Miditech Audiolink USB
"Class Compliant" USB Audio Interface
(WinXP/Vista no drivers necessary)
16 Bit/ 48 kHz resolution line stereo interface
XLR Mic preamp with 48 V Phantom Power
and gain control
HI-Z guitar preamp with gain control
Adjustable stereo headphone output
Full duplex with compatible recording software
USB powered
Include: Magix Samplitude SE
ASIO driver
Typical applications:
Recording from microphone, instruments and LINE devices,
e.g. cassette, CD-players or mp3-players
Low latency when playing VST instruments
eMail:
info@miditech.de
Internet:
www.miditech.de
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Audiolink and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Miditech Audiolink

Summary of Contents for Miditech Audiolink

  • Page 1 Miditech Audiolink USB "Class Compliant" USB Audio Interface (WinXP/Vista no drivers necessary) 16 Bit/ 48 kHz resolution line stereo interface XLR Mic preamp with 48 V Phantom Power and gain control HI-Z guitar preamp with gain control Adjustable stereo headphone output...
  • Page 2 Audiolink USB audio interface Owner’s Manual Thank you for deciding to purchase the Miditech Audiolink, we are certain you will be delighted with its performance and advanced features. This interface brings an unparalleled level of USB audio quality to the Mac or PC, with pristine 16-bit/48kHz A/D and D/A converters, ultra-low jitter clock, and low noise mic/line/hi-Z preamps.

  • Page 3: Hardware Setup

    10. RCA Output 1 and 2 : These unbalanced RCA outputs the signal which is from your computer and should be connected to a pair of powered speakers, a mixer or a stereo amplifier. 12. USB Jack: This jack connects the Audiolink to your computer, using a USB 1.1 (or higher) connection.

  • Page 4: Software Installation

    USB cable, to a free USB port on your computer. When the Audiolink is attached the red POWER LED lights up briefly to signal a good power supply to the Audiolink. The installation under Windows will then take place automatically, a few seconds after connecting to your computer-system it will find a "USB Audio Codec"...
  • Page 5 Control Panel Setup Once setup is complete, you can control most aspects of the Audiolink Pro using its control panel.To launch the control panel in your operating system, check the following instructions: The control panel has the following sets of controls: Configuration: Device: Please chose the Audiolink Pro USB audio device.
  • Page 6 „audio set-up“. If you have installed the ASIO2ks driver, you can adjust this here as a "record and play“ device - please choose the ASIO2ks driver for Audiolink Pro. Below this the actual latency time will be displayed after selecting the driver, also, by clicking the button „Attitudes“...
