Mercedes-Benz Parking Assistant System
——————————————————————————————————————————————————————————
Mercedes-Benz
Model: SE-MB15(A/B/CLA/GLA/C/V/GLC/GLE-Class)
Multimedia GPS system
with Capacitive touchpad
Easy Operation Manual
For ALL NTG5-Entry
SUNE TECHNOLOGY ELECTRONIC CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City
70849,TAIWAN
TEL:+88662292246 FAX:+88662288104
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
NTG5-HU
NTG5S1
Easy Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the SE-MB15 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sune Technology SE-MB15

Summary of Contents for Sune Technology SE-MB15

  • Page 1 Mercedes-Benz Parking Assistant System Easy Operation Manual —————————————————————————————————————————————————————————— Mercedes-Benz Multimedia GPS system with Capacitive touchpad Easy Operation Manual Model: SE-MB15(A/B/CLA/GLA/C/V/GLC/GLE-Class) For ALL NTG5-Entry NTG5-HU NTG5S1 SUNE TECHNOLOGY ELECTRONIC CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99...
  • Page 2 1.2.Features and Performance  products Model :SE-MB15 Multimedia GPS system for C-Class,B-class,CLA-class,A-Class,GLA-Class, GLC-class ,GLE-class,V-class with NTG5 audio20 with 7inch system.  All features of this product is switched by the original car audio buttons or by touch ...
  • Page 3 Installation(For W205/GLC/447) 1.How to remove Headunit 1.The center armrest side silver plaque with the 2.Remove two screws apart and trim, tools to remove, the two sides each a dark The whole panel can be removed, as button as shown above shown above 3.The entire panel is dark fasten.Removed from 4.Remove two screws on the top of...
  • Page 4 2.How to remove screen and install capacitive touchpad 1.Use special tool,remove speaker 2.Carefully remove Chrome frame cover than remove 2 of screws you than you can remove black frame will take out monitor on chrome frame 4.The cable folded like photo 3.Remove black front frame like this.
  • Page 5 7.Insert into ting-long ribbon cable 8.The small plate into the gap from front to back of screen 10.Fixed small plate 9.Mounted on the front frame make sure ribbon cable was back of screen 12.Front side 11.Finished back side...
  • Page 6 Installation(For A/B/CLA/GLA/GLE) 1.How to remove Headunit 1.Use tool remove Left and Right Air- 2.Remove parts conditioning vent 3.Remove screws(Left and Right) than you can remove Audio system...
  • Page 7 2.How to remove screen and install capacitive touchpad 1.Remove 2 of screws back of screen than 2.Remove buttom of 2 screws take out monitor 4.Remove black front frame like this. 3.Remove front chrome frame,push it different size than you can remove it see red arrow 5.Carefully past capacitive on chrome...
  • Page 8 7.connection ting-long ribbon cable 8.The small plate into the gap 10.Front side 9.ribbon cable to back size...

  • Page 9: Installation

    Installation 6.Remove original blue LVDS than plug 5.Please take away black connector than into module LVDS-out connector,module plug into module Female connector than LVDS from module LVDS-in to comand module black male connector in original blue connector connector Power 12V 7.you can connection module 8.install module and camera than power from front passenger...
  • Page 10 Diagram Cable colour Assignment CAN LOW Pin 3 ● Brown CAN HIGH Pin 9 ●● Brown/Red No liability for vehicle wire colors and pin definition! Possible changes by the vehicle manufacturer. The given information must be verified by the installer.
  • Page 11 Function on the original single-finger tap the touch screen (about 2 seconds) change to car Multimedia interface.In the GPS screen, the two finger tap the touch screen (1-2 seconds) to display the Main menu screen, Quick button operation: Return button on the steering wheel (can be changed according to customer demand other button) Short Press Return button ：...
  • Page 12 DTV,DVD Model selection DTV type(option) Factory IR touch code default : DVD DVR type(option) DVD input For touch code(option) DTV input For touch code(option) DTV input All function you can touch on touch screen to control function We can support DVBT,DVBT2 and ISDBT...
  • Page 13 DVR input touch control with multi language Rear View camera GPS system Parking setting,FM Setting(built-in wirless transfer can send DVD,DTV audio to car system) Switch mode button(shortcut button)
  • Page 14 2. Blue wire connection 360 signal to back light(12V) 3. Auxiliary "Voltage trigger" must enable Note: Customers can function DIP switch status to select according to their actual needs. Monitor comand system Original LCD cable Offered LCD cable LVDS IN power LVDS OUT Multimedia GPS system SE-MB15...
