  • Page 1 2015 2 1 9 0 0 1 5 3 1 Original Instructions...
  • Page 2 This is a non-exhaustive list of trademarks that are the property of Bombardier Recreational Products Inc. or its affiliates: Sea-Doo ® Sea-Doo MOVE™ Spark™ smo2015-004 en JT ®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates.

  • Page 3: Introduction

    INTRODUCTION Congratulations on your purchase continue or change specifications, de- of your new BRP Sea-Doo MOVE™ signs, features or equipment without trailer. It is backed by the BRP warranty incurring any obligation upon itself. and a network of authorized Sea-Doo...
  • Page 4 INTRODUCTION This page is intentionally blank _______________...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ..............Know Before You Go ..
  • Page 6 Trailer Cleaning ..............32 WARRANTY BRP LIMITED WARRANTY USA AND CANADA: 2015 SEA-DOO MOVE ™...

  • Page 7: Safety Information

    SAFETY INFORMATION ________ ________ SAFETY INFORMATION...

  • Page 8: Special Safety Messages

    Make sure your vehicle is de- signed to tow a trailer and its towing ca- pacity is sufficient. Trailer This BRP Sea-Doo MOVE™ trailer has WARNING been specially designed to carry a per- sonal watercraft (PWC). Never tow this trailer with a vehi-...

  • Page 9: Location Of The Important Labels

    Safety Labels The following labels are on your trailer. If missing or damaged, they can be replaced free of charge. See an autho- rized Sea-Doo dealer. Please read the following labels care- fully before using your trailer. smo2012-006-055_a MOVE I AND II TRAILERS WITH WINCH...

  • Page 10: Technical Information Label

    LOCATION OF THE IMPORTANT LABELS Technical Information Label 1250 1250 4.80 X 12B smo2014-004-001 LABEL 1 - MOVE I EXTENDED 1250 smo2015-004-001_a TYPICAL - MOVE I 1500 1500 5.30 X 12C smo2015-004-002_a smo2013-005-100 TYPICAL - MOVE II LABEL 1 - MOVE I EXTENDED 1500 1220 1220 4.80 X 12B...
  • Page 11 LOCATION OF THE IMPORTANT LABELS smo2012-006-005_a LABEL 1 - MOVE II smo2012-006-002 LABEL 2 - MOVE I smo2014-004-004 LABEL 2 - MOVE I EXTENDED 1250 ________ ________ SAFETY INFORMATION...
  • Page 12 LOCATION OF THE IMPORTANT LABELS smo2013-005-101 LABEL 2 - MOVE I EXTENDED 1500 smo2012-006-003 LABEL 2 - MOVE II smo2014-004-003 LABEL 2 - SPARK™ MOVE II _______ ________ SAFETY INFORMATION...

  • Page 13: Operating Instructions

    OPERATING INSTRUCTIONS _______________...

  • Page 14: Trailer Set-Up

    (20 lbf•ft ± 2 lbf•ft) bolt Bunks The wooden bunks are preset to suit all Sea-Doo personal watercraft (PWC) smo2010-003-025_a hull designs, however, a universal 1. Winch support U-bolts nuts rule applies: bunks must lean square against a plain area of the hull.

  • Page 15: Spark™ Move Ii

    TRAILER SET-UP 2. Put the PWC on the trailer so the bunks are square with hull as shown on illustration. smo2012-006-009_a MOVE I TRAILER 1. Bunk square with hull 2. Nut sbl2012-012-200_a MOVE II TRAILER 1. Bunk square with hull 2.

  • Page 16: Before Getting Underway

    WARNING If the coupler cannot be secured to hitch ball, do not tow the trailer. Refer to an authorized Sea-Doo dealer to inspect the trailer as soon as possible. smo2010-003-002_a TYPICAL 1.
  • Page 17 BEFORE GETTING UNDERWAY 7. Attach the tongue safety cables or chains. Attach the left cable or chain to the bracket on the right side of hitch and the right cable or chain to the left bracket. NOTICE avoid damaging wiring harness, ensure the harness is not passed between the tongue safety cables or chains.

