NOTICE
When handling supplemental restraint system components (removal,
installation or inspection, etc.), always follow the direction given in the repair
manuals listed above to prevent accidents and supplemental restraint
system malfunction.
FOREWORD
This wiring diagram manual has been prepared to provide
information on the electrical system of the 1994 TOYOTA
CAMRY.
Applicable models:
For service specifications and repair procedures of the above
models other than those listed in this manual, refer to the
following manuals;
Manual Name
S 1994 CAMRY Repair Manual
S 1994 Model New Car Features
All information in this manual is based on the latest product
information at the time of publication. However, specifications
and procedures are subject to change without notice.
TOYOTA MOTOR CORPORATION
SXV10 Series
MCV10 Series
Volume 1
Volume 2
Pub. No.
RM361U1
RM361U2
NCF099U
1
