Vecom ECS-8000 User Manual

Intel quad core i7 (broadwell-h) fanless embedded system high performance, rugged, extended temp, power protection
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ECS-8000
Intel
®
Quad Core™ i7 (Broadwell-H) Fanless Embedded System
High Performance, Rugged, Extended Temp, Power Protection
USER
USER
Manual
Manual
1.0.0 Edition 20160311

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECS-8000 and is the answer not in the manual?

Questions and answers

Related Manuals for Vecom ECS-8000

Summary of Contents for Vecom ECS-8000

  • Page 1 USER USER ECS-8000 Manual Manual Intel ® Quad Core™ i7 (Broadwell-H) Fanless Embedded System High Performance, Rugged, Extended Temp, Power Protection 1.0.0 Edition 20160311...
  • Page 2 Record of Revision Version Date Page Description Remark 02/26/2016 Preliminary Release 03/11/2016 Office Release...

  • Page 3: Declaration Of Conformity

    Declaimer This manual is released by Vecow Co., Ltd. for reference purpose only. All product offerings and specifications are subject to change without prior notice. It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation, nor for any infringements upon the rights of third parties, which may result from such use.
  • Page 4 Order Information Part Number Description ® ECS-8000- ECS-8000 Fanless Embedded System, Quad Core 5th Gen Intel PoER850Q Core™ i7-5850EQ Processor (Broadwell-H), 6 GbE LAN with 4 , 2 Front-access SSD Tray, 4 COM, 7 USB, 2 SIM, Isolated DIO, 16 GPIO ®...

  • Page 5: Optional Accessories

    Optional Accessories Part Number Description M340L-W28M1 Vecow DDR3L 4GB 1333/1066 MHz RAM, Wide Temperature -40°C to +85°C DDR3L8G Certified DDR3L-1600 8G RAM DDR3L4G Certified DDR3L-1600 4G RAM PWA-120W 120W, 24V, 90VAC to 264VAC Power Adapter with 3-pin Terminal Block PWA-120WM4P 120W, 24V, 90VAC to 264VAC Power Adaptor with 4-pin Mini-DIN Connector PWA-160W-WT...

  • Page 6: Table Of Contents

    1.5.1 Dimensions of ECS-8000-PoER 1.5.2 Dimensions of ECS-8000-PoE 1.5.3 Dimensions of ECS-8000-2G 1.5.4 Dimensions of ECS-8000-2R CHAPTER 2 GETTING TO KNOW YOUR ECS-8000 2.1 Packing List 2.2 Front Panel I/O Functions 2.3 Rear Panel I/O and Functions 2.4 Main Board Expansion Connectors 2.5 Main Board Jumper Settings...
  • Page 7 3.2 Installing DDR3L SO-DIMM Modules 3.3 Installing Mini PCIe Cards 3.4 Installing Antenna Cable 3.5 Installing CFast Card and SIM Card 3.6 Installing SSD/HDD 3.6.1 ECS-8000-PoER/ ECS-8000-2R 3.6.2 ECS-8000-PoE/ ECS-8000-2G 3.7 Mounting ECS-8000 CHAPTER 4 BIOS AND DRIVER SETTING 4.1 BIOS Settings 4.2 Main Menu...

  • Page 8: Chapter 1 General Introduction

    16-mode configurable ignition power control, all-in-one, cable-less, single board design, fanless design and -25°C to 70°C operating temperature, optional supports SUMIT expansion, ECS-8000 is ready to meet your project requirements. Vecow ECS-8000 Series high performance Fanless Embedded System delivers...

  • Page 9: Features

    • 2 Front-access 2.5" HDD/ SSD Tray • 4 COM RS-232/ 422/ 485, 4 USB 3.0, 3 USB 2.0 • 6V to 36V DC-in with 80V Surge Protection • Configurable Ignition Power Control 1.3 Product Specification 1.3.1 Specifications of ECS-8000-PoER System ® Processor Quad Core Intel Core™...
  • Page 10 Interface • VGA : Up to 1920 x 1200 @ 60Hz • DVI-D : Up to 1920 x 1080 @ 60Hz • DisplayPort 1 : Up to 4096 x 2304 @ 60Hz • DisplayPort 2 : Up to 4096 x 2304 @ 60Hz •...

