10. Control and Settings Through HTTP Order
User can control the 9258's action directly though the HTTP orders.
The format of the HTTP order is :
http://username:password@XXX.XXX.XXX.XXX/Set.cmd?CMD=***Power+para1=*+p
ara2=*+para3=*......
Explanations of each part of the order:
Username : 9258's username, default username is admin
Password : 9258's password, default password is 12345678
XXX.XXX.XXX.XXX the IP Address of 9258
CMD=***Power : the function module of 9258
para1 ~ para3 parameters
Example 1 : control the power supply of 9258:
http://admin:12345678@192.168.1.10 /Set.cmd?CMD=SetPower+
P60=1+P61=1+P62=1+P63=0
This command control IP Power 9258 IP address at 192.168.1.0, user name is admin and
password is 12345678.
This order will:
turn on the power of outlet1 (p60), turn on the power of outlet2 (p61),
turn on the power of outlet3 (p62), turn off the power of outlet4 (p63).
When this order is sent, the IP Power will return the following message:
<html>P60=1,P61=1,P62=1,P63=0</html>
* Function of 9258 :
1. SetPower : to control I/O - read parameter as follow
out1 set parameter as 0 （output1 disconnect power ）or 1（output1 connect power）
out2－out4 same as out1
2. GetPower : to read I/O pasameter - read parameter as follow
out1 if parameter reply as 0 （output1 disconnect power ）or 1（output1 connect power）
out2－out4 same as out1
http:// /admin:1234567@ 192.168.1.100/Set.cmd?CMD=GetPower
the above command control 9258 IP address as 192.168.1.10， username is admin，
password is 12345678的9258，
as send out thiis command , 9258 will get message as follow: :
<html>P60=1,P61=1,P62=1,P63=0</html>
IP POWER 9258 USER MANUAL
- 22 -
