Menu Elements

Title bar
Highlight
Solid triangle
Radio button
Menu windows or dialog box typically have the following elements:
Title bar: Indicates the menu title.
X Close button:
Click to close the window with saving changes. (USB mouse only)
Highlight:
Indicates the selected menu or item.
Solid triangle: Indicates further choices are available. A highlighted triangle indicates the item is active.
Tab: Indicates a group of features in a dialog box. Clicking on any tab brings its page to the front.
Radio button:
Use this round button to select an option in a dialog box.
Check box:
Place a checkmark in the square box to turn the option On.
Slide bar: Indicates settings or the direction of adjustment.
OK button: Press to confirm your setting. You will return to the previous menu.
Cancel button:
Press to cancel your setting. You will return to the previous menu.
Tab
Setup
Page4
Page1 Page2 Page3
Orientation
Front Floor
Background
Blue
Setup
Page1 Page2 Page3 Page4
Mouse
Button
Right Hand Left Hand
Sensitivity
Fast Medium Slow
Clear Lamp Hour Meter
Slide bar
Brightness
Close button
Signal Select
Auto
RGB
Auto
Video
Auto
S-Video
OK Cancel
Auto Start
Power Management
Power Off Confirmation
Keystone Save
Fan High Speed Mode
OK Cancel
E–19
Cancel Button
OK Button
Check box