  • Page 18: Pre-Use Inspection

    The pre-use inspection can help you monitor wear and deterioration before they become a problem. Correct any problems that you discover to reduce the risk of a breakdown or crash. See an authorized Sea-Doo dealer as necessary. ✔ OPERATION Make sure the hitch ball size matches the coupler size (5 cm (2 in)).

  • Page 19: Towing The Trailer

    TOWING THE TRAILER Follow the tow vehicle's manufacturer instructions regarding trailer towing. SEVERE INJURY OR DEATH can re- sult if you do not follow these instruc- tions: When towing the trailer, pay particular attention to the following: – Use a longer following distance from the vehicle in front of you.

  • Page 20: Launching The Watercraft

    LAUNCHING THE WATERCRAFT Launching the Watercraft (Trailers with Winch) 1. Prepare the personal watercraft (PWC) for launching according to the PWC manufacturer's recom- mendations. 2. Remove tie-downs from stern and trailer eyelets. 3. Disconnect lights connector. 4. Make sure the way is clear behind the trailer (in and out of water).

  • Page 21: Loading The Watercraft

    LOADING THE WATERCRAFT Loading the Watercraft (Trailers with Winch) WARNING Make sure nobody stands on the walk pads when loading the water- craft. 1. Disconnect lights connector. smo2012-007-053_a 2. Have someone guiding you and TYPICAL - MOVE I back the vehicle until the trailer 1.
  • Page 22 LOADING THE WATERCRAFT This page is intentionally blank ______________...

  • Page 23: Technical Information

    TECHNICAL INFORMATION _______________...

  • Page 24: Trailer Identification Number

    TRAILER IDENTIFICATION NUMBER The trailer is identified by a serial number. It may sometimes become necessary to locate this number for warranty purposes or to trace the trailer in the event of theft. The serial number is located on the Technical Information label and is also engraved on the tongue of the trailer.

  • Page 25: Specifications

    SPECIFICATIONS MOVE I MOVE I MODEL MOVE I EXTENDED 1250 EXTENDED 1500 SUSPENSION Torsion and leaf Type Leaf spring Leaf spring spring DIMENSIONS Overall length 4.1 m (13.5 ft) 4.1 m (13.5 ft) 3.8 m (12.5 ft) Overall width 1.5 m (4.9 ft) 1.7 m (5.5 ft) 1.5 m (4.9 ft) Width between fenders...
  • Page 26 SPECIFICATIONS MODEL MOVE II SPARK™ MOVE II SUSPENSION Type Leaf spring Leaf spring DIMENSIONS Overall length 5.18 m (17 ft) 3.78 m (12.5 ft) Overall width 2.5 m (8.2 ft) 2.6 m (8.5 ft) Width between fenders 2.1 m (6.9 ft) 2.23 m (7 ft) Width between rails N.A.

  • Page 27: Reporting Safety Defects

    REPORTING SAFETY DEFECTS Your safety is very important to Bombardier Recreational Products Inc. (BRP). If you have any concerns you should immediately contact BRP's customer service. In the USA, if you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Bombardier Recreational Products Inc.
  • Page 28 REPORTING SAFETY DEFECTS This page is intentionally blank ______________...

  • Page 29: Maintenance

    MAINTENANCE _______________...

  • Page 30: Maintenance Schedule

    MAINTENANCE SCHEDULE Maintenance is very important for keeping your trailer in safe operating condition. The maintenance schedule does not exempt the pre-use inspection. NOTE: If trailer is used all year STORAGE round, carry out both PRE-SEASON maintenance opera- tions once a year. At Storage Carry out the following at trailer stor- age:...