  • Page 11: Specifications Of Ecs-8000-Poe

    • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN 50155, EN 50121-3-2 1.3.2 Specifications of ECS-8000-PoE System ® Processor Quad Core Intel Core™ i7-5850EQ/ i7-5700EQ (Broadwell-H) ®...
  • Page 12 Graphics ® Graphics Processor • Intel Iris Pro Graphics 6200 (5850EQ) ® • Intel HD Graphics 5600 (5700EQ) Interface • VGA : Up to 1920 x 1200 @ 60Hz • DVI-D : Up to 1920 x 1080 @ 60Hz • DisplayPort 1 : Up to 4096 x 2304 @ 60Hz •...

  • Page 13: Specifications Of Ecs-8000-2G

    • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN 50155, EN 50121-3-2 1.3.3 Specifications of ECS-8000-2G System ® Processor Quad Core Intel Core™ i7-5850EQ/ i7-5700EQ (Broadwell-H) ®...
  • Page 14 Expansion Mini PCIe 3 Mini PCIe Socket : • 2 Mini PCIe for PCIe/ USB/ External SIM Card/ mSATA • 1 Mini PCIe for PCIe/ USB SUMIT A, B 2 SUMIT Slot (Optional) Graphics ® Graphics Processor • Intel Iris Pro Graphics 6200 (5850EQ) ®...
  • Page 15 95% at 70°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN 50155, EN 50121-3-2 ©Vecow ECS-8000 User Manual GENERAL INTRODUCTION...

  • Page 16: Specifications Of Ecs-8000-2R

    1.3.4 Specifications of ECS-8000-2R System ® Processor Quad Core Intel Core™ i7-5850EQ/ i7-5700EQ (Broadwell-H) ® Chipset Intel QM87 BIOS IT8786E Memory • DDR3L 1600 MHz SO-DIMM, up to 32GB • 2 204-pin SO-DIMM Socket I/O Interface Serial 4 COM RS-232/ 422/ 485 •...
  • Page 17 95% at 70°C Shock • IEC 60068-2-27 • SSD : 50G @ wallmount, Half-sine, 11ms Vibration • IEC 60068-2-64 • SSD : 5Grms, 5Hz to 500Hz, 3 Axis CE, FCC, EN 50155, EN 50121-3-2 ©Vecow ECS-8000 User Manual GENERAL INTRODUCTION...

  • Page 18: Supported Cpu List

    1.4 Supported CPU List CPU Name Cache Max. Frequency Embedded i7-5950HQ 47 W Up to 3.80 GHz i7-5850HQ 47 W Up to 3.60 GHz i7-5850EQ 47 W Up to 3.40 GHz i7-5750HQ 47 W Up to 3.50 GHz i7-5700HQ 47 W Up to 3.50 GHz i5-5700EQ 47 W...

  • Page 19: Mechanical Dimensions

    1.5 Mechanical Dimensions 1.5.1 Dimensions of ECS-8000-PoER Unit: mm (inch) 297,0 (11,7) 282,0 (11,1) 297,0 (11,7) 260,0 (10,2) 1.5.2 Dimensions of ECS-8000-PoE Unit: mm (inch) 297,0 (11,7) 282,0 (11,1) 297,0 (11,7) 260,0 (10,2] ©Vecow ECS-8000 User Manual GENERAL INTRODUCTION...

  • Page 20: Dimensions Of Ecs-8000-2G

    1.5.3 Dimensions of ECS-8000-2G Unit: mm (inch) 297,0 (11,7) 282,0 (11,1) 297,0 (11,7) 260,0 (10,2) 1.5.4 Dimensions of ECS-8000-2R Unit: mm (inch) 297,0 (11,7) 282,0 (11,1) 297,0 (11,7) 260,0 (10,2) GENERAL INTRODUCTION...

  • Page 21: Chapter 2 Getting To Know Your Ecs-8000

    ● HDD Tray Key 2.2 Front Panel I/O Functions In Vecow ECS-8000 series family, all I/O connectors are located on front panel and rear panel. Most of the general connections to computer device, such as USB, DVI-D, DisplayPort and any additional storage, are placed on the front panel.

