Safety, Operation and
Maintenance Manual
TW411
Read these instructions carefully
before operating machinery.
To obtain the best results from you new TW 411,
please read and follow these instructions carefully.
Always use manufactures recommended cleaning
and care products with this machine. Proper care and
maintenance is recommended to keep your machine
running at optimal performance. Our experience
shows that diffi culties with the machine and poor
cleaning results, are as a direct consequence of using
non-suitable cleaning and care products.
Contents
Safety instructions .........................2
How to Operate ..............................3,4
Assembly ..........................................4
Technical Information ...................5
Parts Lists .........................................5-7
Maintenance ....................................8
Servicing ...........................................8
Contact Information ......................8
TW 411 Manual 2/12
Advertisement
Table of Contents
Related Manuals for MasterCraft TW411
Summary of Contents for MasterCraft TW411
-
Page 1: Table Of Contents
Safety, Operation and Maintenance Manual TW411 Read these instructions carefully before operating machinery. To obtain the best results from you new TW 411, please read and follow these instructions carefully. Always use manufactures recommended cleaning and care products with this machine. Proper care and maintenance is recommended to keep your machine running at optimal performance. -
Page 2: Safety Instructions
Safety Safety Instructions • Do not use the machine in direct proximity of heat sources (fi re, gas or electrical stoves etc.)! • This device is designed for commercial use, for example in hotels, schools, hospitals, factories, shops, offi ces and rental shops. •... -
Page 3: How To Operate
How to Operate Prepare the fl oor Spray extraction with heavy soiling • Before using spray extractor, vacuum carpet thoroughly. • Carry out spray/extraction a second time, in a crosswise direction if area permits. This second cleaning phase is only to be carried out on a totally dry carpet. -
Page 4: Assembly
How to Operate Assembly and usage max. max. 122° F ° MAX. .5 gal TW 411 Manual 2/12 Page 4... -
Page 5: Technical Information
Technical 1. Machine body / Clean water tank 2. Waste water tank 2a. Handle for lifting waste water tank 3. Waste water tank cover 4. Filter 5. Hopper with level indicator 6. Female quick connector for Spray hose 7. Connectors for Suction hose 8. - Page 6 Technical Cover Housing - Parts list Cover ..............043.201 Hinge pin ............043.504 Seal for cover ..........043.202 Filter ..............043.205 Cover employment ........043.204 PT-screw KA 30x16 ........P...515 F Bent tube ............043.203 PT-screw KA 30x10 ........P...515 Q Cover ..............043.502 10. PT-screw KA 50x16 ........P...515 Z 11.
- Page 7 Technical Vacuum pump parts - Parts list Fan unit complete including items..2-10 043.600 Lower jacket of motor ........043.602 Upper jacket of motor ........043.601 Suction motor ..........P...876 Pair of Charbon brushes ......— Profi le ...............043.606 Seal for motor ..........043.607 Motor sealing ring ........P...971 J Seal for motor ..........043.605 10.
-
Page 8: Maintenance
Maintenance and Servicing Daily servicing Contact Information • Drain the fresh water tank. Fill with approx. 1.5 Gal of fresh water. 777 South Street P.O. Box 3210, Hold the nozzle over a drain and fl ush the pressure pump, hose and Newburgh, NY 12550-0606 spray nozzles thoroughly.