  • Page 31: Maintenance Procedures

    Discontinue use and contact an autho- 1.6 mm (1/16 in) depth or if the built-in rized Sea-Doo dealer if cable or its liner wear indicator bars are visible and flush are damaged.

  • Page 32: Wheel Bearings And Seals

    MAINTENANCE PROCEDURES Wheel Bearings and Seals To remove side marker light bulb, pry it off its socket. To install, push the bulb Wheel Bearing Inspection in the socket until it bottoms. There is no indexation for that type of bulb. Install a jack under the axle and raise until the tire gets off the ground.

  • Page 33: Winch

    MAINTENANCE PROCEDURES smo2010-003-015_a smo2010-003-006_a PRY LENS OFF 1. Grease fitting 1. Flat screwdriver Wooden Bunks 2. Pull burnt bulb off its socket. Check wooden bunks carpet condition 3. Push a new bulb into the socket un- and wood hardness. til it bottoms. There is no indexation for that type of bulb.

  • Page 34: Trailer Care

    TRAILER CARE Salt Water Use If trailer used in salt water, thoroughly rinse trailer daily with fresh water. Trailer Cleaning 1. Rinse the trailer thoroughly with fresh water to remove loose dirt. 2. Using a soft, clean cloth, wash the trailer with water mixed with a mild detergent, such as soap specially formulated for motorcycles or auto-...

  • Page 35: Warranty

    WARRANTY _______________...

  • Page 36: Brp Limited Warranty Usa And Canada: 2015 Sea-Doo Move

    All genuine Trailer parts and accessories installed on the Trailer by an authorized Sea-Doo Dealer at the time of delivery of the Trailer will carry the same warranty as that of the Trailer.

  • Page 37: Trailer

    – The Trailer must be purchased as new and unused by its first owner from a Sea- Doo dealer authorized to distribute Trailers in the country in which the sale oc- curred (“Sea-Doo Dealer”). – The BRP specified pre-delivery inspection process must be completed, docu- mented and signed by the purchaser.
  • Page 38 The customer must cease using the Trailer upon the appearance of an anomaly. The customer must notify a servicing Sea-Doo Dealer within two (2) days of the appearance of a defect, and provide it with reasonable access to the product and reasonable opportunity to repair it.
  • Page 39 In the event of a controversy or a dispute in connection with this limited warranty, BRP suggests that you try to resolve the issue at the dealership level. We recom- mend discussing the issue with the authorized Sea-Doo Dealer's service manager or owner.
  • Page 40 This page is intentionally blank ______________...

  • Page 41: Customer Information

    CUSTOMER INFORMATION _______________...

  • Page 42: Privacy Information

    PRIVACY INFORMATION BRP wishes to inform you that your coordinates will be used for safety and war- ranty related purposes. Furthermore, BRP and its affiliates may use its customer list to distribute marketing and promotional information about BRP and related products.

  • Page 43: Change Of Address/Ownership

    CHANGE OF ADDRESS/OWNERSHIP If your address has changed or if you are the new owner of the trailer, be sure to no- tify BRP by either: – Mailing one of the following card below; – North America only: calling at 715 848-4957 (USA) or 819 566-3366 (Canada); –...
  • Page 44 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 45 CHANGE OF ADDRESS/OWNERSHIP _______________...
  • Page 46 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 47 CHANGE OF ADDRESS/OWNERSHIP _______________...
  • Page 48 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 49 CHANGE OF ADDRESS/OWNERSHIP NOTES _______________...
  • Page 50 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 51 219 001 363 219001531 USER’S GUIDE, SEA-DOO MOVE TRAILER / ENGLISH USER’S GUIDE, SEA-DOO MOVE TRAILER / ENGLISH GUIDE DE L’UTILISATEUR, REMORQUE SEA-DOO MOVE / ANGLAIS GUIDE DE L’UTILISATEUR, REMORQUE SEA-DOO MOVE / ANGLAIS FAIT AU ÉTATS-UNIS/ MADE IN USA U/M:P.C.