  • Page 22: Power Button

    WLAN WWAN CFast It is a hardware reset switch. Use this switch to reset the system without power off the ECS-8000. Press the Reset Switch for a few seconds, then reset will be enabled. 2.2.2 Power Button Reset SIM 1...
  • Page 23 It is implemented by a SATA II Port from Broadwell-H PCH. Be sure to disconnect the power source and unscrew the CFast socket cover before installing a CFast card. The ECS-8000 does not support the CFast hot swap and PnP (Plug and Play) functions. It is necessary to remove power source first before inserting or removing the CFast card.
  • Page 24 Reset DVI-D LAN 2 LAN 1 SIM 1 SIM 2 WLAN WWAN CFast The DVI-D connector on the front panel supports DVI display modes. The DVI output mode supports up to 1920 x 1080 resolutions. GETTING TO KNOW YOUR ECS-8000...

  • Page 25: Vga Connector

    V-Sync. Ground DDC-CLK Ground 2.2.7 DisplayPort Reset DVI-D LAN 2 LAN 1 SIM 1 SIM 2 WLAN WWAN CFast Onboard DisplayPort connection supports up to 4096 x 2304 resolutions at 60 ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 26 There are 2 USB 3.0 connections available supporting up to 5GB per second data rate in the front side of ECS-8000. It also compliant with the requirements of SuperSpeed (SS), high speed (HS), full speed (FS) and low speed (LS).
  • Page 27 WWAN CFast There are 2 8-pin RJ-45 jacks supporting 10/ 100/1000 Mbps Ethernet connections in the front side and rear side of ECS-8000. LAN 1 is powered by ® Intel I218LM Ethernet engine; LAN 2 is powered by Intel I210 Ethernet engine.

  • Page 28: Audio Connector

    LAN 1 SIM 1 SIM 2 WLAN WWAN CFast There are 2 front-access 2.5” SSD/ HDD trays in the front side of ECS-8000. Just trigger to open the SSD/ HDD tray, up to 4TB is available. GETTING TO KNOW YOUR ECS-8000...

  • Page 29: Rear Panel I/O And Functions

    LAN 6 On / Off Power Switch ECS-8000 supports 6V to 36V DC power input by terminal block in the rear side. In normal power operation, power LED lightens in solid green. ECS-8000 supports up to 80V surge protection. Pin No.
  • Page 30 OUTPUT 0 INPUT 1 OUTPUT 1 INPUT 2 OUTPUT 2 INPUT 3 OUTPUT 3 INPUT 4 OUTPUT 4 INPUT 5 OUTPUT 5 INPUT 6 OUTPUT 6 INPUT 7 OUTPUT 7 DI_COM DIO_GND DIO_GND External 24~78VDC Input GETTING TO KNOW YOUR ECS-8000...
  • Page 31 GPI SOURCE Mode Digital GPI input signal circuit in SOURCE mode (PNP) is illustrated as follow : GPO SINK Mode Digital GPO output circuit in SINK mode (NPN) is illustrated as follow : ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 32 RS-422 RS-422 RS-485 Port (5-wire) (9-wire) (3-wire) TXD- TXD- DATA- TXD+ TXD+ DATA+ RXD+ RXD+ ----------- 1, 2 RXD- RXD- ----------- 3, 4 ----------- RTS- ----------- ----------- RTS+ ----------- ----------- CTS+ ----------- ----------- CTS- ----------- GETTING TO KNOW YOUR ECS-8000...
  • Page 33 LAN 6 On / Off Power Switch There are 4 RJ45 connectors in the rear side of ECS-8000. It supports IEEE 802.3at (PoE ) Power over Ethernet (PoE) connection delivering up to 25.5W/ 48V per port and 1000BASE-T gigabit data signals over standard Ethernet Cat 5/ Cat 6 cable.

