MaxiiNet VI3010 Specifications

Vi3010
Features
• All 10 Ethernet ports are 1Gbps - 8 PoE and 2 SFP ports
• 8 ports at 802.3af PoE and up to 6-ports at 802.3at (30W)
• SNMP for communicating error messaging to local computers
• Automatic IP and PoE connection and reconnection
• Automatic MAC identification for all connected devices
• Individual IP Source Guard for protecting ports
• Supports Jumbo Frames up to 9600 bytes
• High Bandwidth 20Gbyte switching fabric
• Virtual Network Switch Stacking
• Lifetime Warranty
The Vi3010 is the next generation L2+ managed switch designed for PoE+ and high Bandwidth network applications. It provides a reliable
infrastructure for your business network. The Vi3010 delivers unique intelligent features that are needed to improve the availability of your
critical business applications with unique PoE monitoring and application features. The Vi3010 can be programmed to apply PoE
individually timed to each port to lower the potential for power overload that can result in damage. Total power and PoE are monitored for
over power conditions. Programmable IP and PoE connection reduces connection failure potentials and will automatically re-establish
connections and apply PoE, reducing down time and field service calls. It can easily support any Ethernet device such as IP Phones, IP
Cameras, and Wireless base stations; thus helping you to create a more efficient, better networked workforce. Full CLI documentation is
provided for custom integration.
Vigitron Vi3010 is designed to meet the growing power and bandwidth requirements for IP security cameras by providing both reliability
and conductivity with the ability to locate and determine network system problems:
• High PoE Power Budget: Total 250W power supply with 185W PoE budget providing 8-ports at full 15.4W (802.3af) and
6-ports at full 30W (802.3at).
• Programmable Video/Data packet transmission up to the Jumbo Frame limit of 9600 bytes for transmitting the highest mega
pixel cameras at 100Mbps and 1Gps port speeds.
• Wide 20Gbps switch fabric assuring all required bandwidth, even with all ports at their maximum bandwidth assuring video and
data quality.
• Automatic connection and re-connection with PoE application for more reliable startups reducing down time potentials.
• Programmable multicasting for compatibility and performance with largest IP video network systems.
• Programmable Rapid Spanning Tree for redundant network configuration assuring maintenance of network communication
using multiple paths.
• Virtual Stacking features eliminate the need for all switches to be at the same location, while providing access to all switches
anywhere on the network using one IP address.
• Automatic MAC address detection for connected devices for easy connection verification and security programming.
• Easy port feature provides one step port settings for IP camera, VoIP and wireless connections.

Application Diagram

Vi3010
IP Camera
Cat-5
VoIP
MaxiiNet Gigabit Ethernet L2 Plus Managed PoE Switch
Cat-5
Up to 3,000 ft. (914m) Cat-5
Vi2301
Up to 5,000 ft./1,515 m Coax
Vi2401
The Smart Choice for Transmission Solutions
TM
Vi2301
Vi2401
Network Switches
Cat-5
IP Camera
Cat-5
IP Camera
