Onvif CDIH116IR User Manual

Indoor 1.3 mega pixel ir dome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Indoor 1.3 Mega Pixel IR Dome Camera
•
High resolution H.264 / MJPEG dual encoding and transmission
•
30 images per second at 1.3 mega pixel resolution
•
Versatile 3.6-16mm auto Iris mega pixel lens
•
Advanced 1/3" progressive scan MOS technology
•
24 high performance IR LED's for zero lux viewing up to 65 feet
•
Extremely low light performance true Day/Night with mechanical IR cut filter
•
Integrated 3 axis mount bracket included
•
iNEX compatible
•
OnVIF and PSIA integration
•
DC12V
101 Wrangler, Suite 201 • Coppell, Texas 75019 • Phone: 469-635-6800 • Fax: 469-635-6822 • Toll Free: 1-888-694-STAR (7827)
www.costarvideo.com
CDIH116IR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDIH116IR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onvif CDIH116IR

Summary of Contents for Onvif CDIH116IR

  • Page 1 Extremely low light performance true Day/Night with mechanical IR cut filter • Integrated 3 axis mount bracket included • iNEX compatible • OnVIF and PSIA integration • DC12V 101 Wrangler, Suite 201 • Coppell, Texas 75019 • Phone: 469-635-6800 • Fax: 469-635-6822 • Toll Free: 1-888-694-STAR (7827) www.costarvideo.com...
  • Page 2 CDIH116IR User’s Manual CDIH116IR User’s Manual (Product Guide) Version 4.12(Rev.E) September 30, 2011 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 3 Revised: September 30, 2011 About This Document This document is prepared for users of CDIH116IR supplied by Costar Video Systems, LLC. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer.

  • Page 4: Table Of Contents

    2.1..........................12 IEW UNDER OVER 2.1.1. CTL Port Description ............................13 2.1.2. Speaker V-out Jack Description ........................13 2.1.3. MIC Jack Description ............................13 CDIH116IR INSTALLATION AND BASIC SETUP ................14 3.1..............................14 EFORE NSTALLATION 3.2............................14...

  • Page 5: Product Overview

    Costar Video® CDIH116IR is a stand-alone device transmitting vdeo from built-in megapixel camera over IP(Internet Protocol) network. It can transmit up to 30fps over the existing network. You can monitor video of CDIH116IR through web browser(ie. MS Internet Explorer), if CDIH116IR is connected to network. CDIH116IR supports video compression both Motion-JPEG and H.264 simultaneously so that user can choose appropriate video...

  • Page 6: Key Features

    CDIH116IR User’s Manual 1.2. Key Features  Standalone device with a built-in web server  10M/100M Auto-Sensing Ethernet  Configuring and controlling through Web browser  Max 30 fps transmission speed on TCP/IP network  Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 ...

  • Page 7: Technical Specification

    CDIH116IR User’s Manual 1.3. Technical Specification CDIH116IR-MS 32bit Embedded CPU NAND Flash 128Mbytes/DDR2: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed up real-time clock 1/3” progressive scan MOS Active pixels 1280H x 1024V, 1.31M Effective pixels 1376H x 1070V, 1,47M Pixel size: 3.75 (H) μm ×...
  • Page 8 CDIH116IR User’s Manual Frame rate Motion JPEG: Up to 30 fps @ 1280H x 1024V (Other Stream at QCIF) (each channel) H.264: Up to 30 fps @ 1280H x 1024V (Other Stream at QCIF) Motion JPEG and H.264 Dual Streaming (Simultaneously)
  • Page 9 About 0.940kg without power supply Dimensions (HxWxD) and 1.0kg impact-resident casing weight (1lbs = 454g) Polycarbonate clear dome glass Metal base * All specifications are subject to change without prior notice. Table 1 : CDIH116IR Data Sheet Costar Video Systems, LLC...

  • Page 10: Cdih116Ir Packing List

    (Power Cable & SMPS DC12V 1.0A Adapter) Star Wrench and Screw Set CD (User’s Manual, installation wizard and etc) Table 2 : CDIH116IR Packing List Note: Please check all the listed items are included in your package. For any missing items, please contact your local distributor.

  • Page 11: Hardware Description

    Camera module to input Video Bolt for positioning module Move the position of Module right and left (Fix the position when install) (Right and Left) Main Body Mainboard and Camera Module Table 3 : CDIH116IR Front View Costar Video Systems, LLC...

  • Page 12: Rear View Under Dome Cover

    CTL Conn. CTL Port (RS-485, RS-232, DI, DO) Cable Hole Hole for cable out SPEAKER ,V-OUT Conn. Speaker Port ,Video Output Port MIC Conn. MIC Port Power Conn. Power Connector. Table 4 : CDIH116IR Rear View Costar Video Systems, LLC...

  • Page 13: Ctl Port Description

    CDIH116IR User’s Manual 2.1.1. CTL Port Description It’s RS-232 port for Serial input device, Modem or Console (Hyperterminal.connection). For RS-232 connection, RXD,TXD and GND are used. For connection to PC, RXD and TXD are used. RXD and TXD should be cross to communicate properly Picture 4 : CTL Port Description 2.1.2.

  • Page 14: Cdih116Ir Installation And Basic Setup

    Following steps are the physical installation process for CDIH116IR. Fix the CDIH116IR in place Connect the CDIH116IR to the Internet cable through the LAN port. Connect the power supply of CDIH116IR. After that, you need to follow the steps below.