  • Page 34: Main Board Expansion Connectors

    2.4 Main Board Expansion Connectors 2.4.1 Top View of ECS-8000 Main Board With Connector Location FAN1 CN10 CN11 CN12 CN13 CN15 CN14 CN16 Battery CN18 BIOS CN19 CN20 CN22 CN27 CN24 2.4.2 Bottom View of ECS-8000 Main Board With Connector Location...
  • Page 35 The pinouts of Miscellaneous port are listed in following table: Group Pin No. Description HDD_LED_P HDD LED HDD_LED_N FP_RST_BTN_N RESET BUTTON PWR_LED_P POWER LED PWR_LED_N FP_PWR_BTN_IN POWER BUTTON ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 36 2.4.4 CN16, CN18 eDP CN16 CN18 ECS-8000 supports eDP display, up to 4096 x 2304 pixels resolution. The pin assignments of CN18 are listed in the following table: Pin No. Definition Pin No. Definition +V3P3S_DP_EMB (+5V / +3.3V) VSS_EDP_AMOLED N.C.
  • Page 37 The LCD inverter is connected to CN16 via a 2x5-pin, 2.0mm pin header providing backlight control. The pin assignments are listed in the following table: Pin No. Definition Pin No. Definition LVDS_VDD_EN L_BKLT_EN N.C. L_BRIGHTNESS EDP_UTIL_LS N.C. N.C. ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 38 2.4.5 CN9, CN10 : SATA III Connector CN10 There are 2 onboard high performance Serial ATA III (SATA III) on ECS-8000. It supports higher storage capacity with less cabling effort and smaller required space. The pin assignments of CN9 and CN10 are listed in the following table: Pin No.
  • Page 39 2.4.6 CN14 : SATA II Connector CN14 There is a onboard high performance Serial ATA II (SATA II) on ECS-8000. It supports higher storage capacity with less cabling effort and smaller required space. The pin assignments of CN14 are listed in the following table: Pin No.
  • Page 40 2.4.7 CN11 : SATA Power Connector CN11 The ECS-8000 also equip with a SATA power connector. It supports 5V (Up to 4A) and 12V (Up to 2A) current to the hard drive or SSD. The pin assignments of CN11 are listed in the following table: Connector Pin No.
  • Page 41 2.4.8 CN12 : Internal USB CN12 The ECS-8000 main board provide one expansion USB port using plug-and- play for Dongle Key or LCD touch Panel. The USB interface supports 480 Mbps transfer rate which comply with high speed USB specification Rev. 2.0.
  • Page 42 DIP Switch SW 4-1 DIP Switch SW 4-2 Interface *Auto Detection CN27 Mini PCI-E (Forced) mSATA (Forced) Mini PCIe DIP Switch SW 1-1 DIP Switch SW 1-2 Interface *Auto Detection CN15 Mini PCI-E (Forced) mSATA (Forced) GETTING TO KNOW YOUR ECS-8000...
  • Page 43 Reserved +3.3Vaux USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V PERp0 PERn0 +3.3Vaux PERST# Reserved reserved Reserved Mechanical Key UIM_VPP REFCLK+ UIM_RESET REFCLK- UIM_CLK UIM_DATA CLKREQ# UIM_PWR Reserved 1.5V Reserved WAKE# 3.3Vaux ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 44 The pin assignments of CN19 are listed in the following table: Pin No. Signal Name Pin No. Signal Name Reserved +3.3Vaux Reserved Reserved +1.5V Reserved Reserved Reserved +3.3Vaux Reserved +3.3Vaux USB_D+ USB_D- PETp0 PETn0 SMB_DATA SMB_CLK +1.5V GETTING TO KNOW YOUR ECS-8000...
  • Page 45 2.4.10 Battery Battery The ECS-8000’s real-time clock is powered by a lithium battery. It is Equipped with Panasonic BR2032 190mAh lithium battery. It is recommended that you not replace the lithium battery on your own. If the battery needs to be changed, please contact the Vecow RMA service team.
  • Page 46 2.4.12 J6 : LAN2 I210 SDP The pin assignments of J6 are listed in the following table: Pin No. Function Pin No. Function LAN2_SDP0 LAN2_SDP3 LAN2_SDP1 LAN2_SDP2 GETTING TO KNOW YOUR ECS-8000...
  • Page 47 2.4.13 CN13 : GPIO CN13 The ECS-8000 offers 16 programmable I/O within TTL 5V (1mA max. /pin) tolerance. If the GPIO is logic high, it indicates that the mapping SIO GPIO pin is logic high level. If the GPIO is logic low, it indicates that the mapping SIO GPIO pin is logic low level.
  • Page 48 2.4.14 FAN 1 FAN1 Fan power connector supports for additional thermal requirements. The pin assignments of FAN 1 are listed in the following table: Pin No. Function Pin No. Function Fan speed sensor +12V (1.5A max) GETTING TO KNOW YOUR ECS-8000...
  • Page 49 2.4.15 J4 : SGPIO The pin assignments of J4 are listed in the following table: Pin No. Function Pin No. Function SCLOCK SDATA_OUT0 SDATA_OUT1 SLOAD ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 50 2.4.16 J7 : MCU Spy-bi wire Interface For download FW The pin assignments of J7 are listed in the following table: Pin No. Function Pin No. Function 3.3V_MCU MCU_RST# MCU_PRG GETTING TO KNOW YOUR ECS-8000...
  • Page 51 2.4.17 CN20, CN24 SUMMIT CN20 CN24 ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 52 Reserved SPI_MISO USB_OC# SPI_MOSI Reserved SPI_CLK SPI_CS10 USB_3+ SPI_CS1# USB_3- Reserved LPC_DRQ1# USB_2+ LPC_AD0 USB_2- LPC_AD1 LPC_AD2 USB_1+ LPC_AD3 USB_1- LPC_FRAME# SERIRQ# USB_0+ Reserved USB_0- CLK_33MHz A_PET_P0 A_PER_P0 A_PET_N0 A_PER_N0 APRSNT#/A_PE_CLKREQ# PERST# A_CLKP WAKE# A_CLKN GETTING TO KNOW YOUR ECS-8000...
  • Page 53 B_PER_N0 C_CLKP B_CLKP C_CLKN B_CLKN CPRSNT#/C_PE_CLKREQ# C_PET_P0 C_PER_P0 C_PET_N0 C_PER_N0 C_PET_P1 C_PER_P1 C_PET_N1 C_PER_N1 C_PET_P2 C_PER_P2 C_PET_N2 C_PER_N2 C_PET_P3 C_PER_P3 C_PET_N3 C_PER_N3 PERST# WAKE# Reserved Reserved Reserved +3.3V +3.3V +3.3V +5V_AUX ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 54 The pinouts of LEDs port are listed in following table: Pin No. Function Pin No. Function POE_LED_LAN6 POE_LED_LAN4 GND_POE GND_POE POE_LED_LAN5 POE_LED_LAN3 GND_POE GND_POE Note: Do not connect GND_POE to Digital Ground (GND) GETTING TO KNOW YOUR ECS-8000...
  • Page 55 Connector Pin No. Description Pin No. Description LAN3_LINK100# LAN3_ACT# LAN4_LINK100# LAN4_ACT# LAN3_LINK1000# +V3P3_SB LAN4_LINK1000# +V3P3_SB Connector Pin No. Description Pin No. Description LAN5_LINK100# LAN5_ACT# LAN6_LINK100# LAN6_ACT# LAN5_LINK1000# +V3P3_SB LAN6_LINK1000# +V3P3_SB ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 56 2.4.20 J9: LPC Port 80 Debug Port The pin assignments of J9 are listed in the following table: Pin No. Function Pin No. Function INT_SERIRQ PCH_LFRAME_N +3.3V (0.5A max.) PCH_LPC_LAD0 PCH_LPC_LAD3 Mechanical Key PLTRST_SIO# PCH_LPC_LAD1 CLK_PORT80_33M PCH_LPC_LAD2 GETTING TO KNOW YOUR ECS-8000...

