Setting Of Software Shut Down Controlled Pc/ Server - Aviosys IP POWER 9258T User Manual

2. IP Power 9258's default setting is fixed IP address: 192.168.10.100. The IP
address of your computer should in the same subnet with that of IP Power 9258's,
so that you can open the control web page. In the figure above, the IP address of
IP Power 9258 is 192.168.100.168. You can make sure the IP address of your
computer first, then use the ipedit.exe to modify the IP address of IP Power
9258.after that, your computer can connect to the IP Power 9258.
3. IF user can not enter the control web page, please set the IP address of IP Power
9258 and your computer in the same subnet. User can obtain the computer's IP
address, subnet mask, and default gateway through the following method.
start run type in "cmd"
"ipconfig"
The last number of the IP address (default is 100) can be any number between 1~254, but
cannot be the same with that of the computer's. If you want to use it at home, you can enter
the web page by typing in the IP, the IE, or using ipedit.exe program.
*Same subnet : means the first three parts of the IP address must be the same, such as
XXX.XXX.X.abc. For example, 192.168.1.100 and 192.168.1.123 are in the same subnet.
5 .The default username and password of IP Power 9258 are:
Username: admin
Password: 12345678

Setting of software shut down controlled PC/ Server

9258 can safety turn off the PC/Server through Network then cut off the power of PC
/Server . By this way you can remote shut down PC/ Server which is connect with IP Power
9258 by normal Windows shut down procedure, before operate software shut down function
please note the essence install our software on as following :
1. Please install program " IP9258service.exe " in controlled PC.
2. If there is operate program like WINDOWS OFFICE which can not be save
automatically. 9258 will still shut down controlled PC/server without save the file.
then open the MS –DOS window, now type in
- 9 -
IP POWER 9258 USER MANUAL
VER. X.X,
