Sony CFD-V177L Operating Instructions

Use TYPE I (normal) tape only.
Playing a tape Recording
1 1
Press xZ to open the tape compartment and insert a Press xZ to open the tape compartment and insert a
recorded tape. Close the compartment. blank tape.
c
With the side you want to
play facing upward
2 2
Set FUNCTION to TAPE•CD/RADIO OFF. Select the program source you want to record.
To record from the CD player
Set FUNCTION to CD and insert a CD (see "Playing a
CD").
3
Press N.
To record from the radio
Tune in the station you want (see "Listening to the
radio").
To Do this
adjust the volume Turn VOLUME.
stop playback Press xZ.
fast-forward or rewind the tape Press M or m.
3
pause playback Press X.
Press z to start recording.
Press the button again to resume play
(N is depressed automatically).
after pause.
eject the cassette Press xZ.
Notes on cassettes
• Break off the cassette tab from side A or B to prevent accidental
recording. If you want to reuse the tape for recording, cover the broken
tab with adhesive tape.
Side A
To
stop recording
pause recording
Tab for side A
Tab for side B
• The use of a cassette with more than 90 minutes of play time is not Tips
recommended except for long, continuous recording or playback.
• Adjusting the volume or the audio emphasis will not affect the
recording level.
• CFD-V21L/V27L/V31L/V177L only:
If the MW/LW program makes a whistling sound after you've pressed
r in step 3, set the FM MODE•ISS (Interference Suppress Switch) at
the rear to the position that most decreases the noise.
• For the best results, use the AC power as a power source for recording.
• To erase a recording, proceed as follows:
1 Insert a tape with the recording you want to erase.
2 Set FUNCTION to TAPE•CD/RADIO OFF.
3 Press z.
Use TYPE I (normal) tape only.
• Make sure the FUNCTION
Troubleshooting
• Make sure the FUNCTION
General
The power does not come on.
• Connect the AC power cord
securely.
• Make sure the batteries are
Poor or distorted playback,
inserted correctly.
recording or erasing quality.
• Replace all the batteries with new
• Clean the heads, pinch roller and
c
ones if they are weak.
There is no audio.
• Make sure the FUNCTION
• Replace all the batteries with new
selector is set to the function you
want to operate.
With the side you want to
• TYPE II (high position) or TYPE
• Adjust the volume.
record on facing upward
• Unplug the headphones when
listening through speakers.
• Demagnetize the heads using a
Noise is heard.
• Someone is using a portable
telephone or other equipment that
emits radio waves near the player.
tMove the portable telephone,
etc., away from the player.
Radio
The audio is weak or has poor
quality.
• Replace all the batteries with new
ones if they are weak.
• Move the player away from the
TV.
The picture of your TV becomes
unstable.
• If you are listening to an FM
program near the TV with an
indoor antenna, move the player
away from the TV.
CD Player
The CD does not play or "00 -- --" After trying the above remedies, if
you still have problems, unplug the
lights in the display even when a
CD is in place. AC power cord and remove all the
batteries. After all the indications in
• Make sure that the CD
the display disappear, plug the power
compartment is closed.
cord and insert the batteries again. If
• Place the CD with the label
the problem persists, please consult
surface up.
your nearest Sony dealer.
• Clean the CD.
• Take out the CD and leave the CD
compartment open for about an
hour to dry moisture
condensation.
• Make sure the FUNCTION
selector is set to CD.
The sound drops out.
• Reduce the volume.
• Clean the CD, or replace it if the
CD is badly damaged.
Press
• Place the player in a location free
xZ
from vibration.
X • Clean the lens with a
Press the button again to resume recording. commercially available blower.
• The sound may drop out or noise
may be heard if the CD is
recorded using a personal
computer(CD-R,etc.).
Tape Player
The tape does not move when you
press an operation button.
• Close the cassette compartment
securely.
The REC z button does not
function or the tape does not play
or record.
• Make sure the safety tab on the
cassette is in place.
General
selector is set to CD, AM or FM. Specifications
Speaker
(CFD-V27/V177) CFD-V21L/V27/V27L/V31L/V177/V177L:
Full range: 10 cm dia., 3.2 ohms, cone
type (2)
CD player section
selector is set to CD or RADIO.
