  • Page 1 Instruction manual URC-1625 Universal remote...

  • Page 2: Table Of Contents

    Introduction Congratulations on the purchase of the URC-1625. The URC-1625 is a replacement remote control that can be set up to control 2 devices. - sat - Satellite Receiver, Digital Box or Cable Box - tv - Television, Plasma- or LCD TV The URC-1625 is preprogrammed to control your SKY DigiBox (no set up required).

  • Page 3: The Keypad

    The red LED (Light Emitting Diode) underneath the sat key will light up every time a key is pressed in sat mode. As default: when in “sat” mode your URC-1625 will be set to control your SKY digiBox. tv (LED) - device key for: Television, LCD, Plasma, Projector or Rear Projector.
  • Page 4 If your original remote has an 20 key, this function can be found under the AV key. magic Key The magic key is used to set up your URC-1625. tv/sat Key In tv mode you will obtain the AV / Input function. In sat mode you will obtain the “TV/SAT”...

  • Page 5: Setting Up The Urc-1625

    Codes are listed by device type and brand name. The most popular code is listed first. Make sure your device is switched on (not on standby). Press the tv key on the URC-1625 for the device you wish to Set-Up. Press and hold down the magic key...

  • Page 6: Search Method

    The Search Method If your device does not respond to the URC-1625 after you have tried all the codes listed for your brand, try searching for your code. The Search Method allows you to find the code for your device by scanning through all the codes contained in the memory of the URC-1625.

  • Page 7: Sat

    Code Blink out (To find out which code is currently programmed) Once you have Set-Up your URC-1625, you can blink back your SET-UP CODE for future reference. Example: To blink out your Television code: Press tv once. Press and hold down the magic key...

  • Page 8: Volume Punch-Through

    When controlling your Set-Top-Box (e.g. Sky digiBox) you normally need to press the “tv” button first if you wish to control the volume for your Television. The URC-1625 gives you the possibility to punch though TV-VOLUME without pressing the tv mode key. This is only possible if you have programmed the URC-1625 to also control your Television.

  • Page 9: Trouble-Shooting

    A) Try all the codes listed for not operate your your brand. B) Try the search device(s)? method on page 6. The ONE FOR ALL is not You may be using the wrong performing commands code. Try repeating the Direct properly?

