Clas Ohlson MA-825 Operating Instructions

Bluetooth Speaker
Art.no 38-6048-1, -2, -3 Model MA-825
Please read the entire instruction manual before using the product and
save it for future reference. We reserve the right for any errors in text or
images and any necessary changes made to technical data. If you have
any questions regarding technical problems please contact our Custo-
mer Services.
Safety
• Never use the speaker if it has been damaged in any way.
• Never attempt to repair or modify the speaker in any way.
• Never subject the speaker to high temperatures, dust, heavy
vibrations, impacts, humidity or moisture.
• Do not place the speaker in an unstable position where there is
a risk that it may fall into water or other liquids.
Buttons and functions
1
2
3
4
1. [ ] Bluetooth connection button
2. LED indicator
3. [ OFF/ON ] Power switch
4. Micro-USB charger port connection
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk

Operating instructions

Charging
1. Connect one end of the charge cable to the speaker and the other
end to an available USB port on your computer. Optionally, you can
connect it to another USB charge source/charger.
2. The LED indicator will show red while charging is in progress and
will turn off once the integrated battery is fully charged
(charging time: 1.5–3 h).

Bluetooth connection

1. Switch the speaker on. The LED indicator will begin flashing blue.
2. Hold the [ Bluetooth connection ] button depressed until the speaker
emits an audible signal and the LED indicator begins a slow flashing
pattern which indicates that the speaker is ready for device pairing.
3. Activate Bluetooth on the device to be paired and place it in
search mode.
4. The Bluetooth speaker will appear as "MA-825" on your device.
Select this as the device to be connected. If you are prompted to
enter a PIN code, enter 0000 (four noughts). Certain devices may
even require the connection to be approved. Refer to the instruction
manual of your device for further clarification.
5. When contact has been established the LED indicator will indicate
a successful connection by flashing twice every 4 seconds.
6. Start and check for proper playback from the connected device.

Care and maintenance

Clean the speaker using a lightly moistened cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.

Troubleshooting guide

•
The Bluetooth The battery is discharged.
speaker will Recharge the battery.
not switch on.
No sound. • Check both the volume and that play/pause
has been activated on the device.
•
Make sure that the Bluetooth connection is
functioning properly.
• Test the playback of the file on the device itself
before connecting it to the speaker.
• Try playback using another file. The file you are
attempting to play may be damaged.
•
Make sure that no other wireless devices are
disrupting the current Bluetooth connection.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

Specifications

Bluetooth 3.0
Integrated battery 3.7 V
Charge current 5 V
Size 55 × 55 x 80 mm

Declaration of Conformity

Hereby, Clas Ohlson AB declares that following product(s):
Bluetooth Speaker
Art.no 38-6048-1 Model MA-825
38-6048-2 MA-825
38-6048-3 MA-825
is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC.
Article 3.1a (Health): EN 62479
Article 3.1a (Safety): EN 60950-1
Article 3.1b (EMC): EN 301489-1
EN 301489-17
Article 3.2 (Radio): EN 300328
0700
Insjön, Sweden, December 2013
Klas Balkow,
President.
Clas Ohlson, 793 85 Insjön, Sweden