  • Page 57: Main Board Jumper Settings

    2.5 Main Board Jumper Settings 2.5.1 Front View of ECS-8000 Main Board with Jumper Location The figure below is the top view of the ECS-8000 main board which is the main board used in the ECS-8000 Series system. It shows the location of the jumpers.
  • Page 58 Description Header Header 1 - 2 +5V (1A max.) 1 - 2 +5V (1A max.) COM3 COM4 3 - 4 +12V (0.5A max.) 3 - 4 +12V (0.5A max.) 5 - 6 5 - 6 GETTING TO KNOW YOUR ECS-8000...
  • Page 59 JP5 provides LVDS voltage selection function, closing Pin 1, 2 is for 3.3V LVDS power input; closing Pin 2, 3 is for 5V LVDS power input. Pin No. Function Pin No. Function +3.3V (Default) ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 60 DIP Switch SW 6-3 Description Enable eDP Enable *Disable Function DIP Switch SW 6-4 Description Disable Front USB3.0 / USB2.0 Wake Up *Enable Function DIP Switch SW 6-5 Description Disable Rear USB3.0 Wake Up *Enable GETTING TO KNOW YOUR ECS-8000...
  • Page 61 Description *Enable COM2 RS-422/485 Receiver Terminator Disable Function DIP Switch SW 3-1 Description *Enable COM3 RS-422/485 Receiver Terminator Disable Function DIP Switch SW 3-2 Description *Enable COM4 RS-422/485 Receiver Terminator Disable ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 62 Mini PCIe / mSATA Description SW 4-1 SW 4-2 *Auto Detection CN27 Mini PCI-E (Forced) mSATA (Forced) DIP Switch Mini PCIe / mSATA Description SW 1-1 SW 1-2 *Auto Detection CN15 Mini PCI-E (Forced) mSATA (Forced) GETTING TO KNOW YOUR ECS-8000...

