Summary of Contents for geminox EBS-1 100

  • Page 1 EBS-1 T30.39005.04 High fidelity heat...
  • Page 2: Table Of Contents

    - SELECTIVE VALVE KIT (EBS-1 CONNECTION WITH A ZEM.C BOILER - OPTION) ...... 11 - HYDRAULIC CONNECTION ....................... 12 6.1 - GEMINOX recommendations ....................12 6.2 - EBS-1 WRc approval amendment ................... 12 6.3 - Hydraulic connections for cylinders ..................15 6.4 - Accessories to connect, install or adjust ..................
  • Page 3 CONTENTS VI - MAINTENANCE ..........................24 - TANK MAINTENANCE ........................24 - DRAINING ............................24 - P&T VALVE ............................24 - CHANGING THE THERMOSTATS OR THE THERMOMETER ............25 4.1 - Bulbs positioned in the pocket (7) ................... 25 4.2 - Bulb positioned in the pocket (D) ..................... 25 4.3 - Changing the thermostats or the thermometer ................
  • Page 4: I - Safety Precautions

    I - SAFETY PRECAUTIONS 1 - SYMBOLS In this document: Safety recommendations, warnings and recommendations are by a warning- triangle symbol accompanied by bold text. 2 - SAFETY PRECAUTIONS 2.2 - Operation 2.1 - Fitting, commissioning - Respect these installation instructions to ensure The fitting, the electrical connection and commis-...
  • Page 5: Presentation

    • polystyrene insulation that can be easily OPTIONAL: removed. - Selective valve kit (THI.C/EBS-1) - Selective valve kit (ZEM.C/EBS-1) 2 - RANGE Models Capacity EBS-1 100 100 litres EBS-1 150 150 litres EBS-1 200 200 litres EBS-1 300 300 litres...
  • Page 6: Technical Specifications

    III - TECHNICAL SPECIFICATIONS 1 - CHARACTERISTICS FOR THE EBS-1 EBS-1 Models WRC number 0210132 Tank water capacity litre Tank useful volume litre 98.8 148.6 192.6 292.2 Primary capacity (internal exchanger volume) litre Exchanger surface dm² 78,5 81,7 177,5 184,6 Nominal exchanger power Exchanger load losses Continuous flow rate at 40°C...
  • Page 7: Dimensions

    TECHNICAL SPECIFICATIONS 2 - DIMENSIONS Fig. 1 Top view Models EBS-1 100 EBS-1 150 EBS-1 200 EBS-1 300 1020 1245 1695 - 7 -...
  • Page 8: List Of Components

    TECHNICAL SPECIFICATIONS 3 - LIST OF COMPONENTS 3.1 - EBS-1 models Fig. 2 1) Primary inlet 10) Thermometer 2) Domestic hot water outlet 11) Stainless steel coiled pipe 3) Domestic hot water recycling 12) Domestic cold water elbow and tube* 4) Primary outlet 13) Polystyrene insulation 5) Domestic cold water inlet...
  • Page 9: Domestic Hot Water Production By The Exchanger

    1 hour in 10 min 1 hour 40°C rate (*1) Storage at 80°C Storage at 65°C l/min l/min litres litres litres litres EBS-1 100 13.9 20.1 EBS-1 150 13.9 24.3 1011 EBS-1 200 26.3 38.5 1797 1701 EBS-1 300 27.3 47.7...
  • Page 10: Installation

    (A). 12.2 12.1 3 - FITTING THE IMMERSION HEATER KIT Only Geminox immersion part number Fig. 4 C70.38447 should be used, no other immersion should be used with the EBS-1 tank. Remove the 1''1/2 male plug (7) originally fitted to the sleeve (8) of the domestic hot water production system.
  • Page 11: Selective Valve Kit (Ebs-1 Connection With A Thi.c Or Zem.c Boiler - Option)

    INSTALLATION 4 - SELECTIVE VALVE KIT (EBS-1 CONNECTION WITH A THI.C OR ZEM.C BOILER - OPTION) The selective valve kit enables the hydraulic Fig. 5 connection of the EBS-1 with the THI.C or ZEM.C boilers. - Refer to the kit assembly instructions. ref : W07.31709 5 - SELECTIVE VALVE KIT (EBS-1 CONNECTION WITH A ZEM.C BOILER - OPTION) The selective valve kit enables the hydraulic...
  • Page 12: Hydraulic Connection

    INSTALLATION 6 - HYDRAULIC CONNECTION 6.2.2 - MAINTENANCE 6.1 - GEMINOX recommendations BEFORE COMMENCING ANY MAINTE- NANCE WORK, ISOLATE ALL MAINS Burn risk: ELECTRICITY SUPPLIES TO THE SYS- Never place the isolation valve between the safety control box and the tank.
  • Page 13 • Check operation of expansion relief valve on The EBS-1 range of cylinders is ideally suited for Cold Water Supply kit by lifting manual release connection to our Geminox boilers to match the coil lever and discharging water. ratings. However, connection to non - Geminox •...
  • Page 14 Please Note From table 2 The Geminox range of products are designed to be Maximum resistance allowed for a straight length of used in installations where the complete system is 22mm copper discharge pipe (D2) from a G 1/2 tem- supplied by Geminox therefore when used in con- perature relief valve is 9.0m.
  • Page 15: Hydraulic Connections For Cylinders

