab.
To move the scan area
Click the inside rim of the scan area and drag it.
NOTE
To maintain height-width proportions of the original image
Click [ ] in [Input Settings].
When scanning from the feeder
The current cropping frame is deleted when new one is defined.
