Bullet 1.3 Mega Pixel IR Camera
•
High resolution H.264 / MJPEG dual encoding and transmission
•
30 images per second at 1.3 mega pixel resolution
•
Versatile 3.6-16mm auto Iris mega pixel lens
•
Advanced 1/3" progressive scan MOS technology
•
50 high performance IR LED's for zero lux viewing up to 100 feet
•
Extremely low light performance true Day/Night with mechanical IR cut filter
•
Integrated 3 axis mount bracket included
•
Includes integrated sun shield
•
iNEX compatible
•
OnVIF and PSIA integration
•
Vandal resistant aluminum construction
•
Weatherproof IP66 rating for extreme conditions
•
DC12V
101 Wrangler, Suite 201 • Coppell, Texas 75019 • Phone: 469-635-6800 • Fax: 469-635-6822 • Toll Free: 1-888-694-STAR (7827)
www.costarvideo.com
CBIH116IR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Onvif CBIH116IR
Summary of Contents for Onvif CBIH116IR
- Page 1 • Integrated 3 axis mount bracket included • Includes integrated sun shield • iNEX compatible • OnVIF and PSIA integration • Vandal resistant aluminum construction • Weatherproof IP66 rating for extreme conditions • DC12V 101 Wrangler, Suite 201 • Coppell, Texas 75019 • Phone: 469-635-6800 • Fax: 469-635-6822 • Toll Free: 1-888-694-STAR (7827)
- Page 2 CBIH116IR User’s Manual CBIH116IR User’s Manual (Product Guide) Version 4.12(Rev.E) September 30, 2011 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
- Page 3 Revised: September 30, 2011 About This Document This document is prepared for users of CBIH116IR supplied by Costar Video Systems, LLC. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer.
-
Page 4: Table Of Contents
ECHNICAL PECIFICATION 1.4. CBIH116IR P ............................9 ACKING HARDWARE DESCRIPTION ......................10 2.1................................. 10 2.1..................................11 CBIH116IR INSTALLATION AND BASIC SETUP ................12 3.1..............................12 EFORE NSTALLATION 3.2............................12 ACTORY EFAULT ETTINGS 3.3. CBIH116IR ............................. 12... -
Page 5: Product Overview
Costar Video® CBIH116IR is a stand-alone device transmitting vdeo from built-in megapixel camera over IP(Internet Protocol) network. It can transmit up to 30fps@1.3M over the existing network. You can monitor video of CBIH116IR through web browser(ie. MS Internet Explorer), if CBIH116IR is connected to network. CBIH116IR supports video compression both Motion-JPEG and H.264 simultaneously so that user can choose appropriate video... -
Page 6: Key Features
CBIH116IR User’s Manual 1.2. Key Features Standalone device with a built-in web server 10M/100M Auto-Sensing Ethernet Configuring and controlling through Web browser Max 30 fps transmission speed on TCP/IP network Effective Bandwidth & Bit-rate Control (VBR/CBR) by H.264 ... -
Page 7: Technical Specification
CBIH116IR User’s Manual 1.3. Technical Specification CBIH116IR 32bit Embedded CPU NAND Flash 128Mbytes / DDR2: 128Mbytes Hardware Linux version 2.6.xx operating system Battery backed up real-time clock 1/3” progressive scan MOS Active pixels 1280H x 1024V, 1.31M Effective pixels 1376H x 1070V, 1,47M Pixel size: 3.75 (H) μm ×... - Page 8 RoHS Dimensions (HxWxD) and 92.8Ø x 235.8(L) x 125.8(H) (in mm) weight (1lbs = 454g) About 1.1kg without power supply * All specifications are subject to change without prior notice. Table 1 : CBIH116IR Data Sheet Costar Video Systems, LLC...
-
Page 9: Cbih116Ir Packing List
Power Supply Unit (Power Cable & SMPS DC12V 1.0A Adapter) CD (User’s Manual, installation wizard and etc) Table 2 : CBIH116IR Packing List Note: Please check all the listed items are included in your package. For any missing items, please contact your local distributor. -
Page 10: Hardware Description
2. Hardware Description 2.1. Main Body View Picture 2 : Front View Name Description IR LED 50pcs 850nm Infrared LEDs. Lens Lens for board mount Sunshield Top covering Sunshield Table 3 : CBIH116IR Main Body View Costar Video Systems, LLC... -
Page 11: Full View
CBIH116IR User’s Manual 2.1. Full View Picture 3 : CBIH116IR Full View Name Description Main body Mainbody Mounting Bracket Mounting bracket LAN Connector. Power Conn. Power Connector. Table 4 : CBIH116IR Full View Costar Video Systems, LLC... -
Page 12: Cbih116Ir Installation And Basic Setup
Following steps are the physical installation process for CBIH116IR. Fix the CBIH116IR in place Connect the CBIH116IR to the Internet cable through the LAN port. Connect the power supply of CBIH116IR. After that, you need to follow the steps below.
