Owner's Manual &
Installation Instructions
AVE12
AVE15
AVE18
AVE22
23-11-2130N-003
49-7411
01-01 JR
Advertisement
Table of Contents
Related Manuals for GEAppliances AVE12
Summary of Contents for GEAppliances AVE12
-
Page 1: Table Of Contents
Connect Electricity ....2 Extension Cords ....3 AVE12 Safety Precautions ....2... -
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, electric shock or personal injury. SAFETY PRECAUTIONS Use this appliance only for its intended Turn the mode control OFF and unplug purpose as described in this Owner’s your air conditioner before making any... -
Page 3: Adapter Plugs
WARNING! USE OF EXTENSION CORDS – 115-Volt models only Because of potential safety hazards under certain CAUTION: conditions, we strongly recommend against the use of an extension cord. DO NOT use an extension cord with any of the However, if you must use an extension cord, 230/208 volt models. -
Page 4: Operating Instructions
About the controls on the air conditioner. Features and appearance will vary. COOL COOL HEAT HEAT MODE CONTROLS Your model will have one of the above type controls. TEMP CONTROLS Your model will have one of the above type controls. Controls Mode Controls Heating Descriptions... - Page 5 Additional controls and important information. Vent Control When set at CLOSED , only the air inside the room On some models, the vent control is located beside will be circulated and conditioned. When set at the air louvers. OPEN , some inside air is exhausted outside.
-
Page 6: Care And Cleaning
Care and cleaning of the air conditioner. Grille and Case Turn the air conditioner off and remove the To clean, use water and a mild detergent. plug from the wall outlet before cleaning. Do not use bleach or abrasives. Outdoor Coils The coils on the outdoor side of the air conditioner should be checked regularly. -
Page 7: Window Installation
Preparing to install the air conditioner. Read these instructions completely and carefully. Before You Begin NOTE TO INSTALLER: Leave these instructions with CAUTION: the air conditioner after installation is completed. Do not, under any circumstances, cut or remove the third (ground) prong from the NOTE TO CONSUMER: Keep this Owner’s Manual power cord. - Page 8 Window Installation Instructions. Read the section Preparing to Install the Air Conditioner before beginning. Parts Included 2 support brackets Foam top window gasket 2 sliders Case 2 case Window side seals locking 2 filler panels bracket 3/8″ slotted 3/8″ hex-head screws washer Upholstery 5/8″...
- Page 9 The electrical outlet must be within reach of the power cord. The air conditioner can be installed without the accordion panels if needed to fit in a narrow window. See the window opening dimensions below. AVE12 model AVE15, AVE18 and AVE22 models ″ min. ″ min. ⁄ ⁄...
- Page 10 Window Installation Instructions. Remove the Air Conditioner from the Case On some models, open the control door and Remove one screw from each side of the case. remove the screw. Remove the front grille. Keep these ground/anti-theft screws so they may be replaced at the end of the installation.
- Page 11 Install the Side Seals and the Case in the Window Open the window and mark the centerline Carefully place the case in the window and on the stool. align the center of the bottom tie bar with the centerline on the window stool. Do not release your grip on the case until the window is in its final position.
- Page 12 Window Installation Instructions. Install the Support Brackets Thread a bolt into each support bracket. Position the brackets on the case bottom so they will be near the outermost point on the window sill. (Brackets may be positioned in either direction, for maximum support, depending on the depth of the window sill.) Attach a support bracket to each side of the case bottom using two 3/8″...
- Page 13 Install the Window Filler Panels and Locking Bracket Insert the cut edge of the filler panel into the Pull the sliders out until they contact the case side seal groove. face of the window molding. (Note: If a slider has slipped into the top retainer bar and cannot be pulled out, use the slider on Case the other side to tap it out.)
- Page 14 Window Installation Instructions. Install the Window Gasket and Replace the Air Conditioner Cut the foam top window gasket to the window Slide the air conditioner into the case and width. Stuff the foam between the glass and the replace the front grille. Install the two window to prevent air and insects from getting ground/anti-theft screws removed at the into the room.
-
Page 15: Installation Instructions
Through the Wall Installation Instructions–Optional. The case may be installed through the wall in both existing and new construction. Read completely, then follow step-by-step. IMPORTANT Through the wall installation is not appropriate if any of the side louvers in the case will be obstructed by the wall. -
Page 16: Troubleshooting Tips
Before you call for service… Troubleshooting Tips Save time and money! Review the charts on the following pages first and you may not need to call for service. Problem Possible Causes What To Do • Make sure the air conditioner plug is pushed Air conditioner The air conditioner completely into the outlet. -
Page 17: Product Registration
GE Service Protection Plus ™ GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus —comprehensive protection on all your appliances— ™ No Matter What Brand! We’ll Cover Any Appliance. Benefits Include: • Backed by GE Anywhere. - Page 18 Serial Number Important: If you did not get a registration card with your product, detach and return the form below to ensure that your product is registered, or register online at www.GEAppliances.com. Cut here Consumer Product Ownership Registration Model Number Serial Number Mrs.
-
Page 19: Air Conditioner Warranty
Customer Care ® technician. To schedule service, Proof of the original purchase on-line, 24 hours a day, contact us at www.GEAppliances.com, or date is needed to obtain service call 800-GE-CARES. under the warranty. For The Period Of: We Will Replace: Any part of the air conditioner which fails due to a defect in materials or workmanship. -
Page 20: Consumer Support
Consumer Support. GE Appliances Website www.GEAppliances.com Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day of the year! For greater convenience and faster service, you can now download Owner’s Manuals, order parts, catalogs, or even schedule service on-line.
