OWNER'S GUIDE
S3501SL

Advertisement

loading
Need help?

Need help?

Do you have a question about the S3501SL and is the answer not in the manual?

Questions and answers

Summary of Contents for Shark S3501SL

  • Page 1 OWNER’S GUIDE S3501SL...
  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WHEN USING YOUR SHARK ® Use the system only for its intended use. STEAM MOP, BASIC SAFETY 2. DO NOT use outdoors. PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, 3. DO NOT leave the appliance unattended when plugged in.
  • Page 3 12. DO NOT unplug by pulling on 24. Keep your work area well lit. power cord. To unplug, grasp the 25. Store steam mop indoors in a cool, plug not the power cord. Do not dry place. use extension cords or outlets 26.
  • Page 4: Quick Start

    This is because we test all our steam mops 100% before you buy them, so you get a quality Shark Steam Mop. ® ASSEMBLE Insert the mop handle into the pump actuator (the tube that leads to the tank).
  • Page 5 DIRT CAN’T HIDE ON EITHER SIDE! All new design allows for optimal cleaning! When one side of the pocket gets dirty, just turn the mop head over and clean with the QUICK other side of the pocket. TIP: For easier pushing and pulling, extend the...
  • Page 6 This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of electrical and electronic equipment (WEEE). This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC and its revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions. This marking indicates that this product should not be disposed with other household wastes throughout the EU.
  • Page 7: Table Of Contents

    Contents Thank you for Getting Started ................2 purchasing Using Your Steam Mop ..............5 the Shark Using Your Carpet Glider ............. 7 ® Steam Care of Your Steam Mop .............. 8 Pocket Mop. ® Troubleshooting Guide ............... 10...
  • Page 8: Getting Started

    When assembling your steam mop there may be a little water in or around the water tank. This is because we test all our steam mops 100% before you buy them, so you get a quality Shark ® Steam Pocket Mop.
  • Page 9 ASSEMBLE Insert the mop handle into the pump Snap the mop head into the base to actuator (the tube that leads to the secure it. Press the release button to tank). Push the mop handle and pump exchange mop heads. actuator together in until you hear it click into place.
  • Page 10 If you have hard water you might want to use distilled water to prolong the life of the Shark ® Steam Mop. Make sure you only add water to the tank.
  • Page 11: Using Your Steam Mop

    Using Your Steam Mop IMPORTANT: Make sure you don’t use the mop without attaching a microfibre pocket and adding water to the tank first. When you are using the mop for the first time, it might take longer than the normal 30 seconds to start steaming.
  • Page 12 Using Your Steam Mop - cont’d For your comfort, you can adjust the When the water tank is empty, the height of the mop. Just lift the latch steam mop will stop producing on the tube 90 degrees to the open steam.
  • Page 13: Using Your Carpet Glider

    Using Your Carpet Glider The Steam Mop won’t clean your carpeting or area rugs. However, it’s great for deodorising and freshening. THE CARPET GLIDER The Carpet Glider can be used with the rectangle mop head to lightly steam your carpet and area rugs. Just place the mop head on top of the glider and move back and forth across a section of the carpet.
  • Page 14: Care Of Your Steam Mop

    2-3 minutes and release steam by pumping the handle several times before removing the microfibre cleaning pocket from the mop head. To store the Shark Remove the microfibre cleaning ® Steam Mop pocket by releasing the quick hanging up;...
  • Page 15 40° KEEPING YOUR MICROFIBRE If there are loose threads on the pocket carefully cut the thread with CLEANING POCKET AS GOOD scissors. Don’t pull on them or cut at AS NEW the base. We recommend washing your microfibre pockets separately from other fabrics to avoid picking up lint.
  • Page 16: Troubleshooting Guide

    Troubleshooting Guide PROBLEM POSSIBLE REASONS & SOLUTIONS Your Steam Mop should be securely plugged into a The Steam Mop 220-240 V. electrical outlet only. will not turn on. Check your fuse or breaker. Prime the pump, see page 4 for more information. Steam Mop will not Is there water in the water tank? If not, add water to your make steam.
  • Page 17 Notes...
  • Page 18 Notes...
  • Page 19 Notes...
  • Page 20 Technical Details Model number: S3501SL 11 Input: 1550 Watts Main unit voltage: 230V~, 50/60 Hz COPYRIGHT© EURO-PRO OPERATING LLC 2011 PRINTED IN CHINA S3501SL.E.110907.3 Illustrations may differ from actual product.