CFD-V77S: Full range: 10 cm dia., 6
(CFD-V21L/V27L/V31L/V177L/ System
ohms, cone type (2)
V77S) Compact disc digital audio system Outputs
Laser diode properties Headphones jack (stereo minijack)
Material: GaAlAs For 16 - 68 ohms impedance
Wave length: 780 nm headphones
Emission duration: Continuous Maximum power output (excluding Korean
model)
Laser output: Less than 44.6 µW
CFD-V21L/V27/V27L/V31L/V177/V177L:
(This output is the value measured at a
capstan with a cleaning swab 2.3 W + 2.3 W
distance of about 200 mm from the
objective lens surface on the optical CFD-V77S: 4.5 W + 4.5 W
slightly moistened with cleaning
pick-up block with 7 mm aperture.)
Power output (CFD-V27 Korean model)
fluid or alcohol.
Spindle speed
1.6 W + 1.6 W (at 3.2 ohm, 10 %
harmonic distortion in AC operation)
200 r/min (rpm) to 500 r/min(rpm)
ones if they are weak. (CLV)
Power requirements
Number of channels
For CD radio cassette-corder
2
IV (metal) tape is being used. Use
Europe
Frequency response
TYPE I (normal) tape only.
20 - 20,000 Hz +1/–2 dB
230 V AC, 50 Hz
Wow and flutter
commercially available tape head Korea
Below measurable limit
demagnetizer.
220 V AC, 60 Hz
Radio section
Other countries
Frequency range
Record/playback head
110 - 127, 220 - 240 V AC selectable,
CFD-V21L/V31L
Capstan 50/60 Hz
or 230 V AC, 50 Hz
FM Italy 87.5 - 108 MHz
Other models 87.6 - 107 MHz
9 V DC, 6 R20 (size D) batteries
MW Italy 526.5 - 1,606.5kHz
Power consumption
Other models 531 - 1,602kHz
CFD-V21L/V27/V27L/V31L/V177/V177L:
Korean model: AC 15 W
Erase head Pinch roller
LW Italy 148.5 - 283.5 kHz
Other models: AC 20 W
Other models 153 - 279kHz
CFD-V77S: AC 25 W
Lens
CFD-V27/V177
Battery life
For CD radio cassette-corder:
FM Korea 87.6 - 107 MHz
Other models 87.6 - 108 MHz
CFD-V21L/V27/V27L/V31L/V177/V177L
or 87.6 - 107 MHz
FM recording
AM Korea 531 - 1,602 kHz
Other models 530 - 1,605 kHz
Sony R20P: approx. 13.5 h
or 531 - 1,602 kHz
Sony alkaline LR20: approx. 20 h
CFD-V27L/V177L
Tape playback
FM Italy 87.5 - 108 MHz
Central and Eastern Europe
Sony R20P: approx. 7.5 h
65 - 108 MHz
Other models 87.6 - 107 MHz
Sony alkaline LR20: approx. 15 h
MW Italy 526.5 - 1,606.5 kHz
CD playback
Other models 531 - 1,602 kHz
Sony R20P: approx. 2.5 h
LW Italy 148.5 - 283.5 kHz
Other models 153 - 279 kHz Sony alkaline LR20: approx. 7 h
CFD-V77S
CFD-V77S
FM Italy 87.5 - 108 MHz
Central and Eastern Europe FM recording
65 - 108 MHz
Sony R20P: approx. 3.5 h
Other European models and
Saudi Arabia
Sony alkaline LR20: approx. 10 h
87.6 - 107 MHz
Other models 87.6 - 108 MHz
Tape playback
MW Italy 526.5 - 1,606.5 kHz
Sony R20P: approx. 1.5 h
Other European models
531 - 1,602 kHz
Sony alkaline LR20: approx. 5 h
Other models 530 - 1,605 kHz
CD playback
or 531 - 1,602 kHz
SW1 2.3 - 7 MHz Sony R20P: approx. 1 h
Sony alkaline LR20: approx. 4 h
SW2 7 - 22 MHz
IF
Dimensions
FM: 10.7 MHz
Approx. 420 165 256 mm (w/h/d)
AM/MW/LW/SW: 455 kHz
(16 5 ⁄ 6 1 ⁄ 10
8 2
Aerials
projecting parts)
FM/SW: Telescopic aerial
Mass (incl. batteries)
AM/MW/LW: Built-in ferrite bar aerial
CFD-V21L/V27/V27L/V31L/V177/V177L:
Approx. 4.1 kg (9 lb. 1 oz)
Cassette-corder section
CFD-V77S: Approx. 4.2 kg (9 lb. 4 oz)
Recording system Supplied accessory
4-track 2 channel stereo AC power cord (1)
Fast winding time
Design and specifications are subject to
Approx. 120 s (sec.) with Sony cassette
C-60 change without notice.
