Method of usage
Other manual function
Function Button
Calf rest lifting button, press this button, calf restlifting slowly,
Calf rise
stop when release it
and drop
Calf rest decline button, press this button, calf rest decline
slowly, stop when release it
Backrest lifting button, press this button, backrest lifting slowly,
stop when release it
Backrest rise
and drop
Backrest decline button, press this button, backrest decline
slowly, stop when release it
with three modes circulation function, when press the button,
Auto lay
turn into auto lay downmode.
down mode
3.Turn off power, stop massage
1)Press power button during massage progress, all massage function will be stop
immediately, the backrest and footrest will return to original position automatically,
meanwhile you can set up memory function. After rated working time, all massage
functions will be finished, meanwhile you can set up memory function, but
backrest and footrest won't return to original position.
2)Memory store function: After rated working time or switch off, the hand controller
displays "Memory" and glitter, remind the users whether need to store the
massage mode before turn off, you can press the memory function buttons
M1
or M2
as you like, store the massage mode.
3) Cut off the power of the whole machine.
Figure (Switch power off)
Diagram of the switch position of power supply
WARNING
Description
Power switch method map
Set with safety switch in a power supply
box, if there is heavy pressure on power
supply box, then forced stop back lying
function, prevent hurts peoplewhen lying.
12
Method of usage
4.Armrest disassembly method
Note: this method is only use for cannot easy move into small space, such as too
small room door, please do not arbitrarily disassemble.
Open the master carton, take down the calf rest. (figure 1)
Remove the back cushion (note: please ensure the heat wire in the cushion was
unplugged before remove). (figure 2)
Figure 1
Zip the backrest kneading cloth open completely, put the cloth on the top of chair
(note: please remember to prevent the kneading cloth from dirty or damage).
( figure 3)
The calf rest decoration cover is card slot design, make an effort to pull it when
disassembly. (figure 4)
Figure 3
Unscrew the 8 screws of front dam-board (NEED NOT unscrew the 4 screws on
the bottom). (figure 5)
Open the front dam-board, unplug the joint of air pipe and power cord
corresponding to armrest. (figure 6)
Figure 5
Figure 2
Pull
Figure 4
Figure 6
13
