- Page 1 06178 UNDERWATER HOUSING for Canon EOS Kiss X8i / REBEL T6i / 750D RDX-750D 取扱説明書 Instruction Manual...
-
Page 2: Table Of Contents
Introduction Thank you for purchasing SEA&SEA products. Please read this instruction manual carefully prior to using this product. Only with a thorough understanding of this manual’s content will you be able to use the housing correctly. After reading the manual, please be sure to keep it in a place where you can easily come back to it at any time. -
Page 3: Safety Precautions
Safety Precautions For safe handling of the product, please read the following precautions carefully before use. Failure to heed the precautions listed below could result in serious consequences. To prevent injury or damage to yourself and/or others, please observe the precautions as they contain highly important information related to personal and product safety. - Page 4 Safety Precautions Do not rest heavy weight on the product. It might deform the outer casing, damage internal parts, make the waterproofing fail, or result in fire or electric shock. Please note that some marks may be left on the camera scraping against the dials or gears of the housing.
-
Page 5: Precautions On Handling The O-Ring
Precautions on Handling the O-ring This product is kept watertight by the O-ring. To keep the O-ring functioning properly, please observe the following. Improper handling of the O-ring could cause flooding. CAUTION SEA&SEA products use blue O-rings. These O-rings are impregnated with silicone oil through a special process. - Page 6 Precautions on Handling the O-ring Coat with silicone grease Silicone grease protects the O-ring from chafing. After checking the O-ring to make sure that there are no scratches, dust, or debris, apply a light coating of silicone grease to the entire O-ring with your finger. Applying too much grease will make it easier for dust and debris to adhere to the O-ring, and could cause flooding.
-
Page 7: Identification Of Parts
Identification of Parts AF area selection button Accessory shoe ISO speed set button Fiber-optic cable socket Display button Power switch Hand strap eyelet Focus / Zoom dial Main dial Shutter lever Buckle Buckle lock lever Hand strap eyelet Port mount ring Housing body cap for RDX Front case Viewfinder... -
Page 8: Pressure Balance Control Valve
Identification of Parts Front case Camera tray Fixing screw Camera base Knob Pressure balance control valve This product comes equipped with a pressure balance control valve. Pushing the valve counterbalances the pressure difference that occurs due to temperature or atmospheric changes, and makes it possible to open the housing. -
Page 9: Preparation For Setting Up
Preparation for Setting Up This product must be used in combination with the optional equipment (digital camera, port, strobe, accessories etc.) for underwater photography. In order to set up the equipment, prepare each item correctly. Prepare the housing and port Maintaining the O-ring O-ring This product is kept watertight by the O-ring. -
Page 10: Opening And Closing The Housing
Opening and Closing the Housing Opening and closing the housing is done with the buckles. Here we will explain how to open and close the buckles. Opening the buckle Press and hold the buckle lock lever (①), and remove the right and left buckles simultaneously (②) CAUTION When removing the buckle, be sure to use... -
Page 11: Attaching And Detaching The Port
Attaching and Detaching the Port (option) In order to use this product underwater, the optional port (option) for the camera lens must be attached to this product. CAUTION Only the optional ports designed for SEA&SEA RDX-series housings can be attached to this product. This product is delivered with a housing body cap attached to the port mount. - Page 12 Attaching and Detaching the Port (option) Rotate the port mount ring toward LOCK (in a clockwise direction) until you hear it click into position Make sure that the port lock has returned to the lock position as shown in the diagram. Click Lock position Detaching the port...
-
Page 13: Mounting The Camera In The Housing
Mounting the Camera in the Housing CAUTION Make sure to remove the eyecup from the camera. If used with the eyecup in place, it could cause flooding. Release the lock on the camera tray by pushing the knob in the direction of the arrow ( ), and slide the camera tray out ( ) Knob... - Page 14 Mounting the Camera in the Housing Pop up the camera's built-in flash. Align the camera tray with the camera base inside the front case, and slide the camera forward into the front case Make sure to pop up the built-in flash of the camera before mounting the camera in the housing.
-
Page 15: Connecting The Strobe
Connecting the Strobe This product comes equipped with two fiber-optic cable sockets. Connect the strobe with the fiber-optic cable (option) when the strobe is triggered by sensing the light from the camera's built-in flash. Remove the fiber-optic cable Fiber-optic cable socket cap socket caps Insert the fiber-optic cable's connector into the socket until... -
Page 16: Attaching The Hand Strap
Attaching the Hand Strap Put the hand strap through the ③ hand strap eyelet on top of the ② housing as shown ④ ① Put the hand strap through the hand strap eyelet on bottom of ④ ② the housing as shown ③... -
Page 17: External Controls
External Controls Power switch Power switch By rotating the knob as indicated, you can turn the power ON/OFF. Shutter lever Push the lever toward you or gently press on it from the top to control the shutter button of the camera. Focus / Zoom dial When a focus or zoom gear (option) is Shutter lever... -
Page 18: Attaching The Optional Accessories
Attaching the Optional Accessories This product accepts SEA&SEA optional accessories. By using this product in combination with those accessories, you will be able to try various shooting techniques. CAUTION Lenses, strobes and other accessories have different depth rating. Check the depth rating for each before use. Read the instruction manual for each accessory before use. -
Page 19: Accessory Shoe
Attaching the Optional Accessories Accessory shoe SEA&SEA strobes / lights can be mounted to the accessory shoe by using optional Mini Shoe Arm (29511) or Hot Shoe Arm (29501). <Example> CAUTION The max. weight of an accessory that can be mounted to the accessory shoe is approx. -
Page 20: Maintenance And Storage
Maintenance and Storage CAUTION Never use chemicals, cosmetics, any petroleum solvents such as paint thinner, or neutral detergent on the product. They may deform and damage the product. After each use in salt water, make sure it’s watertight, then soak it sufficiently in fresh water. -
Page 21: Specifications
Specifications Compatible Canon EOS REBEL T6i / 750D camera Power switch, ISO speed set button, Focus / Zoom Controls dial, Shutter lever, Main dial, Mode dial, AF point selection / Magnify button, AE lock / FE lock / Index / Reduce button, Live View shooting / Movie shooting button, Aperture / Exposure compensation button, Cross button, SET button, Erase button, Playback button, MENU button, Info button, Quick... - Page 22 SEA&SEA SUNPAK Co., Ltd. シーアンドシー・サンパック株式会社 1-4-6, Kitasenzoku, Ohta-ku, 〒145-0062 東京都大田区北千束1-4-6 Tokyo, Japan 145-0062 TEL.03-5701-5533 TEL. +81-3-5701-5533 カスタマーサービスセンター World Customer Service Center TEL.048-255-8512 TEL. +81-48-255-8512 http://www.seaandsea.jp http://www.seaandsea.co.jp 1522-Z-01A (2015年10月現在 / Current as of Oct.2015)