  • Page 63: Ignition Control

    2.6 Ignition Control ECS-8000 series provides ignition power control feature for in-vehicle applications. The built-in MCU monitors the ignition signal and turns on/ off the system according to pre-defined on/ off delay period. ©Vecow ECS-8000 User Manual GETTING TO KNOW YOUR ECS-8000...
  • Page 64 2.6.1 Adjust Ignition Control Modes ECS-8000 series provides 16 modes of different power on/ off delay periods adjustable via rotary switch. The default rotary switch is set to 0 in ATX/ AT power mode. The modes are listed in below table:...
  • Page 65 Note: 1. DC power source and IGN share the same ground. 2. ECS-8000 supports 6V to 36V wide range DC power input in ATX/AT mode. In Ignition mode, the input voltage is fixed to 12/24/36V for car battery scenario.

  • Page 66: Chapter 3 System Setup

    SYSTEM SETUP “Please make sure to assemble the system in an anti-static environment.” 3.1 How to Open Your ECS-8000 3.1.1 ECS-8000-PoER/ ECS-8000-2R Step 1 Remove 6 pcs KHS #6-32 screws with front panel. Step 2 Take off the front panel.
  • Page 67 Step 3 Remove 5 pcs KHS #6-32 screws with rear panel. Step 4 Remove 4pcs F#6-32(red) screws. ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...

  • Page 68: Ecs-8000-Poe/ Ecs-8000-2G

    Step 5 Finish. 3.1.2 ECS-8000-PoE/ ECS-8000-2G Step 1 Remove 6 pcs KHS #6-32 screws with front panel. HARDWARE INSTALLATION...
  • Page 69 Step 2 Take off the front panel. Step 3 Remove 5 pcs KHS #6-32 screws with rear panel. Step 4 Remove 1 pcs M3x6 (red) and 4 pcs F#6-32 (blue) screws. ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...
  • Page 70 Step 5 Take off SSD/HDD cover and bottom cover, be careful SATA cable. Step 6 Finish. HARDWARE INSTALLATION...

  • Page 71: Installing Ddr3L So-Dimm Modules

    3.2 Installing DDR3L SO-DIMM Modules Step 1 Install DDR3L RAM module into SO-DIMM slot. (ECS-8000-PoER/ ECS-8000-PoE/ ECS-8000-2G/ ECS-8000-2R) Step 2 Make sure the RAM module is locked by the memory slot. (ECS-8000-PoER/ ECS-8000-PoE/ ECS-8000-2G/ ECS-8000-2R) ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...

  • Page 72: Installing Mini Pcie Cards

    3.3 Installing Mini PCIe Cards Step 1 Install Mini PCIe card into the Mini PCIe slot. (ECS-8000-PoER/ ECS-8000-PoE/ ECS-8000-2G/ ECS-8000-2R) Step 2 Fasten M2.5 screws. (ECS-8000-PoER/ ECS-8000-PoE/ ECS-8000-2G/ ECS-8000-2R) HARDWARE INSTALLATION...

  • Page 73: Installing Antenna Cable

    3.4 Installing Antenna Cable Step 1 Check Antenna cable and washers. Step 2 Remove 3pcs rubber cork on rear panel. (Pick up the location you want) ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...
  • Page 74 Step 3 Put Antenna cable connector into the hole on rear panel. Step 4 Fasten the washer 1, washer 2 and washer 3 on Antenna cable connector. Step 5 Antenna cable is installed ready. HARDWARE INSTALLATION...

  • Page 75: Installing Cfast Card And Sim Card

    3.5 Installing CFast Card and SIM Card Step 1 Remove 2pcs M3x4 Flat head screws on CFast & SIM Card cover on front panel. Step 2 Remove CFast Card and SIM Card cover from front panel. ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...
  • Page 76 Step 3 Before Inserting CFast & SIM Card, make sure the system power is not plugged. Step 4 Insert CFast & SIM Card, push to lock. HARDWARE INSTALLATION...

  • Page 77: Installing Ssd/Hdd

    3.6 Installing SSD/HDD 3.6.1 ECS-8000-PoER/ ECS-8000-2R Step 1 Open the SSD/ HDD tray on the ECS-8000 front panel. Step 2 Put on the SSD/HDD. Step 3 Push the tray panel with locked. ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...