    INSTALLATION 6.3.2 - ¾" Unvented kit for EBS-1 cylinders 6.3 - Hydraulic connections for cylinders When the system installed is "Unvented" it is necessary to fit the "unvented kit" on the cold water supply. The "Unvented kit" contains pressure reducing valve, non-return valve, pressure relief valve and optional use balanced cold water connector.
  • Page 16 INSTALLATION 6.3.3 - 1" Unvented kit for EBS-1 cylinders 6.3.4 - 1" Unvented kit for EBS-1 cylinders 1) Unvented kit 2) Safety zone valve 3) Expansion vessel 4) Expansion vessel connection 5) Tundish 4) Expansion vessel connection 6) Cold water 7) Cold water to EBS-1 tank 8) / 9) Balanced cold water...
  • Page 17 INSTALLATION Fig. 7 This drawing has to be read in conjunction with the full installation manuals supplied EBS-16-3E 1) Primary inlet A) Safety device (e.g. temperature relief valve) 2) Domestic hot water supply outlet B) Metal discharge pipe (D1) from temperature relief valve to tundish 3) Domestic hot water return C) Metal discharge pipe (D2) from tundish with...
  • Page 18 INSTALLATION Fig. 8 This drawing has to be read in conjunction with the full installation manuals supplied Note : - This detail is only to be used where there is no other alternative. It is strictly subject to local. Dispensation and approval must be sought from NHBC and Building Control inspector prior to installation.
  • Page 19: Accessories To Connect, Install Or Adjust

    INSTALLATION 6.4 - Accessories to connect, install or adjust - Piping thermal insulation: - Access flap access: To limit heat loss to a minimum, insulate the boiler Leave enough room above the tank to enable link tubes and the tank's domestic hot water outlet access to the stainless steel tank access flap tube.
  • Page 20: Electrical Connection

    INSTALLATION 7 - ELECTRICAL CONNECTION - The electrical connection and all the equipment - Power supply: 230 V - 50 Hz (single phase), used to make this connection must be in - Earth connection compulsory. conformity with the codes of practise in force - the electricity supply must contain a circuit (according to the installation standards), breaker, preferably bipolar, with a 6 A trip switch...
  • Page 21 INSTALLATION 7.1.2 - Boiler equipped with electronic - drill a hole in the upper thermoformed base. regulation - run the domestic hot water sensor bulb delivered with the boiler through this opening, The domestic hot water temperature will be adjusted - position the domestic hot water sensor bulb in the on the boiler's regulator.
  • Page 22: Commissioning

    V - COMMISSIONING 1 - FILLING THE INSTALLATION WITH WATER - Filling the installation: - Filling the tank: • before you fill, rinse the installation's pipes, • fill the domestic hot water production system except for the tank. using the installation's safety control box (8, fig.
  • Page 23: Commissioning

    COMMISSIONING 4 - COMMISSIONING 4.1 - Boiler with domestic hot water load Fig. 12 pump - Adjust the domestic hot water temperature setting thermostat (9, fig. 12) according to the selected temperature -  Recommended setting 55/60 °C (read on the thermometer ( 10)).
  • Page 24: Maintenance

    VI - MAINTENANCE An annual inspection of the tank is compulsory. It type and serial number. must be carried out by a qualified professional. Disconnect the electricity supply before All spare parts will be original parts and must be carrying out any action on the tank. ordered using the references in chapter VII - PARTS LIST - page 26, specifying the appliance 1 - TANK MAINTENANCE...
  • Page 25: Changing The Thermostats Or The Thermometer

    MAINTENANCE 4 - CHANGING THE THERMOSTATS OR THE THERMOMETER 4.1 - Bulbs positioned in the pocket (7) - unscrew the attachment screw on the thermostat (17) - Domestic water temperature setting thermostat (9). - remove the defectives thermostats (9 / 17) and replace it, - Water overheating safety thermostat (17).
  • Page 26: Parts List

    VII - PARTS LIST EBS-1 100/150/200/300 - 26 -...
  • Page 27 PARTS LIST Reference Item. Description A00.03749 FLANGE PLASTIC D.27 WHITE A90.15475 GREY PS CLEANING DOOR C91.20704 CABLE BUSHING; GLAND N° 11 + NUT A90.38569 THERMOFORMED BOTTOM GREY L60.01135 THERMOSTAT RECT HORIZ 69X14 LG CAPIL.1500 MM L71.10972 THERMOSTAT 20/80°C L71.15349 BLACK THERMOSTAT KNOB L71.16695 BLACK CAP FOR THE THERMOSTAT D20.34129...
  • Page 28: Rating Plate Abbreviations

    VIII - RATING PLATE ABBREVIATIONS Abbreviation Description Total volume of the tank Useful volume of the tank Vech Internal volume heat exchangers Pn ech Rated power heat exchangers T max Maximum domestic hot water storage temperature Maximum operating pressure Static heat losses of the tank - 28 -...
  • Page 29: Warranty Terms

    These parts The repair, modification or replacement of once again become the property of GEMINOX parts during the warranty period may not have and must be returned to them without delay.
  • Page 30 NOTES - 30 -...
  • Page 31 NOTES - 31 -...
  • Page 32 For the UK, please contact : Evinox Ltd Blenheim House 1 Blenheim Road Epsom Surrey KT19 9AP : +44 (0)1372 722277 : +44 (0)1372 744477 e-mail sales@evinox.co.uk technical@evinox.co.uk www.evinox.co.uk Company number 4404137 For Eire, please contact : VCS Valve Control Systems Ltd Unit 3, Dunshaughlin Business Park Dundshauglin Co Meath...
