INTRODUCTION

The artec 300 series full range systems have been designed to provide wide bandwidth and high SPL in a
visually discrete package. The artec 300 products can be installed on walls, ceilings or columns thanks to an
extensive selection of optional mounting accessories. The ideal choice for under balcony, area fill and near
field applications, their reduced dimensions and sleek styling fits perfectly into multiple surroundings including
hotels and restaurants, from elegant nightclub installations to educational facilities.
Features
artec 306
artec 308
artec 310.96
artec 310.64
6
- 1x 6" low frequency loudspeaker
- 1x 1" exit compression driver
- Rotatable 90ºx60º horn
- Vertical or horizontal positioning
- VESA-75/VESA-100 standard threaded mounting points
- Versions with factory-installed line transformer and black or white finishes
available.
The artec 306 employs a single 6" woofer for low frequency reproduction.
The M-26 compression driver provides the highs. The birch plywood cabinet
construction offers an ultra-compact design which is available in black or
white. Precise coverage and control in either the horizontal or vertical position
is possible thanks to the 90ºx60º horn geometry. The cabinets can be
permanently installed by way of the included "U" brackets and the other
optional accessories which allow for multiple configurations. Four threaded
fixing points for the wall mount and stand mounting accessories augment
adaptability. A robust steel grille internally lined with acoustically transparent
filter cloth protects components.
- 1x 8" low frequency loudspeaker
- 1x 1" exit compression driver
- Rotatable 90ºx60º horn
- Vertical or horizontal positioning
- VESA-75/VESA-100 standard threaded mounting points
- Versions with factory-installed line transformer and black or white finishes
available.
The artec 308 employs a single 8" woofer for low frequency reproduction.
The M-26 compression driver provides the highs. The birch plywood cabinet
construction offers an ultra-compact design which is available in black or
white. Precise coverage and control in either the horizontal or vertical position
is possible thanks to the 90ºx60º horn geometry. The cabinets can be
permanently installed by way of the included "U" brackets and the other
optional accessories which allow for multiple configurations. Four threaded
fixing points for the wall mount and stand mounting accessories augment
adaptability. A robust steel grille internally lined with acoustically transparent
filter cloth protects components.
- 1x 10" low frequency loudspeaker
- 1x 1" exit compression driver
- Rotatable 90ºx60º / 60ºx40º horn (different models)
- Vertical or horizontal positioning
- VESA-75/VESA-100 standard threaded mounting points
- Versions with factory-installed line transformer and black or white finishes
available.
The artec 310.XX employs a single 10" woofer for low frequency
reproduction. The M-34 compression driver provides the highs. The birch
plywood cabinet construction offers an ultra-compact design which is
available in black or white. Precise coverage and control in either the
horizontal or vertical position is possible thanks to the 90ºx60º horn geometry
in artec 310.96, or the 60ºx40º horn geometry in artec 310.64. The cabinets
can be permanently installed by way of the included "U" brackets and the
other optional accessories which allow for multiple configurations. Four
threaded fixing points for the wall mount and stand mounting accessories
augment adaptability. A robust steel grille internally lined with acoustically
transparent filter cloth protects components.
Manual del Usuario / artec 300 series / User's Manual
artec 306
artec 308
artec 310.96 / artec 310.64