  • Page 78: Ecs-8000-Poe/ Ecs-8000-2G

    Step 4 Have a key can fasten the tray. Close Open 3.6.2 ECS-8000-PoE/ ECS-8000-2G Step 1 Remove M3x6 screws for SSD/ HDD cover. Step 2 Insert 2.5” SSD/ HDD in the tray then match SSD/ HDD bracket with screw hole.
  • Page 79 Step 3 Locked 8 pcs M3 screws in SSD/ HDD screw hole. Step 4 Insert SATA cable with SSD/ HDD. ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...
  • Page 80 Step 5 Close the SSD/ HDD cover. Step 6 Fasten M3x6 screw with SSD/HDD cover. HARDWARE INSTALLATION...

  • Page 81: Mounting Ecs-8000

    3.7 Mounting ECS-8000 Step 1 Ensure the screw holes on the right and left side of upper case match the ones on ECS-8000 wallmount bracket. Step 2 Fasten 4pcs KHS#6-32 screws. ©Vecow ECS-8000 User Manual HARDWARE INSTALLATION...

  • Page 82: Chapter 4 Bios And Driver Setting

    BIOS AND DRIVER SETTING 4.1 BIOS Settings The board uses UEFI BIOS that is use Serial Peripheral Interface (SPI) Flash. The SPI Flash contains the BIOS Setup program, POST, the PCI auto- configuration utility, LAN, EEPROM information, and Serial port support. The BIOS setup program is accessed by pressing the <Del>...

  • Page 83: Advanced Function

    This system support ACPI function as auto process. You should Enable/ Disable that depend as your OS. Enable Hibernation It is able to use Hibernate function if OS support. But some OS may not be effective with this function. BIOS AND DRIVER SETTING ©Vecow ECS-8000 User Manual...

  • Page 84: Cpu Configuration

    4.3.2 CPU Configuration Figure 4-3-2: CPU Configuration setup screen Intel Virtualization Technology This for Virtualization Application or platform usage, when enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology. 4.3.3 SATA Configuration Figure 4-3-3 : SATA Configuration setup screen BIOS AND DRIVER SETTING...

  • Page 85: Amt Configuration

    This system offers six SATA ports for connection SATA device. 4.3.4 AMT Configuration Figure 4-3-4: AMT Setup screen Intel AMT ® Enables or Disables Intel Active Management Technology BIOS extension. This option just controls the BIOS extension executes. BIOS AND DRIVER SETTING ©Vecow ECS-8000 User Manual...

  • Page 86: Serial Port 1 Configuration

    4.3.5 Serial Port 1 Configuration Figure 4-3-5 : Serial Port 1 Setup screen Serial Port Enable or Disable Serial Port. Device Setting Current IO address and interrupt resource of Serial Port. Change Settings Select another device setting. There are 6 options as follow : •...

  • Page 87: Serial Port 2 Configuration

    IO=3F8h; IRQ=3,4,10,11; • IO=2F8h; IRQ=3,4,10,11; • IO=3E8h; IRQ=3,4,10,11; • IO=2E8h; IRQ=3,4,10,11; Interface Mode There are 4 options as follow : • RS-232 Mode • RS-422 Mode • RS-485 Mode • Loop Back BIOS AND DRIVER SETTING ©Vecow ECS-8000 User Manual...

  • Page 88: Serial Port 3 Configuration

    4.3.7 Serial Port 3 Configuration Figure 4-3-7 : Serial Port 3 Setup screen Serial Port Enable or Disable Serial Port. Device Setting Current IO address and interrupt resource of Serial Port. Change Settings Select another device setting. There are 6 options as follow : •...
  • Page 89 IO=3E8h; IRQ=3,4,10,11; • IO=2E8h; IRQ=3,4,10,11; • IO=2F0h; IRQ=3,4,10,11; • IO=2E0h; IRQ=3,4,10,11; Interface Mode There are 4 options as follow : • RS-232 Mode • RS-422 Mode • RS-485 Mode • Loop Back BIOS AND DRIVER SETTING ©Vecow ECS-8000 User Manual...

  • Page 90: Chipset Function

    4.4 Chipset Function Figure 4-4: Chipset Function Setup screen Chipset related options for this platform. 4.4.1 WOL Configuration Figure 4-4-1 : Network Setup screen PCH LAN Controller Enable or Disable on board network device. Wake on LAN Enable or Disable integrated LAN to wake the system. BIOS AND DRIVER SETTING...