  • Page 10: Tv : Television / Lcd / Plasma / Projector / Rear Projector

    Ardem 0486 0714 0037 0633 0556 Arena 0037 Aristona 0556 0037 Arthur Martin 0163 0105 0346 0070 0104 0087 0163 A.R. Systems 0037 0352 0556 0374 Asberg 0037 0556 0102 0455 Asora 0009 Accent 0009 0037 0556 Astra 0037 0556 Adcom 0625 Asuka...
  • Page 11 Blue Sky 0037 0714 1037 0487 Continental 0668 0715 1909 0556 Edison 0109 0287 0487 0218 0282 0455 1934 Cosmel 0009 0337 0037 0556 1904 1908 1191 0808 Crosley 0087 0247 0074 0084 1916 1243 0163 Blue Star 0282 Crown 0009 0712 0370 0486 Bondstec 0247...
  • Page 12 Dual 0349 0217 0037 0556 Finlandia 0208 0346 0548 0361 0259 0352 0394 0163 0163 0363 0072 0287 1904 1137 0631 1149 0045 1037 Finlux 0105 0104 0037 0556 Dumont 0087 0104 0102 0217 0714 0346 0217 0072 0070 0072 1904 0163 0516 0715 0070 Dunai 0163...
  • Page 13 GoldStar 0037 0009 0370 0001 Hisawa 0282 0218 0455 0610 0290 0377 0217 0178 1908 0714 0247 0216 0556 0163 HISense 0848 0208 0698 0891 0361 0109 0363 0606 0860 0044 1934 0714 0715 0087 0455 Hitachi 0225 1225 0349 0578 Gooding 0487 0036 0356 0044 0108...
  • Page 14 0037 0371 0218 0282 Lemair 0411 0264 0216 0009 0556 Lenco 0037 0721 0009 0163 0163 0480 0349 0361 0374 0556 0104 0587 0473 0548 0193 0346 1037 0339 0208 0610 Lenoir 0009 ITT Nokia 0361 0548 0163 0473 Lenoxx 1189 0480 0349 0346 0208 Lesa...
  • Page 15 Maxdorf 0773 0698 0706 0264 0170 0587 1170 0036 Maxim 1982 1556 0320 0455 0009 0374 0009 0217 0037 0556 0011 Mediator 0037 0556 0704 0245 1704 0499 Medion 0037 0714 0808 0668 0653 0771 0661 0705 0556 0512 1137 0698 Neckermann 0037 0191 0370 1505 1908 1037 1437 1900...
  • Page 16 Otto Versand 1505 1010 0036 0093 Profex 0009 0163 0361 0363 0512 0037 0556 0535 Profi 0009 0195 0349 0554 0191 Profitronic 0037 0556 0102 0361 0109 0226 0247 Proline 0037 0556 0625 0634 0320 0217 0009 0282 0630 0411 0321 0072 0516 0621 Pace...
  • Page 17 Royal Lux 0370 0412 0335 Shanghai 0848 Rukopir 0556 0037 Sharp 0093 1193 0157 0036 S-Media 1217 0491 0653 0256 0193 Saba 0625 0109 0560 0287 0516 0200 0760 1393 0087 0163 0516 0361 1163 0498 0335 0548 0650 Shintoshi 0037 0556 0714 Shivaki...
  • Page 18 Stylandia 0217 Telefunken 0625 0560 0074 0587 Sunic Line 0037 0556 0109 0698 0712 0498 Sunkai 0355 0321 0455 0218 0820 0896 0754 0780 0610 0037 0556 0487 0287 0891 0084 0819 0865 0335 0073 1243 0037 Sunstar 0371 0037 0556 0009 0556 0486 0714 1556 0264 0346 0821...
  • Page 19 TRANS- Weltstar 1037 continents 0668 1037 0865 0556 Weston 0037 0556 0037 0621 0486 0217 Wharfedale 0037 0861 0896 0891 Transonic 0037 0556 0455 0587 0556 0860 0698 1556 0512 0264 0698 0712 0706 1988 0418 0009 White Transtec 0216 Westinghouse 0320 0216 0037 0556 Triad 0037 0556 0218 0009...
  • Page 20 Astro 0133 0173 0658 1113 Discovery 0710 1099 1100 0200 0292 Distratel 1205 1283 1273 Distrisat 0200 Atlantic 1075 Telephone 1333 0200 Audioline 1429 Dream Aurora 0879 0642 1333 1433 Multimedia 1237 1537 1637 1437 Austar 1259 0863 0642 0497 1651 1652 0879 1176 1173 DStv...
  • Page 21 Hirschmann 1111 0882 1113 0173 MediaSat 0292 0853 0573 1085 0299 1232 MediaStar 1173 0710 0125 1412 Medion 1232 0299 0713 1043 Hitachi 1284 0132 1075 1412 1626 1232 0132 1334 Homecast 1214 1680 Medison 0713 Humax 1176 1665 1427 1675 Mega 0200 1225 0863 1568 1648...
  • Page 22 Philips 0099 1114 0200 0853 Sky XL 1412 1251 0133 0292 0818 1672 SKY+ 1175 0750 0710 0173 1076 Skymaster 0713 1409 1200 1085 1429 1075 0587 1611 1334 Phoenix 1273 Skymax 0200 1413 Phonotrend 0863 1017 1200 1472 Skypex 0299 Pilotime 1339...

  • Page 23: Cbl : Cable Converter / Set-Top-Box / Dvb-C

    Topfield 1206 1208 1207 1545 Melita 0003 Toshiba 1446 1284 MNet 0443 0019 0820 1253 1307 Motorola 0276 1106 1483 Triax 0200 0713 0853 1251 Mr Zap 1112 0114 1296 1291 0132 Multichoice 0019 0443 1474 1099 1113 1227 Nokia 1569 1594 1626 1611 1413 Noos...
  • Page 24 English UNIVERSAL ELECTRONICS INC./ONE FOR ALL warrants to the original purchaser that this product will be free from defects in materials and workmanship under normal and correct use for a period of one (1) year from the date of original purchase. This product will be replaced free of charge if it has been proven to be defective within the one (1) year warranty period.
