Pairing:
With the PAIRING section highlighted, press MENU key once to begin camera pairing. Pair and the
LED on camera will blink once, followiedby the LED blinking continuously, indicating data transmission
is in process.
System will confirm that the pairing process is successful with "PAIRED" displaying onscreen.
System will indicate that the pairing process failed with "PAIRING FAIL" displaying onscreen.
Press ESC to return to the main menu.
Note: the camera is paired by factory default. The pairing procedure must be followed when adding
additional cameras (SEC-TRCAM30).
Brightness:
With the BRIGHTNESS section highlighted, use ▼▲ to adjust camera brightness.
Press ESC to return to the main menu.
Activation:
With the ACTIVATION section highlighted, use ▼▲ to enable or disable a camera.
Press ESC to return to the main menu.