  • Page 91: Boot Function

    4.5 Boot Function Figure 4-5: Boot function Setup screen 4.5.1 Boot Option Figure 4-5-1 Boot Option Setup screen Boot option You can select boot device priority in this page. BIOS AND DRIVER SETTING ©Vecow ECS-8000 User Manual...

  • Page 92: Save & Exit

    4.6 Save & Exit Figure 4-6: Save & Exit Setup screen Save Changes and Exit / Save Changes and Reset Choose this setting to exit the BIOS setup program and save changes to the BIOS NVRAM memory. Make sure you select this in order to keep your changes.

  • Page 93: Appendix A : Isolated Dio Guide

    DIO Output A.2 Function Description The ECS-8000 offers a 16-bit DIO (8-DI / 8-DO) 20-pin terminal block connector. Each bit of DI and DO equipped with a photo-coupler for isolated protection. All IO pins are fixed by Hardware design and cannot change in/out direction in runtime process.
  • Page 94 Digital GPIO input signal circuit in SINK mode (NPN) is illustrated as follow. Digital GPIO input signal circuit in SOURCE mode (PNP) is illustrated as follow. Digital GPIO output signal circuit in SINK mode (NPN) is illustrated as follow. Appendix A...
  • Page 95 Please execute “64bit_driver.bat” on console window as administrator. While execute the driver install process, here shows the Security window popup. Please checked “Always trust software from : Vecow Ltd. Co” and click Install bottom go to next step. Appendix A ©Vecow ECS-8000 User Manual...
  • Page 96 In 64bit version, here have another Window for driver certified. Please agree this license to finish the install process. After driver install process complete , you must restart system to get DIO driver actived. Appendix A...

  • Page 97: Appendix B : Gpio And Wdt Functions

    I/O special data port, 0x07); 3. Config the WDT Register outb(WDT_Config,SPECIAL_ADDRESS_PORT); outb(WDT_As_Second|WDT_Pin_PWRGD,SPECIAL_DATA_PORT); 4. Start WDT TimeOut Value Here have 2 Byte for WDT timing count, MSB and LSB should be write the value separate. WDT_TimeOut_MSB,SPECIAL WDT_TimeOut_LSB,SPECIAL outb(WDT_TimeOut_LSB,SPECIAL_ADDRESS_PORT); outb(WDT_TimeOutValue,SPECIAL_DATA_PORT); Appendix B ©Vecow ECS-8000 User Manual...

  • Page 98: Appendix C : Power Consumption

    APPENDIX C : Power Consumption Testing Board ECS-8000 2 x Innodisk 16GB USB-1 USB Keyboard Logitech K120 USB-2 USB Mouse Microsoft 1113 USB-3 USB Flash Transcend 3.0 8GB USB-4 USB Flash Transcend 3.0 8GB USB-5 USB Flash Transcend 2.0 16GB USB-6 USB Flash Kingston 3.0 8GB...
  • Page 99 Current Consumption Current Consumption i7-5850EQ 2.680A 16.08W 6.220A 37.32W i7-5850EQ 1.730A 15.57W 3.960A 35.64W i7-5850EQ 1.370A 16.44W 2.970A 35.64W i7-5850EQ 0.720A 17.28W 1.500A 36.00W i7-5850EQ 0.610A 17.08W 1.280A 35.84W i7-5850EQ 0.490A 17.64W 1.040A 37.44W Appendix C ©Vecow ECS-8000 User Manual...
  • Page 100 C.2 CPU : Intel® Core™ i7-5850EQ (6M Cache, 2.60GHz) Standby Mode Input Power Max Current Max Consumption i7-5700EQ 0.390A 02.34W i7-5700EQ 0.270A 02.43W i7-5700EQ 0.230A 02.76W i7-5700EQ 0.150A 03.60W i7-5700EQ 0.130A 03.64W i7-5700EQ 0.120A 04.32W Power-on and boot to Win7 64-bit Idle Status : Run 100% CPU usage CPU usage less 3%...
  • Page 101 For further support information, please visit www.vecow.com This document is released for reference purpose only. All product offerings and specifications are subject to change without prior notice. No part of this publication may be reproduced in any form or by any means, electric, photocopying, recording or otherwise, without prior authorization of the publisher.
