DA-2000
2x1 B&W Screen Splitter
Instruction Manual
Thank you for purchasing one of our products. Please read this manual before using this
product. When using this product, always follow the instructions contained in this manual,
and pay attention to the safety information.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CVS DA-2000
Summary of Contents for CVS DA-2000
- Page 1 DA-2000 2x1 B&W Screen Splitter Instruction Manual Thank you for purchasing one of our products. Please read this manual before using this product. When using this product, always follow the instructions contained in this manual, and pay attention to the safety information.
- Page 2 Do not expose this product to water, rain or moisture. Doing this can result in electric shock or fire. Never take this product apart or try to modify it. Doing so is very dangerous and could result in electric shock. Do not store this product near open flame.
- Page 3 The DSP-2000 is a 2 camera video screen splitter that does not require any genlock feeds for the cameras. By using digital technology CVS is able to capture and synchronize one camera to another so that the pictures can be split. The size, type and position of the split (Fig.
- Page 4 Camera Requirements: The DSP-2000 will work with 1 Color or B&W camera for input 1 and only a B&W camera for input 2 which is the digitized input. Both cameras must conform with RS-170A sync timing standards. This means they must also be interlaced with the proper pulse widths and sync frequencies.
- Page 5 For units with serial numbers before 201225 the vertical delay can be disable: The units are shipped with the variable vertical delay activated. If you are going to use a vertical split (2 pictures, side by side) you need to disable the vertical delay. For newer units simply turn the “Camera 2 Vertical Delay”...
- Page 6 ·Set the front panel switch to the center split position. ·It is recommended that you center the controls and vary each one while observing the picture. This will give you a feel for the way each control effects the picture. ·Begin by adjusting the start of the split with the Height Start Control.
- Page 7 Fig. 6 Diagram P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
- Page 8 KEY FEATURES: ·High resolution: 910x525 memory ·TBC feature, mix DC and LL Cameras ·Industrial grade specifications ·Color or B&W master camera ·Electronic positioning of B camera ·UL listed Power Supply ·Made in the USA P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
- Page 9 P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
- Page 10 NOTES: P.O. Box 749 Peekskill, NY 10566 Tel: (845) 737-7009 Fax: (845) 737-0426 Web: www.compuvideosystems.com...
-
Page 11: Limited Warranty
Compu-Video Systems Inc. to the user is free of charge. How To Get Service Please contact CVS by phone for return authorization number and then return the defective unit, transportation prepaid and a dated proof of purchase to: Compu-Video Systems Inc.
