A150.117G
Bedienungsanleitung
D/A/CH
Elektro-Multipfanne „MINI"
Seite 3 bis 16
Instruction manual
Electric multi pan „MINI"
GB/UK
from page 17 to 30
Mode d'emploi
Multi-poêle électrique „MINI"
F/B/CH
de page 31 à page 44
Gebruiksaanwijzing
NL/B
Elektrische multipan „MINI"
blz. 45 t/m 58
Instrukcja obsługi
PL
Elektryczna patelnia uniwersalna „MINI"
strony od 59 do 72
V5/0112
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bartscher A150.117G
Summary of Contents for Bartscher A150.117G
- Page 1 A150.117G Bedienungsanleitung D/A/CH Elektro-Multipfanne „MINI“ Seite 3 bis 16 Instruction manual Electric multi pan „MINI“ GB/UK from page 17 to 30 Mode d’emploi Multi-poêle électrique „MINI“ F/B/CH de page 31 à page 44 Gebruiksaanwijzing NL/B Elektrische multipan „MINI“ blz. 45 t/m 58 Instrukcja obsługi...
-
Page 2: Table Of Contents
5.3 Operation 25-27 6. Cleaning and maintenance 6.1 Safety advice 6.2 Cleaning 28-29 6.3 Safety instructions for maintenance 7. Waste disposal Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax: +49 (0) 5258 971-120 - 17 -... -
Page 3: General Information
1. General information 1.1 Information about the instruction manual This instruction manual contains information about the installation, operation and maintenance of the device and should be consulted as an important source of information and reference guide. Awareness of the safety instructions and instructions for use in this manual will ensure the safe and correct use of the device. -
Page 4: Liability And Warrantees
1.3 Liability and Warrantees All the information and instructions in this manual take into account standard safety regulations, current levels of technical engineering as well as the expertise and experience we have developed over the years. The instruction manual was translated with all due care and attention. However, we do not accept liability for any translation errors. -
Page 5: Safety
2. Safety This section provides an overview of all important safety aspects. In addition every chapter provides precise safety advice for the prevention of dangers which are highlighted by the use of the above mentioned symbols. Furthermore, attention should be paid to all pictograms, markers and labels on the device, which must be kept in a permanent state of legibility. -
Page 6: Intended Use
CAUTION! o The device is not intended for use by individuals (including children) with physical or mental disabilities, insufficient experience, and/or insufficient knowledge unless such persons are under the care of a person responsible for their safety or have received instructions regarding appropriate use of the device. -
Page 7: Delivery, Packaging And Storage
3. Transport, packaging and storage 3.1 Delivery check Please check the delivery upon completeness and transport damage immediately after receipt. In case of visible damage do not accept or accept the delivery with reservation only. Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint. Hidden damages should be reclaimed immediately after notice, as claims for damages can only be asserted within the effective period for complaints. -
Page 8: Technical Data
4. Technical data 4.1 Overview of parts COVER HANDLE COVER HEATING PLATE PIN IN SOCKET HANDLE SOCKET BODY The automatic temperature control Temperature adjustment Temperature sensor Control lamp Feed cable Plug - 23 -... -
Page 9: Technical Specification
4.2 Technical specification Description: Electric multi pan „MINI“ A150.117G Item no.: Model: non-stick coating Connection: 230 V ~ 50 Hz 1,3 kW Diameter: outer 32 cm / inner 28.5 cm; Dimensions: Total height: 15.5 cm; Depth: 3.5 cm / approx. 2 litres Weight: 2.05 kg... -
Page 10: Installation And Connection
WARNING! Hazard via electrical current! The device may cause injuries due to improper installation! Before installation, the local power grid specification should be compared with that of the device (see type label). Connect the device only in case of compliance! Take note of the security advice! 5.2 Installation and connection •... - Page 11 WARNING! In case the temperature controller is not plugged in appropriately abnormal heating can arise and lead to accidents and damage. Therefore the correct connection of the temperature controller must be ensured. Connect the device to appropriate power supply source. Adjust temperature scale according to requirements.
- Page 12 Use of the cover Use the cover preferably for pizza, beefsteak, grilling in foil, hamburgers, scrambled eggs, pan cakes and other friable meals. While roasting meals steam escapes between pan and cover, so be cautious when removing the cover. WARNING! Danger of burn! During the work of the device hot steam escapes out of the steam outlet.
-
Page 13: Cleaning And Maintenance
6. Cleaning and maintenance 6.1 Safety advice o Before beginning with repair or cleaning works make sure the device has been disconnected from power socket (pull the power plug!!!) and has cooled down. o Do not use any acid agents and make sure no water ingresses the device. o To protect yourself from electric shock, never immerse the device, its cables and the plug in water or other liquids. -
Page 14: Safety Instructions For Maintenance
Cleaning the heating plate o After it cools, the unit may be cleaned. Cover the frame with a hand, so that water does not get inside. o Remove any scraps of food using a paper cloth. If they cannot be easily removed, pour a small amount of water into the heating plate and turn the thermostat to ON. -
Page 15: Waste Disposal
NOTE! For the disposal of the device please consider and act according to the national and local rules and regulations. Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax:...
