Desktop UHF Radio Paging System
Installation & User Manual
Scope Communications UK Ltd, Quantum House, Steamer Quay, Totnes, Devon TQ9 5AL
Tel: +44 1803 860700 Fax: +44 1803 863716 Email: sales@scope-uk.com Web: www.scope-uk.com
rack 20
rack 20
rack 20
rack 20
DTK/3

Advertisement

Table of Contents
loading

Related Manuals for scope DataTrack 20

Summary of Contents for scope DataTrack 20

  • Page 1 20 DataT DataT rack 20 Desktop UHF Radio Paging System Installation & User Manual Scope Communications UK Ltd, Quantum House, Steamer Quay, Totnes, Devon TQ9 5AL Tel: +44 1803 860700 Fax: +44 1803 863716 Email: sales@scope-uk.com Web: www.scope-uk.com DTK/3...

  • Page 2: Important Installation Information

    Scope has no control of the use and application of the frequencies issued by the Radiocommunications Agency. Some equipment that is licensed may have greater protection than other equipment which is operated on a WT Act License Exempt basis.

  • Page 3: Warranty

    This product is warranted as free from defects of workmanship and materials for a period of one year from the original purchase date. During this time, if there is a defect or malfunction of this product, Scope will, with proof of purchase, repair or replace at it’s discretion any defective parts, free of charge.

  • Page 4: System Overview

    DataTrack 20 System Overview The Scope DataTrack 20 is a desktop radio transcoder which can be used to transmit both text and numeric messages direct to pocket pagers carried by individuals or entire groups. Data can also be transmitted to a central controller for sorting and re-routing to pre-programmed groups and individuals.
  • Page 5 DataTrack 20 Wall Mounted Units 1 Identify a suitable location for fixing the unit, observing the recommendations detailed on page 5. 2 Ensure that a minimum of 8 inches beneath the intended location is left clear for the antenna, and check that the power cable, when fitted, is within reach of a mains wall outlet.
  • Page 6 DataTrack 20 Some major points to consider when installing equipment: Avoid placing the DataTrack 20 in the immediate vicinity of telephone exchanges or computer equipment. Also remember that the performance of the system will be affected by the type of material the unit is mounted on and its surroundings.

  • Page 7: Operation

    DataTrack 20 Operation Prior to operation, check that the DataTrack keypad unit has it’s aerial correctly fitted and that the 12v power lead is firmly plugged into the socket provided at the rear of the unit. The red POWER light on the fascia panel will be lit to indicate that the power is connected and the unit is ready for use.

  • Page 8: Specification

    220 (L) x 130 (W) x 90 (H) max * Mounting Desk or Wall mounted with optional bracket excluding aerial Scope’s policy is one of continuous development and specifications are subject to change without prior notice DTK STD Issue 3...
