Page 1: Technical Data
Air Conditioning Technical Data Wall mounted unit EEDEN14-030 ATX-JV... -
Page 3: Table Of Contents
• Indoor Unit • ATX-JV TABLE OF CONTENTS ATX-JV Features ............. 2 Specifications . -
Page 4: Features
• Indoor Unit • ATX-JV Features U n i o o r - J V I n d A T X • Whisper quiet operation: down to 22dBA sound pressure level • Indoor unit silent operation: "silent" button on the remote control lowers the operation sound of the indoor unit by 3dBA •... -
Page 5: Specifications
• Indoor Unit • ATX-JV Specifications 2-1 Technical Specifications ATX20JV ATX25JV ATX35JV Power input Cooling Nom. 0.040 Heating Nom. 0.040 Casing Colour White Dimensions Unit Height/Width/ 283/770/198 Depth Packed unit Height/Width/ 345/846/266 Depth Weight Unit Packed unit Heat exchanger Length... -
Page 6: Electrical Specifications
• Indoor Unit • ATX-JV Specifications 2-1 Technical Specifications ATX20JV ATX25JV ATX35JV Temperature control Microcomputer control Air direction control Right, Left, Horizontal, Downward Air filter Type Removable / washable / mildew proof Standard Accessories : ; Quantity : Titanium apatite photocatalytic air purification filter without frame;... -
Page 7: Dimensional Drawings
• Indoor Unit • ATX-JV Dimensional drawings 3 - 1 Dimensional Drawings • Split - Sky Air • ATX-JV... -
Page 8: Centre Of Gravity
• Indoor Unit • ATX-JV Centre of gravity 4 - 1 Centre of Gravity • Split - Sky Air • ATX-JV... -
Page 9: Piping Diagrams
• Indoor Unit • ATX-JV Piping diagrams 5 - 1 Piping Diagrams • Split - Sky Air • ATX-JV... -
Page 10: Wiring Diagrams
• Indoor Unit • ATX-JV Wiring diagrams 6 - 1 Wiring Diagrams - Single Phase • Split - Sky Air • ATX-JV... -
Page 11: Sound Data
• Indoor Unit • ATX-JV Sound data 7 - 1 Sound Pressure Spectrum • Split - Sky Air • ATX-JV... - Page 12 • Indoor Unit • ATX-JV Sound data 7 - 1 Sound Pressure Spectrum • Split - Sky Air • ATX-JV...
- Page 13 All content is copy- righted by Daikin Europe N.V. Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende...