Frequency response
TYPE I (normal): 70 - 10,000 Hz Optional accessories
Sony MDR headphone series
WARNING
To prevent fire or shock
hazard, do not expose the
player to rain or moisture.
CD Radio
To avoid electrical shock, do
Cassette- not open the cabinet. Refer
servicing to qualified
Corder
personnel only.
Information
For customers in Europe
Operating Instructions
CFD-V21L
CFD-V27
This Compact Disc player is
CFD-V27L
classified as a CLASS 1 LASER
product.
CFD-V31L
The CLASS 1 LASER PRODUCT
label is located on the bottom
CFD-V77S
exterior.
CFD-V177
CFD-V177L
Sony Corporation © 1999
Printed in Vietnam
3-043-560-12(1)
• For battery operation, use six size
Precautions
D (R20) batteries.
• When the batteries are not to be
On safety used, remove them to avoid
damage that can be caused by
• As the laser beam used in the CD
battery leakage or corrosion.
player section is harmful to the
• The nameplate indicating
eyes, do not attempt to
operating voltage, power
disassemble the casing. Refer
servicing to qualified personnel consumption, etc. is located at the
bottom.
only.
• Should any solid object or liquid
On placement
fall into the player, unplug the
• Do not leave the player in a
player, and have it checked by
location near heat sources, or in a
qualified personnel before
place subject to direct sunlight,
operating it any further.
excessive dust or mechanical
Cleaning the cabinet shock.
• Clean the cabinet, panel and • Do not place the player on an
inclined or unstable place.
controls with a soft cloth slightly
moistened with a mild detergent • Do not place anything within 10
solution. Do not use any type of mm of the side of the cabinet. The
1 ⁄ inches) (incl. abrasive pad, scouring powder, or
8 ventilation holes must be
solvent, such as alcohol or unobstructed for the player to
benzine. operate properly and prolong the
life of its components.
On power sources
• If the player is left in a car parked
• For AC operation, check that the
in the sun, be sure to choose a
player's operating voltage is
location in the car where the
identical with your local power
player will not be subjected to the
supply (see "Specifications") and
direct rays of the sun.
use the supplied AC power cord;
• Since a strong magnet is used for
do not use any other type. The
the speakers, keep personal credit
voltage selector is located at the
cards using magnetic coding or
bottom of the player (CFD-V77S
spring-wound watches away from
except European models).
the player to prevent possible
• The player is not disconnected
damage from the magnet.
from the AC power source
(mains) as long as it is connected
to the wall outlet, even if the
player itself has been turned off.
English
WARNING About this manual
Do not install the appliance in a The instructions in this manual are
confined space, such as a bookcase or for the CFD-V21L, CFD-V27, CFD-
built-in cabinet. V27L, CFD-V31L, CFD-V77S, CFD-
V177 and CFD-V177L. Before you
start reading, check your model
The FUNCTION selector is located at
number. The CFD-V27L is the model
the front.
used for illustration purposes.
When you turn on the player, the
Any differences in operation are
OPR/BATT indicator lights up.
clearly indicated in the text, for
Notice for customers in the United
example, "CFD-V77S only," and also
Kingdom
in the chart below.
A moulded plug complying with BS
1363 is fitted to this equipment for
Model number
your safety and convenience. Band
CFD-V27/V177
FM, AM
Should the fuse in the plug supplied
need to be replaced, same rating fuse CFD-V21L/V27L/ FM, MW,LW
approved by ASTA or BSI to BS 1362,
V31L/V177L
(i.e. marked with or mark) must
CFD-V77S FM, SW1, SW2,
be used.
MW
If the plug supplied with this
equipment has a detachable fuse
cover, be sure to attach the fuse cover
after you change the fuse. Never use
the plug without the fuse cover. If you
should lose the fuse cover, please
contact your nearest Sony service
station.
On operation
• If the player is brought directly
from a cold to a warm location, or
is placed in a very damp room,
moisture may condense on the
lenses inside the CD player
section. Should this occur, the
player will not operate properly.
In this case, remove the CD and
wait about an hour for the
moisture to evaporate.
• If the player has not been used for
a long time, set it in the playback
mode to warm it up for a few
minutes before inserting a
cassette.
If you have any questions or problems
concerning your player, please consult
your nearest Sony dealer.
